PDWA6963-SS Stainless Steel Pipe Mounting Kit
Instruction Manual
Vertical Pipe Mounting
KEY FEATURES
•
Mounts PDW Wireless Field Units to 1.5" or 2" Pipes
•
Suitable for Horizontal or Vertical Pipes
•
All Necessary Hardware Provided
•
316 Stainless Steel
OVERVIEW
The PDWA6963-SS provides a convenient way to mount
PDW30, PDWR, and PDW90 wireless field units to
horizontal or vertical 1.5" or 2" pipes such that the antenna
is not right on top of the metal pipe.
The components in the mounting kit are made from 316
stainless steel and all necessary hardware is provided to
mount one PDW unit on a vertical pipe. To mount one PDW
unit on a horizontal pipe, two kits are required.
PRECISION DIGITAL CORPORATION
Horizontal Pipe Mounting
CONTENTS
•
All hardware is stainless steel
•
One mounting plate
•
Two (each) bolts, washers, lock washers & nuts
to mount instrument to plate
•
One U-bolt and two (each) washers, lock washers
& nuts to mount plate to pipe
www.predig.com
