FORMING FUNCTION Elevate Monitor Arm60 User Manual

USER MANUAL
Elevate Monitor Arm
PARTS AND TOOLS
x1 PCE
A1
x1 PCE
A2
B ×1 PCE
C
×1 PCE
D ×1 PCE
E ×1 PCE
F ×2 PCS
G ×4 PCS
H ×1 PCE
I ×2 PCS
K ×1 PCE 5mm
L ×1 PCE 4mm
M ×1 PCE 2.5mm
N ×1 PCE
Before assembly please spend some time reading this and follow the procedures step by step. Some panels are
viewed differently from the detail drawing below. This is for extra clarity. Do not discard any of the packaging until
you have checked all the parts and tools. If you are missing any of the parts, please contact your supplier.
4386006002
ART. NO
4386006009
4386006001
60
1
STEP 1
"CLAMP" ASSEMBLY
Adhere the pad to the base of the clamp.
Then clamp the arm to the desk.
Fits desk thicknesses 0.32"~3.38"(8-86mm)
LOWER ATTACHMENT POSITION
"GROMMET" ASSEMBLY STEP 1 1
Use 4mm alien key to loosen the 4 screws, then
detach clamp mount from the arm.
Note: Do not lose the screws as they will be
used to attach the grommet mount.
ADHERE
UPPER ATTACHMENT POSITION
~1.4" (36mm)
