Playcore ultraPLAY early play UP145 Manual

UP145 SURFACE MOUNT PACKAGE FOR LEARN-A-LOT
Items listed below Hardware Complete line are included with Hardware Complete Number
Warning: During Installation, Hardware And Small Parts Are Choking Hazards For Young Children. Store
Unused Parts Appropriately Until Assembly Is Completed. Once Assembly Is Completed, Remove Any
Unused Parts From The Play Environment And Dispose/Save Them In A Secure Location. Any bolt end
protruding more than two full threads beyond the face of the nut causes risk of clothing entanglement.
INSTALLATION INSTRUCTIONS:
UP142 & UP143
1. Attach Door, Window, Music, Caterpillar Panel, and 90° Angle Bracket to each other using 90° Angle Bracket, 3/8" x 3/4" Carriage
Bolt, and 3/8" Barrel Nut. See Detail 055.
2. After Assembly is complete drill 3/8" diameter x 2" deep holes in concrete to receive Wedge Anchors.
3. Insert Wedge Anchors and secure with 7/8" O.D. Flat Washers and 3/8" Lock Nut. See Detail 053.
MAINTENANCE PROCEDURE:
Periodically check hardware for tightness, and tighten as necessary. Always check all parts for breakage or wear, and immediately
put equipment out of service until any faulty parts found are repaired or replaced. Also Check all metal parts for rust, paint loss and
touch-up if necessary with paint. Check for welded areas and verify integrity. Check periodically resilient surfacing for appropriate
depth and remove extraneous materials that could cause injury, infection, or disease. Maintain detailed installation, inspection,
maintenance, and repair records for each public-use playground equipment.
Issued/Revised: 01/24/12
800.458.5872
(USED ON MODEL #UP142 & UP143)
DESCRIPTION
3/8" x 2 3/4" WEDGE ANCHOR
90° ANGLE BRACKET
Unless Otherwise Specified, All Units of Measure are Each
Promptly cut-off flush, file smooth, and treat to prevent corrosion.
Parts List
QTY PART NUMBER
4 800076
4 403204
www.ultraplay.com
1
