TECHNICAL MANUAL
CamCleaner Vertical System
CamCleaner Vertical System accommodates:
(1) Prefilter, (16) Cylinder Filters and (1) Final Filter
1
M38000165
Version 1.1
December 2018
www.camfil.us

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CamCleaner Vertical System and is the answer not in the manual?

Questions and answers

Summary of Contents for Camfil CamCleaner Vertical System

  • Page 1 TECHNICAL MANUAL CamCleaner Vertical System CamCleaner Vertical System accommodates: (1) Prefilter, (16) Cylinder Filters and (1) Final Filter M38000165 Version 1.1 December 2018 www.camfil.us...
  • Page 2: Table Of Contents

    TECHNICAL MANUAL CamCleaner Vertical System Index INDEX.……………………………………………………………………………………………………………………………………..2 READ BEFORE STARTING..…………..………………………………………………………………………………………………3 SYSTEM IMAGE…..……………………..………………………………………………………………………………………………4 SYSTEM INSTALLATION……..………………………………………………………………………………………………………..5 MODULE CONNECTIONS……………………………………………….…………………………………………………..5 POWER INLET LOCATION..…………………………………………….…………………………………………………..6 LOUVER OPERATION…..……………………………………………….…………………………………………………..7 MOTOR MODULE ACCESS.…………………………………………….…………………………………………………..8 AIRFLOW CONTROLLER….…………………………………………….…………………………………………………..9 DIFFERENTIAL PRESSURE GAGE…………………………………….…………………………………………………..9 FILTER INSTALLATION..…….………………………………...……………………………………………………………………..10 PREFILTER INSTALLATION.…………………………………………...………………………………………………….10 CYLINDER FILTER INSTALLATION………………………………….……………………………………………………11 FINAL FILTER INSTALLATION………………………………...……….…………………………………………………..12 FEATURES..……...…………………………………………………………………………………………………………………..13 PERIODIC MAINTENANCE INSPECTIONS….……………………………………………………………………………………..14...
  • Page 3: Read Before Starting

    READ BEFORE STARTING Read the instructions before starting! The Camfil CamCleaner is a free-standing, mobile air cleaner designed for molecular and particulate contaminant control applications in heavy process industries. Typical applications include areas that may have corrosive gases and contain sensitive computer or electronic equipment, pulp and paper mills, photochemical facilities, steel mills, refineries or sewage treatment plants.
  • Page 4: System Image

    TECHNICAL MANUAL CamCleaner Vertical System SYSTEM IMAGE OUTLET LOUVER (1-PLC) AIRFLOW CONTROLLER MINIHELIC II 2-5001 P GAGES BLOWER MODULE WITH ACCESS PANEL CYLINDER FINAL FILTER MODULE WITH HINGED ACCESS DOOR INLET PREFILTER MODULE WITH HINGED ACCESS DOOR INLET LOUVERS (3-PLCS) M38000165 Version 1.1...
  • Page 5: System Installation

    TECHNICAL MANUAL CamCleaner Vertical System SYSTEM INSTALLATION Upon receiving your CamCleaner, carefully unbox the equipment and stand upright, taking extra precaution not to damage the casters on the bottom. The CamCleaner arrives fully assembled and ready to use after installing the filters and connecting the power cable to the correct power source.
  • Page 6: Power Inlet Location

    TECHNICAL MANUAL CamCleaner Vertical System POWER INLET LOCATION The power inlet supply is located on the back of the CamCleaner. The power supply is equipped with an ON / OFF switch and a fuse block that contains a 6.3 amp slow blow (time delay) fuse. The fuse block is located under the middle cover on the power supply inlet.
  • Page 7: Louver Operation

    TECHNICAL MANUAL CamCleaner Vertical System INLET LOUVER OPERATION The supplied inlet louvers are fixed. The louvers come equipped with an internal damper. A small flat-blade screw driver can be inserted into the mechanism slot and rotated a quarter turn to open or close the damper.
  • Page 8: Motor Module Access

    TECHNICAL MANUAL CamCleaner Vertical System MOTOR MODULE ACCESS 1 - Locate Motor Module Access Panel 2 - Loosen Panel Stops with 4mm Hex Key 4 – Have an assistant grab both handles and pull the 3 - Rotate Panel Stops to Open Position access panel out approximately 6-inches.
  • Page 9: Airflow Controller

    TECHNICAL MANUAL CamCleaner Vertical System Current Reading AIRFLOW CONTROLLER The airflow controller is located on the blower module access panel and displays the current airflow as well as the airflow set point. No modifications to the airflow controller are required once you receive the CamCleaner. The current airflow reading will display “RED”...
  • Page 10: Differential Pressure Gage

    TECHNICAL MANUAL CamCleaner Vertical System DIFFERENTIAL PRESSURE GAGE A total of two (2) minihelic differential pressure gages are installed to measure pressure drop across the prefilter and final filter. The differential pressure gages have a range of 0 to 1” w.g.. Please use the differential pressure gages to provide a visual indication of when the pre-filter and post filter require change-out.
  • Page 11: Cylinder Filter Installation

    TECHNICAL MANUAL CamCleaner Vertical System CYLINDER FILTER INSTALLATION Cylinder Filter Installation (e.g. CamCarb CG) 6. Ensure system is powered OFF. 7. Located the Cylinder Final Filter Module and open access door using the handles. 8. Locate the cylinder holding frame mounted in the bottom of the cylinder module.
  • Page 12: Final Filter Installation

    TECHNICAL MANUAL CamCleaner Vertical System FINAL FILTER INSTALLATION Note: Only use nominal 4” depth frame final filter. 1. Ensure system is powered OFF. 2. Located the Cylinder Final Filter Module and open access door using the handles. 3. Locate 4” wide extrusion track towards the top downstream of the cylinders;...
  • Page 13: Features

    TECHNICAL MANUAL CamCleaner Vertical System FEATURES EC MOTORIZED IMPELLER FANS Fan is a backward curved impeller fan with an EC motor. EC motor offers low power consumption, quiet operation and easy servicing. FAN SAFETY SHUT OFF When the system is operating, and the blower module access door is opened, the fan motor will automatically power OFF as a built-in safety function.
  • Page 14: Periodic Maintenance Inspections

    The system should be periodically inspected, and routine maintenance checks and/or other planned surveillance should be conducted. When placing an order for replacement filters, provide Camfil with the serial number, part number and housing model number. The information can be found on the equipment label located on the back of the system.
  • Page 15: Warranty

    Camfil USA's published specifications and submittal drawings included in the scope of the purchase agreement. The term of this warranty shall be one (1) year from date of shipment from Camfil USA's manufacturing facility. There are no other warranties that extend beyond this description.
  • Page 16 Belgium • France • Germany • Ireland • Malaysia • Sweden • Switzerland • United Kingdom Camfil USA, Inc. United States Tel: (973) 616-7300 Fax: (973) 616-7771 Camfil has a policy of continuous research, development and product improvement. We reserve the right to change designs Canada Tel: (450) 629-3030 Fax: (450) 662-6035 and specifications without notice.
