  • Page 1 iHope Ventilator Service Manual RV series...
  • Page 2 Resvent Marketing Department. While the information set forth is believed to be accurate, it is not a substitute for the exercise of professional judgment. Nothing in this manual shall limit or restrict in any way Resvent’s right to revise or otherwise change or modify the equipment (including its software) described herein, without notice.

  • Page 3: Table Of Contents

    Contents 1 Safety............................. 1 1.1 Safety Information......................1 1.1.1 Definitions........................1 1.1.2 Warning..........................1 1.1.3 Caution..........................2 1.1.4 Note..........................3 1.2 Symbols..........................3 2 Theory of Operation for Pneumatic..................6 2.1 Pneumatic Circuit.......................6 2.1.1 Overview of the Pneumatic System................6 2.1.2 Pneumatic Circuit Diagram................... 6 2.1.3 Theory of Operation of the Pneumatic Subsystem............8 2.1.4 Inspiratory valve Subsystem..................
  • Page 4 6.2.2 the Mechanical Ventilation test..................47 6.2.3 The Sensor Zero Point test..................48 6.2.4 The Accuracy of Flow Sensor test................49 6.2.5 the Accuracy of Pressure Sensor test..............50 7 Calibration..........................51 7.1 Patient Flow Calibration....................52 7.1.1 Calibration Procedures....................52 7.1.2 Error Codes and Corrective Actions................. 53 7.2 O2% Calibration.......................54 7.2.1 Calibration Procedures....................
  • Page 5 9.2.15 Replace the Inspiratory Valve Seat Component..........95 9.2.16 Replace the Expiratory Valve Seat Component...........95 9.2.17 Replace the Turbine Component................95 9.2.18 Replace the O2 Inlet Component................96 9.2.19 Replace the 3-way Valve Component..............96 9.2.20 Replace the Gas Capacitor Component..............97 9.2.21 Replace the Speaker....................97 9.2.22 Replace the Power Board..................
  • Page 6 11.6.2 Parts List........................111 11.7 O2 Inlet Assembly（DISS）..................111 11.7.1 Exploded View......................111 11.7.2 Parts List........................112 11.8 Blower Box Assembly....................112 11.8.1 Exploded View......................112 11.8.2 Parts List........................112 11.9 Insp. Valve Seat Assembly..................113 11.9.1 Exploded View......................113 11.9.2 Parts List........................113 11.10 Insp.

  • Page 7: Safety

    1 Safety Read this information before servicing the ventilator. This section covers general safety information only. Safety information that applies to a specific task is included in the procedure description for that task. 1.1 Safety Information 1.1.1 Definitions WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

  • Page 8: Caution

    service personnel may remove secured (held in place by screws or fasteners) covers. Failure to comply may result in electric shock. Do not place a container filled with liquid on the ventilator. Doing so may result in  electric shock due to liquid ingress inside the AC power connector. Regularly inspect the system power cord and plug.

  • Page 9: Note

    Do not attempt to sterilize or autoclave the ventilator.  To reduce the risk of electrical shock, disconnect AC power from the ventilator  before cleaning. To reduce the risk of fire, do not use a high-pressure oxygen hose that is worn or ...
  • Page 10 Symbol Definition European Authorized Representative. Dispose according to Council Directive 2012/19/EU or WEEE (Waste Electrical and Electronic Equipment). Indicates the degree of protection provided by enclosure according to IP21 IEC 60601-1. Type BF Applied part (classification of medical electrical equipment, type B, as specified by IEC 60601-1).
  • Page 11 Symbol Definition AC power indicator light. Battery LED...

  • Page 12: Theory Of Operation For Pneumatic

    2 Theory of Operation for Pneumatic 2.1 Pneumatic Circuit 2.1.1 Overview of the Pneumatic System The pneumatic system consists of three parts: inspiratory limb, patient tube, and expiratory limb. The inspiratory limb can be further divided into gas supply system, nebulizing subsystem, blower box subsystem, and inspiratory valve subsystem.
  • Page 13 pressure is 2.8-6bar Filters foreign substance in the high-pressure Filter O2 supply Dust filter Filters dust in the Air supply HEPA filter Filters bacteria and viruses in the Air supply Pfilter Pressure sensor Monitors vacuum at the Air inlet Self-closing cut-off valve Cuts off the connection between the pneumatic Reduces and stabilizes the pressure of Regulator high-pressure O2 supply to 2.5±0.4bar...

  • Page 14: Theory Of Operation Of The Pneumatic Subsystem

    2.1.3 Theory of Operation of the Pneumatic Subsystem According to structural composition and function, the pneumatic system of the ventilator can be broken down into 7 parts as shown below, which are gas supply subsystem, blower box subsystem, inspiratory fixture seat subsystem, inspiratory valve subsystem, nebulizing subsystem, patient tube and expiratory assembly.
  • Page 15 The connector of high-pressure O2 inlet is designed to be NIST/DISS as required by the standard to prevent misconnection. The connector of low-pressure O2 inlet is designed to be quick connector which is compatible with (CPC) PMC series and provides pneumatic cut-off function to prevent gas error between the high-pressure O2 and low-pressure O2 inside the ventilator.
  • Page 16 external structure and size of the nebulizing nozzle comply with BS EN 13544- 2_2002 standard. Nebulizing nozzle 2.1.3.3 Blower Box Subsystem The schematic diagram of the blower box subsystem is as shown below. The blower box subsystem mixes Air and O2 and delivers the mixed gas to the lower level assembly.

  • Page 17: Inspiratory Valve Subsystem

    The inspiratory fixture seat subsystem is located in the downstream of the blower box. As the inspiratory channel of the system, it is composed of fixture seat, Insp. hold valve, flow sensor and pressure release valve electromagnet. This module has four functions. First, it can actively release pressure to prevent the pressure of the pneumatic system from exceeding the preset pressure.
  • Page 18 The expiratory valve (EV) is an electronically controlled valve. The expiratory valve closing pressure is controlled by proportional valve. When the control current the system gives to the proportional valve is zero, the expiratory valve fully opens. When the system gives the proportional valve certain control current, the proportional valve seals the diaphragm to the valve port by control PEEP pressure.

  • Page 19: Pneumatic Connection

    2.1.4.2 Patient Tube Patient tube is the peripheral pneumatic circuit of the ventilator, independent of the ventilation main unit. It can be configured as needed. Patient tube connects the ventilator with the patient and humidifies the patient’s inhaled gas. There are disposable and reusable patient tubes. Generally, disposable tubes integrate tube, water trap, and Y piece, and are made of PP, PE or EVA material.
  • Page 20 0-2 Silicone tube 3.0x0.7 Variable diameter 18±1 11003-000006-00 connector 0-3 Silicone tube 4.0x2.0 Variable diameter 93±1 1004-000012-00 connector 0-4 Silicone tube 3.0x0.7 Variable diameter 37±1 11003-000006-00 connector 0-5 Silicone tube 4.0x2.0 Variable diameter 67±1 1004-000012-00 connector 0-6 Silicone tube 4.0x2.0 Y shape connector 22±1 1004-000012-00...

  • Page 21: Theory Of Operation For Electronic

    3 Theory of Operation for Electronic 3.1 System Schematic Diagram The block diagram of the hardware system is as shown below. The connection lines in the diagram indicate the connection between hardware boards and that between modules. The hardware system is divided into the following modules: power module, main board power management module, parameter module, main control module, protection module, extended module, display module and gas parameter module.

  • Page 22: Hardware Block Diagram

    5. Main control module: includes main core board and peripheral drive interface etc.; fulfills man-machine interaction of the ventilator, data interaction with other modules and subsystems; extends USB, network and HDMI interfaces. 6. Display module: includes includes LCD screen, touchscreen panel and driver board, alarm light board, encoder board and TP-key board;...

  • Page 23: Power Supply System

    3.3 Power Supply System 3.3.1 Power Supply System Block 3.3.2 Power Supplies Distribution Power supplies for hardware boards and their parts Parameter module +3.0V；+3.3V；+5V；+12V；+32V；-5V +3.3V；+5V； Protection module Main core board Extended module +3.3V；+5V；+12V； TP-key board +3.3V Alarm light board +3.6V Encoder board Touchscreen driver board +3.3V；+12V...

  • Page 24: Board Function

    Hall sensor Vacuum sensor board +3.3V Mainstream CO2 module Sidestream CO2 module 3.4 Board Function 3.4.1 Power Boards The power module includes AC-DC board, DC-DC board. Their functions are:  AC-DC board: transforms the external AC input power into DC power (nominal value is 24V ) to be used by the DC-DC board.
  • Page 25 3.4.1.2 DC-DC Board J7 connector of DC-DC board is DC input connector. It is defined as follows: Pin No. Signal name Signal description Remark DC-IN- Negative terminal of external DC input signal DC-IN- DC-IN+ Positive terminal of external DC input signal DC-IN+ J4 connector of DC-DC board is the connector with intelligent battery1.
  • Page 26 J3 connector of DC-DC board is the connector with cooling fan. It is defined as follows: Pin No. Signal name Signal description Remark +12V Power of the fan Fan pwm output Output signal of fan speed Input signal to control the fan Fan pwm in speed J2 connector of DC-DC board is the connector with switch button.

  • Page 27: Main Board

    3.4.2 Main Board The main board includes main board power management module, main control module, parameter module, protection module, extended module. It fulfills the most function of the ventilator. 3.4.2.1 Power Management Module The main board power management module provides the power supply for other parts of the main board.
  • Page 28 +20V or 16.8V) +V12 Power supply for cooling fan Ground Ground Ground Ground Ground Ground Ground AC_LED Control signal of AC indicator light Serial port signal of main core board USART1_TX transmitting to power board Control signal of battery indicator BAT_LED light Serial port signal of main core board...
  • Page 29 J66 is core board debug port. It is defined as follows: Pin No. Signal name Signal description Remark No internal connection No internal connection +V3.3_MAIN Power supply Ground Serial port signal of core board UART1_TXD transmitting to external PC Serial port signal of core board UART1_RXD receiving from external PC USB3 is external USB connector.
  • Page 30 No internal connection Clock line for Display Data Channel Data line for Display Data Channel / DDC_GND Display Data Channel Ground Power supply Hot Plug detect J10 is the connector between main board and display. It is defined as follows: Pin No.
  • Page 31 LVDS1 DIFFERENTIAL DATA LVDS1D0+ LINE0+ LVDS0 DIFFERENTIAL DATA LVDS0D3- LINE3- LVDS0 DIFFERENTIAL DATA LVDS0D3+ LINE3+ LVDS0 DIFFERENTIAL CLOCK LVDS0C- LINE- LVDS0 DIFFERENTIAL CLOCK LVDS0C+ LINE+ Ground Ground LVDS0 DIFFERENTIAL DATA LVDS0D2- LINE2- LVDS0 DIFFERENTIAL DATA LVDS0D2+ LINE2+ LVDS0 DIFFERENTIAL DATA LVDS0D1- LINE1- LVDS0 DIFFERENTIAL DATA...
  • Page 32 Serial port receiving signal of main MRXD1 core board Keyin reserved Ground No internal connection No internal connection +V5_COM 5V power supply Keyout Nurse call signal Parameter Module 3.4.2.3 The parameter module fulfills the ventilator parameter functions. It includes VPM module, inspiration module, expiration module, sensor monitor module, turbine driver circuit, NCV module and the vacuum sensor board.
  • Page 33 HALL3 Hall position signal H3 Ground Turbo blower drive signal C Turbo blower drive signal B NTC_IN Thermistor J50 is the connector for zero valve. It is defined as follows: Pin No. Signal name Signal description Remark Negative terminal of Rinse 3-way RINSE_Valve_N valve Positive terminal of Rinse 3-way...
  • Page 34 No connection Positive terminal of Insp. hold hold _Valve_P valve J45 is the connector between O2 flow sensor and parameter board. It is defined as follows: Pin No. Signal name Signal description Remark VF_O2 Flow signal of O2 TSI sensor Temperature signal of O2 TSI VT_O2 sensor...

  • Page 35: Display Module Boards

    J1 is the connector for vacuum sensor adapter board. It is defined as follows: Pin No. Signal name Signal description Remark Ground Ground Clock line of vacuum sensor I2C2_SCL I2C connector Data line of vacuum sensor I2C I2C2_SDA connector Vacuum sensor power supply, VDD3V3 3.3V 3.4.2.5 Protection Module...
  • Page 36 J3 is the connector between button control board and monitoring module main board. It is defined as follows: Pin No. Signal name Signal description Remark Control signal of AC indicator DC_LED light Control signal of battery AC_LED indicator light Serial port signal of indicator USART1_TXD board transmitting to main core board...
  • Page 37 J3 is the connector between encoder board and indicator board. It is defined as follows: Pin No. Signal name Signal description Remark ENCODE_A Encode signal A ENCODE_B Encode signal B ENCODE_S Encode signal S Ground J2 is the connector between touchscreen control board and indicator board. It is defined as follows: Pin No.

  • Page 38: Electrical Connection

    J1 is the connector between alarm light board and indicator board. It is defined as follows: Pin No. Signal name Signal description Remark +V3.3 3.3V power supply LED_B Control signal of blue light LED_G Control signal of green light LED_R Control signal of red light 3.4.3.4 Encoder Board Select and confirm touch buttons on the IHOPE ventilator display.

  • Page 39: Electrical Connection List

    “Bxx” indicates self-made board and “Sxx” indicates purchased material.  “#xx” indicates cable material.  拆下管 3 3.5.2 Electrical Connection List Description AC-DC board AC input connection line 05602-000002-00 AC-DC board to DC-DC board connection line 05602-000001-00 DC-DC board and main board connection line 05602-000007-00 DC-DC board and cooling fan connection line 05603-000002-00...
  • Page 40 Pressure release valve connection line 01701-000003-00 Autozero 2/3-way valve connection line 05603-000015-00 O2 flow sensor connection line 05603-000003-00 RV200 total flow sensor connection line 05603-000003-00 Speaker connection line 05603-000001-00 O2 concentration sensor connection line 05603-000009-00 Connection line integrated together with blower CO2 module connection line 05603-000026-00 vacuum sensor connection line...
  • Page 41 NOTE For cable material which contains the corresponding purchased component, P/N is the P/N of the cable material. AC-DC board AC input connection line “#1” is outsourced cable with material. Its  incoming material already contains material “S1”. blower connection line “#22is outsourced cable with material. Its incoming material ...

  • Page 42: Maintenance Menu

    4 Maintenance Menu A password is required to access different modes within the ventilator machine. Hospital password:1234  Factory password:1013  4.1 Hospital Setup This section introduces the functions mainly used by the hospital equipment maintenance personnel. It includes these functions: language, unit, gas supply, defaults settings, transfer settings, export, interface setting, system information.

  • Page 43: Export Patient Data

    3. Select [Export] to save the ventilator’s current settings and defaults to the USB memory. 4. Select [Import] to load the settings in the USB memory to the ventilator. 4.1.6 Export Patient Data This function is used for data export, which means to export patient demographics, current setting parameters, current alarm limits, and trend data of the ventilator in the format of “html”.

  • Page 44: System Information

    If no setting is made for [Alarm Level] or [Alarm Type], nurse call signals will not be triggered whatever alarm occurs。 WARNING Do not rely exclusively on the nurse call system for alarm notification. Remember  that the most reliable alarm notification combines audible and visual alarm indications with the patient’s clinical condition.
  • Page 45 Can be set to OFF, 15s, 30s, and 60s. When it is set to OFF, the menu will not hide automatically. When it is set to other options, Hide the Menu if no operation is performed for corresponding period of time, menu will disappear automatically.
  • Page 46 Power-on initialization items: restore to factory defaults each time after power-on; reserve the latest preset item values each time after accessing the menu when not powered off. Module Position Power-on initialization item Nebulizer Nebulizer Time P-V Tools Pstart P-V Tools Pmax P-V Tools Flow...

  • Page 47: Factory Calibration

    4.3.1.5 Software Version Information Select [Setup]→[Maintain]→enter the required password, you can view the version information of the software currently used by each module. 4.3.2 Factory Calibration The factory calibration menu provides access to the following: zeroing, flow calibration, pressure calibration, Exp. valve calibration, O2 calibration. For details, refer to 7Calibration.

  • Page 48: Software Upgrade

    5 Software Upgrade Warning If you remove the memory device before the files are successfully transferred,  you must reinitialize the USB port by powering the ventilator off and on again. CAUTION Software upgrade and configuration activation can be performed by authorzied ...

  • Page 49: Problems And Recommended Actions

    5.2 Problems and Recommended Actions Failure Possible cause Recommended solution description Insert the USB memory into the USB memory is not inserted. USB port of the Unable to find USB memory is faulty. ventilator. USB device The USB port of the Replace with a faultless USB ventilator is damaged.

  • Page 50: Preventive Maintenance

    6 Preventive Maintenance WARNING When it comes to test and maintain the equipment, make sure that the patient  is disconnected from the equipment. The equipment may have been used on patients carrying infectious diseases.  Before testing or maintaining the equipment, wear sterile rubber gloves to reduce the risk of being infected.

  • Page 51: Periodically-Maintained Parts

    （2）Replace the HEPA filter every 12 months as required. Remove the baffle of air inlet and the air inlet dust screen. Depress and grab the snap at the top of HEPA filter and pull it out horizontally. When installing, push in the HEPA filter to the right position and make sure it is installed in place.

  • Page 52: System Test

    worked for 20000 hours or when the system gives the alarm of “Blower Need Maintenance” or “Blower Failure”. 6.2 System Test After maintaining the ventilator at the client end, some routine tests are required to check if the current state of the ventilator is normal. The following table lists the routine tests. Test item Functional description Test interval...

  • Page 53: The Mechanical Ventilation Test

    test pressure sensor and under different pressures, the change pa t i e n t pressure of the readings on the inspiratory sensor. pressure sensor and patient pressure sensor are consistent with each other. The values measured between them shall not deviate by 10cmH2O. Test item description Requirements to pass the test...

  • Page 54: The Sensor Zero Point Test

    To check volume control ventilation, 1. Make sure that the supply pressure is normal and that the tubes in the breathing circuit are correctly connected as required for mechanical ventilation. Connect a 2 L test lung to the Y piece in the patient circuit. 2.

  • Page 55: The Accuracy Of Flow Sensor Test

    If the zero point value of the patient flow sensor or the zero point value of the  inspiratory flow sensor has an error, the baseline of the flow waveform is not at the zero point in ventilation status,. If the zero point value of any sensor is outside of the normal range, and if it can not ...

  • Page 56: The Accuracy Of Pressure Sensor Test

    6.2.5 the Accuracy of Pressure Sensor test NOTE If a great deviation of pressure measured value occurs, test the measurement  accuracy of pressure sensor so as to determine whether to perform pressure calibration again. This test can also validate the effectiveness of pressure calibration. ...

  • Page 57: Calibration

    7 Calibration NOTE Perform the corresponding calibration if any of the system tests described in 5.2  System Test is failed. After replacing the main board, valve, or sensors, perform the corresponding  calibration as described in this chapter. The ventilator provides the function of monitoring flow, pressure, volume, and inspiratory oxygen concentration etc.

  • Page 58: Patient Flow Calibration

    7.1 Patient Flow Calibration NOTE Factory flow calibration is necessary after replacing the main board.  Factory flow calibration is necessary when a great deviation (greater than 2L/min  and 10% of the measured value of calibration device) is detected between the measured value of patient flow sensor and that of the calibration device.

  • Page 59: Error Codes And Corrective Actions

    NOTE After flow calibration, check the measurement accuracy of the flow sensors as per  5.2.4 the Accuracy of Flow Sensor test. In case of calibration failure, first fix the problem and then perform calibration again.  7.1.2 Error Codes and Corrective Actions ErrorCode Cause Corrective Action...

  • Page 60: O2% Calibration

    Check if the sampling tubes are Patient flow sensor zero point twisted. If yes, untwist them. error If error 312 still persists, replace the main board. Check if there exits leakage. If yes, fix the leakage first. Check if patient type is correctly Patient flow sensor resolution selected.

  • Page 61: Error Codes And Corrective Actions

    3. Make sure the outlet of Insp valve and the air inlet of machine are not blocked. 4. Select [Start] to start factory O2% calibration.. 7.2.2 Error Codes and Corrective Actions Error Cause Corrective Action Code Connect or replace the O2 supply to make O2 supply failure sure that O2 supply pressure is normal.

  • Page 62: O2 Proportional Valve Calibration

    7.3 O2 Proportional Valve Calibration NOTE Calibrate O2 proportional valve when the valve or the main board is replaced.  Calibrate O2 proportional valve when a great deviation of O2 concentration  monitored value still occurs even though the O2 cell is replaced. 7.3.1 Calibration Procedures To perform factory O2 proportional valve calibration, 1.

  • Page 63: Pressure And Flow Zeroing

    7.4 Pressure and Flow Zeroing Zeroing is necessary when pressure or flow waveform deviates from the baseline. During the operation of the ventilator, pressure and flow are zeroed automatically at a specific interval. Pressure and flow can also be zeroed manually in the factory maintenance menu.
  • Page 64 Error of patient flow high- pressure end zeroing three-way valve status voltage. It is not in the range of ON. Error of patient flow high- pressure end zeroing three-way Reconnect the terminal and then valve status voltage. It is not in conduct zeroing.

  • Page 65: Pressure Calibration

    The zero point of PEEP pressure sensor is lower than the threshold of previous zero point. 7.5 Pressure Calibration NOTE Factory pressure calibration is necessary when the main board is new made and  never be calibrated. When a great deviation (deviation is larger than 0.4cmH2O and 4% of the monitored ...
  • Page 66 Connect VT Plus calibration line, as shown below. 4. Pneumatic connection. 5. Connect the calibration pneumatic circuit, as shown below. Connect the inspiratory port and expiratory port with hoses and occlude the Y piece end. Connect the airway pressure sampling line to LOW PRESSURE “+” pressure sampling port of VT Plus by using pneumatic connection fixture.
  • Page 67 6. Select [Start] on the ventilator screen to start calibration. Perform pressure calibration by using PF300: 1. Enter the pressure calibration screen. 2. Select [Setup] → [Maintain] , and enter the required password. Select [Sensor] →[Calibration] and then select [Pressure Calibration]. Select [PF300] as calibration device.

  • Page 68: Error Codes And Corrective Actions

    8. Select [Start] on the ventilator screen to start calibration. NOTE After pressure calibration, check the measurement accuracy of the pressure sensor  as per 5.2.5 the Accuracy of Pressure Sensor test. In case of calibration failure, troubleshoot the problem first and then perform ...
  • Page 69 conduct calibration. Three-way valve failure at the high- If step one does not work, replace pressure end of expiratory flow the valve and then conduct sensor calibration. Replace the main board. Check if there exits leakage. Check if the expiratory valve diaphragm is well assembled.

  • Page 70: Troubleshooting

    is well assembled. No torture is allowed. Check if the pressure charging line of peep proportional valve is PEEP pressure sensor resolution properly connected and not twisted. error Check if the pressure relief port of peep proportional valve is blocked. Check if the sampling line of peep pressure sensor is properly connected and not twisted.
  • Page 71 1）Make sure that O2 sensor is correctly 1) Insp branch or O2 connected and there is no O2 sensor related alarm branch test failed. on the screen. Re-do O2 sensor test. 2）The O2 sensor is no O2 sensor 3）Perform O2 sensor test after successful blower not connected or is test test, O2 branch test, and insp.

  • Page 72: Technical Alarms

    Y piece is not occluded or the tube is not connected. There are leakage with the ventilation hose. Occlude the end of Y piece and make sure that its Exp. valve and its two sampling tubes are connected to the machine. membrane are not well Make sure that the ventilation hose is not leaking.
  • Page 73 1.Check the patient. Patient tube is 2.Check the breathing circuit for a Disconnection disconnected. disconnection between the patient and the 1001 on patient The patient flow Flow Sensor, or for other large leaks. High side sensor is 3.Check the Accuracy of Patient Flow inaccurate.
  • Page 74 Check parameter settings, including Pressure pressure high alarm limit setting. Pressure reaches Check if there is pressure sensor failure 1009 Limit pressure high alarm. If yes, eliminate this alarm. Exceeded alarm limit- If the failure persists, replace the main 5cmH2O. board.
  • Page 75 Please check Perform zeroing. Patient flow 1018 patient flow Calibrate the Patient flow sensor. High sensor is faulty. sensor Replace the Patient flow sensor. Blower total running time Please exceeds the 1021 change the factory confirmed Replace the blower. blower maximum faultless running time.
  • Page 76 By the diagnostic tool, check the patient Technical patient pressure 1039 pressure sensor, if the value exceeds the High Fault (1039) sensor failure limit, replace the sensor. By the diagnostic tool, check the blower internal temperature and blower external Technical Blower temp.
  • Page 77 Technical 1058 Blower failure Replace the blower. High Fault (1058) 1. Check if the temperature of machine working environment exceeds the working temperature. Blower 2. Check if the fan air intake vent and air Technical 1059 temperature too exhaust vent are occluded. If yes, clear the High Fault (1059) high...
  • Page 78 1.The system is operable. Connect external power supply immediately. 2. Check if the battery can be normally charged. If it cannot be charged, replace The battery the DC-DC board. remaining 3. Perform battery conditioning once: fully 2004 Battery low capacity is lower Medium charged, completely discharged, and fully than the...
  • Page 79 Error (2020) failure Technical 2021 Battery 2 aging Replace battery 2. High Error (2021) Battery 2 Technical 2022 communication Replace battery 2. High Error (2022) error Technical 2023 Battery 2 failure Replace battery 2. High Error (2023) Technical 2054 Buzzer failure Check and replace the buzzer.

  • Page 80: Diagnostic Test

    1. Check if the extension module and core board are not in good contact. If yes, reinstall the core board. extension 2. Check if the extension module is Technical module damaged. If yes, replace the main board. 3008 High Fault (3008) communication 3.
  • Page 81  O2 proportional valve satus  PEEP valve status  Pressure release valve status 8.4.2.1 Sensor Zero Point Error By using the diagnostic tool, you can easily detect if the zero points of all the pressure and flow sensors of the ventilator are abnormal. To diagnose sensor zero-point error: 1.
  • Page 82 3. Increase the DA setting of the PEEP valve gradually. Check if the AD values of patient pressure sensor and inspiratory pressure sensor also increase.  If the AD value of one pressure sensor has very small change (less than 100AD), it is possible that the sampling line of the pressure sensor is not connected.

  • Page 83: Pneumatic System Failures

    1. Enter the diagnostic menu. Set blower pressure to 80cmH2O. 2. Set the status of pressure release valve to ON and you can hear a subtle click. 3. Set PEEP valve pressure to 50 cmH2O. Check the actual measured values of patient flow sensor and patient pressure sensor, both of which should near “0”...
  • Page 84 The output pressure setting of regulator is Re-set the regulator output The output pressure inaccurate. pressure. of regulator is not 8.5.3.1Regula The internal components Re-set the pressure by accurate. tor Output are aged and ineffective following the correct The output pressure Pressure Is (such as pressure drift method.

  • Page 85: Gas Supply Subsystem

    The electromagnet 8.6.5.2Pressu Leakage of insp. cannot be turned off. Replace the electromagnet. re Relief of valve seat exceeds The electromagnet Replace the insp. valve pressure the limit. diaphragm is aged and seat assembly. release valve damaged. is Failure The pressure 8.6.5.2Pressu release valve cannot The electromagnet of...
  • Page 86 To adjust the output pressure at the rear end of regulator, 1. Connect high pressure O2 connector to the O2 cylinder supply. Adjust supply gas pressure to 400±10KPa. 2. Connect gas flow analyzer VT-PLUS high-pressure port to the nebulizer connector via PU tube and quick connector.
  • Page 87 2. Control the nebulizer switch under the diagnostics mode. Connect the gas flow analyzer VT-PLUS at the nebulizer nozzle via PU tube to test if the nebulized gas flow is normal. If there is no nebulized gas flow available and the failure persists after replacing the nebulizer tube, next control the nebulizer switch under the diagnostics mode for multiple times (3 times recommended) to see if obvious click can be heard.

  • Page 88: Maximum Output Flow Is Small

    1. Troubleshoot by using the machine system check function. If O2 Branch Test fails, it is possible that the flow sensor is faulty. In this case, replace the O2 flow sensor. 2. Check if the filter net (11099-000001-00) at the front end of the flow sensor is normal. If not, replace it.

  • Page 89: Expiration Valve Assembly Leakage

    8.5.7 Expiration Valve Assembly Leakage If the exp. valve is leaky, troubleshoot as follows. 1. If clear leakage sound is heard, listen to find the leakage so as to confirm the faulty part. 2. Remove the exp. valve assembly. Perform visual inspection on the exp. valve diaphragm to see if the exp.

  • Page 90: Patient Flow Test Has An Error

    8.5.8 Patient Flow Test has an Error If patient flow test has an error, and there is no flow sampling data in the sampling limb or there is great deviation, troubleshoot as follows. 1. Observe if the flow sensor diaphragm is normal. If it is broken or damaged, replace the flow sensor.

  • Page 91: Hardware And Electrical System Failures

    2. By using the system check function, if the result of “O2 Sensor Test” is “Pass”, it indicates that the O2 sensor is not damaged. If the result is “Fail”, it indicates that the O2 sensor is damaged. Replace the O2 sensor. 8.6 Hardware and Electrical System Failures Failure Possible cause...
  • Page 92 The hardware failure causes the backlight brightness adjustment signals Screen unable to take effect. Replace the main board. brightness The main board hardware failure causes Check and make sure of cannot be the backlight brightness adjustment reliable cable connection. adjusted. signals unable to output normal signals.

  • Page 93: Repair And Disassembly

    9 Repair and Disassembly WARNING To help prevent fires, only use lubricants approved for ventilator or O2  equipment. Do not use lubricants that contain oil or grease. They burn or explode in high  O2 concentrations. Obey infection control and safety procedures. Used equipment may contain ...

  • Page 94: Disassemble The Service Parts

    9.2 Disassemble the Service Parts 9.2.1 Replace the Inspiratory Valve Component Gently press the lock unit above the valve, pull out the inspiratory valve component, and then install a new one. Press the lock unit 9.2.2 Replace the Expiratory Valve Component Turn the handwheel counterclockwise until the arrow aligns unlock icon，then take out the expiratory valve component.

  • Page 95: Replace The Air Inlet Dust Filter

    9.2.4 Replace the Air Inlet Dust Filter Open the turbine inlet cover, then remove the air inlet dust filter. Open the cover 9.2.5 Replace the Fan Dust Filter Open the fan inlet cover, then remove the fan dust filter Open the cover 9.2.6 Replace the HEPA Filter Open the turbine inlet cover, remove the air inlet dust filter first, then pinch the HEPA filter button and remove it.

  • Page 96: Replace The

    Open the cover Pinch the button 9.2.7 Replace the Back Cover Remove 6PCS Remove the 6PCS M3X8 combination screws, then remove the back shell. M3X8 combination screws 9.2.8 Replace the Battery For optional battery (battery 1): Just need to remove the battery cover from the bottom then could replace the battery.

  • Page 97: Replace The Top Cover Shell Component

    9.2.9 Replace the Top Cover Shell Component Remove the back cover as described in 9.2.7. Pull out the exhaust port. Turn the machine upside down and place the bottom side up on the desk. Remove the 4pcs M3X6 countersunk head screws. Remove 4pcs M3X6 countersunk head screws...

  • Page 98: Replace The Display Component

    9.2.10 Replace the Display Component The same as 9.2.9. 9.2.11 Replace the Core-Board PCBA Remove the back cover, the top cover shell as described in 9.2.7, 9.2.9. Remove 4 PCS M3X8 combination screws and take out the shield plate, then remove the heat transfer gasket above the core-board.
  • Page 99 Remove all cables Remove all cables on the main board(11pcs). Remove all cables Remove 9PCS M3X6 combination screws from the main board, then remove the main board and take down the turbine line, remove the button battery at last. Remove 9PCS M3X6 combination Turbine line...

  • Page 100: Replace The Mounting Plate

    9.2.13 Replace the Mounting Plate Remove the back cover, the top cover shell as described in 9.2.7, 9.2.9. Remove all tubes(5pcs) and all cables(11pcs) on the main board. Remove all cables Remove all tubes Remove the 5pcs M3X6 countersunk head screws, and take out the mounting plate. Remove 5pcs M3X6 countersunk head screws...

  • Page 101: Replace The Inspiratory Valve Seat Component

    Remove the tubes 9.2.15 Replace the Inspiratory Valve Seat Component Remove the front panel component as described in 9.2.14. Remove all the tubes from the inspiratory valve seat component, then remove 4pcs combination screws and take out the inspiratory valve seat component. Remove 4PCS M3X8 combination...

  • Page 102: Replace The O2 Inlet Component

    Disconnect the tube, then remove the turbine component. Note: If the space is too small, unscrew the front panel component first, but do not remove it, and the tubes on the front panel are no need to be removed. Remove 2PCS M3X8 combination screws...

  • Page 103: Replace The Gas Capacitor Component

    9.2.20 Replace the Gas Capacitor Component Remove the back cover, the top cover shell, the mounting plate, the front panel component, the 3-way valve component as described in 9.2.7, 9.2.9, 9.2.13, 9.2.14, 9.2.19. Remove 4pcs combination screws, then remove the gas capacitor component. Remove 4PCS M3X8 combination...

  • Page 104: Replace The Ac-Dc Power Module

    Remove 4PCS M3X6 combination screws Remove the cables 9.2.23 Replace the AC-DC Power Module Remove the back cover, the top cover shell, the mounting plate, the turbine component as described in 9.2.7, 9.2.9, 9.2.13, 9.2.17. Remove 3pcs combination screws and remove the AC-DC power module. Disconnect the cables on the power module.
  • Page 105 Disconnect the switch line and remove the nut, then remove the switch. Remove the nut...

  • Page 106: Performance Verification

    Performance Verification WARNING After servicing the equipment or replacing its components, complete all the tests in  this section. Before doing the tests in this section, completely reassemble the equipment and  refer to 5 Maintenance and Calibration to do necessary calibrations. 10.1 System Inspection NOTE Make sure that the breathing system is correctly connected and not damaged.

  • Page 107: System Test

    6. Disconnect the O pipeline supply. 7. As O pressure decreases, the high level alarm [O Supply Failure] is triggered. 10.4 System Test 1. Enter system check:  Enter system check screen after power-on. Connect O supply and block the flow sensor mounted on Y piece as prompted.

  • Page 108: High Pressure Test

    2. Turn on the ventilator. Select [New Adult] in standby mode. Set ventilation type to [Invasive]. 3. Set the ventilator controls as follows (in standard working state):  Ventilator mode: [VCV]  O2 concentration [O2%]: 40%  Tidal volume [VT]: 300 ml ...

  • Page 109: Patient Circuit Occluded Test

    10.7.7 Patient Circuit Occluded Test 4. Make sure a test lung is connected to the ventilator and start ventilation in PCV mode normally. 5. Nip the inspiration tube with the hands, make sure the monitoring value of VTi is lower 6.

  • Page 110: Apnea Alarm Test

    10.7.12 Apnea Alarm Test 1. After the ventilator system starts up normally, connect the ventilator to the test lungs to start ventilation. 2. Set apnea alarm time to 15s. 3. Set breathing frequency to 3bpm. Verify that the [Apnea] alarm is activated. 4.

  • Page 111: Electrical Safety Test

    automatically terminates the expiration hold function if the [Exp. Hold] key is pressed and held for continuous 30 seconds. 2. Release the [Exp. Hold] key, and make sure the ventilator enters inspiration phase. Enrichment ↑ Suction] 1. When the ventilator is in working state, select Adult mode and press the [O button.

  • Page 112: Test Form

    c. Verify the resistance is not larger than 0.1ohms (100 mohms). d. If the resistance is larger than 0.1ohms (100 mohms) but smaller than 0.2ohms (200 mohms), disconnect the AC power cord and plug the probe which is previously plugged into the protective earth terminal of AC power cord into the protective earth contact of the power outlet.

  • Page 113: Parts

    11 Parts 11.1 Host 11.1.1 Exploded View 11.1.2 Parts List Description 3600-000012-00 Creative host housing component(summer) 10001-000061-00 Fan cover / CV01-RV 10001-000044-00 Intake Cover-Silk / English / CV01-RV 10001-000060-00 Host Backshell / CV01-RV 60201-000002-00 Host kernel component / CV01-RV / General 60201-000019-00 Front Shell Component / CV01-RV 10001-000047-00...

  • Page 114: Parts List

    11.2.2 Parts List Description 3600-000014-00 Backscreen shell assembly-RV 3600-000015-00 Screen front shell assembly-RV 0501-000007-00 12.1 "Touch-screen 11.3 Display Front Housing Assembly 11.3.1 Exploded View 11.3.2 Parts List Description 10002-000034-00 LCD left mounting frame / CV01-RV...

  • Page 115: Kernel Assembly

    10002-000035-00 LCD right mounting frame / CV01-RV 05101-000002-00 LCD screen / 12.1 10001-000048-00 Display Front Shell / CV01-RV 05102-000002-00 Touch-screen / 12.1 inches 10001-000049-00 Encoder knob / CV01-RV 11.4 Kernel Assembly 11.4.1 Exploded View 11.4.2 Parts List Description 60201-000003-00 Oxygen gas source inlet component/Nist / CV01 10002-000073-00 Vapour plate / CV01-RV 60201-000014-00...

  • Page 116: Front Shell Assembly

    05502-000001-00 Lithium battery RRC2054-2 05901-000001-00 loudspeaker 60201-000017-00 Turbine Box Component / CV01-RV 10002-000030-00 Turbine Box Component Fixing Board / CV01-RV 10002-000031-00 Control Board PCBA Installation Board / CV01-RV 30101-000003-00 Control Board PCBA/CV01-RS 11.5 Front shell assembly 11.5.1 Exploded View 11.5.2 Parts List Description 10002-000033-00 Mainframe front baffle / CV01-RV...

  • Page 117: Parts List

    11.6.2 Parts List Description 10003-000019-00 O2 connector (NIST) 11002-000002-00 Seal, O ring 14X1.78 silicone black A50 11006-000001-00 Filter 11002-000001-00 Seal, O ring 10X1.5 silicone black A50 11001-000002-00 O2 proportional value with cable 11001-000005-00 Nebulizer value with cable 11001-000004-00 Main body of regulator 11099-000001-00 Filter net 01402-000001-00 SENSOR Flow Oxygen 300slpm 11.7 O2 Inlet Assembly（DISS）...

  • Page 118: Parts List

    11.7.2 Parts List Description 10003-000018-00 O2 connector (DISS) 11002-000002-00 Seal, O ring 14X1.78 silicone black A50 11006-000001-00 Filter 11002-000001-00 Seal, O ring 10X1.5 silicone black A50 11001-000002-00 O2 proportional value with cable 11001-000005-00 Nebulizer value with cable 11001-000004-00 Main body of regulator 11099-000001-00 Filter net 01402-000001-00 SENSOR Flow Oxygen 300slpm 11.8 Blower Box Assembly...

  • Page 119: Insp. Valve Seat Assembly

    11002-000007-00 O-RING.8.2X1.78 Silicone, black, A50 30101-000001-00 Negative pressure sensor PCBA 11.9 Insp. Valve Seat Assembly 11.9.1 Exploded View 11.9.2 Parts List Description 01701-000004-00 Insp. hold valve 10004-000010-00 Diaphragm of Insp. hold valve 10004-000009-00 Seal diaphragm 01701-000003-00 Electromagnet of pressure release valve 01402-000001-00 Insp.

  • Page 120: Exp. Valve Seat Assembly

    11002-000007-00 O-RING.8.2X1.78 Silicone, black, A50 10004-000016-00 Seal diaphragm of pressure release valve 11002-000006-00 O-RING.19X2 Silicone, black, A50 10004-000015-00 check valve 10102-000001-00 Spring of pressure release valve 10004-000017-00 Gasket of Insp. valve 10006-000019-00 Filter sponge 11002-000008-00 O-RING.28X2 Silicone, black, A50 10001-000013-00 Patient connector 11.11 Exp.

  • Page 121: Parts List

    11.12.2 Parts List Description 10004-000019-00 Membrane of Exp. valve 11002-000013-00 O-RING.40X2 Silicone, black, A50 10001-000074-00 Hand wheel of Exp. valve 11002-000008-00 O-RING.28X2 Silicone, black, A50 10001-000020-00 Patient connector 11.13 Rinse box Assembly 11.13.1 Exploded View 11.13.2 Parts List Description 11006-000003-00 Flow restrictor 10004-000022-00 Gasket...

  • Page 122: Parts List

    11.14.2 Parts List Description 30301-000003-00 Trolley handle assembly 60201-000028-00 Trolley gas cylinder fixed assembly 10007-000001-00 Trolley column 30301-000001-00 Trolley base assembly 10002-000043-00 Trolley humidifier fixed assembly 11.15 Trolley Handle Assembly 11.15.1 Exploded View 11.15.2 Parts List...

  • Page 123: Trolley Base Assembly

    Description 10001-000054-00 RV200 trolley front handle top cover 10001-000055-00 RV200 trolley front handle bottom cover 30301-000003-00 RV200 trolley support platform assembly 11.16 Trolley Base Assembly 11.16.1 Exploded View 11.16.2 Parts List Description 10001-000053-00 Trolley base cover 10103-000001-00 Caster.5" white, with brakes (FRU) 10103-000002-00 Caster.5"...

  • Page 124: A Preventive Maintenance Report

    A Preventive Maintenance Report Customer Name Service Company Service Date (YYYY/MM/DD) A.1 Check before Preventive Maintenance System Total Running Time S/N of Ventilator (hrs) Linux System System Software AB Module Software CB Module Software KB Module Software PB Module Software Software Version SB Module Software AB Module Boot...

  • Page 125: Test After Preventive Maintenance

    calibration O2 proportional valve Calibrate successfully. □Yes □No calibration Pressure calibration Calibrate successfully. □Yes □No Calibrate successfully and □Yes □No O2 % calibration record the AD value. (21% ______ 100% ______) Resistance calibration Calibrate successfully. □Yes □No (Single limb) A.3 Test after Preventive Maintenance System Check (Dual Limb) Items Result...
  • Page 126 PEEP 8 cmH2O PEEP □Pass □Fail Zero Point Accuracy Test (Chapter 6.2.3) Sensor Name Counts Actual Counts Range Result Insp. flow sensor -1~1LPM □Pass □Fail O2 flow sensor -1~1LPM □Pass □Fail Pat. flow sensor -1~1LPM □Pass □Fail Insp. press sensor -0.2~0.2cmH2O □Pass □Fail PEEP press sensor -0.2~0.2cmH2O □Pass □Fail...
  • Page 127 Current Single Fault(uA) <=1000 □Pass □Fail Remarks Engineer Signature： Date：...

  • Page 128: B Replacement Parts List

    B Replacement parts list Material Code Material Description Picture Inspiratory Valve 60201-000022-00 Component/RV Expiratory Valve 60201-000026-00 Component/RV 50199-000001-00 O2 Sensor 10006-000016-00 Air Inlet Dust Filter 10006-000017-00 Fan Dust Filter HEPA Filter 60201-000109-00 Component 10001-000060-00 Back cover...
  • Page 129 60201-000023-00 Display Component/RV Exhaust Cover 60201-000112-00 Component 60201-000113-00 Host Shell Component 10001-000045-00 Front panel 10001-000044-00 Air Inlet Cover 10001-000061-00 Fan Cover 10001-000047-00 O2 Sensor Cover 05502-000001-00 Lithium Battery...
  • Page 130 05001-000003-00 Core-Board PCBA 30101-0000013-00 Main Board PCBA/RV 60201-000088-00 Three-way Valve Gas Capacitor 60201-000014-00 Component 30101-000008-00 Power Board/RV Turbine 60201-000017-00 Component/RV Inspiratory Valve Seat 60201-000021-00 Component/RV 60201-000003-00 O2 Inlet Component...
  • Page 131 Expiratory Valve Seat 60201-000020-00 Component/RV 09901-000015-00 Speaker 05204-000001-00 AC-DC Power Module 60201-000110-00 Fan Component 60201-000111-00 Switch Component...

Table of Contents

Save PDF
