Integrated Washer Dryer
MIWD75
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
Installation and Operating Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIWD75 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for montpellier MIWD75

Summary of Contents for montpellier MIWD75

  • Page 1 LAUNDRY - DISHWASHING - COOKING - COOLING Installation and Operating Instructions Integrated Washer Dryer MIWD75 Please read these instructions carefully before attempting to install or use this appliance. We recommend that you keep these instructions in a safe place for future reference.
  • Page 2 Welcome Thank you for choosing this Montpellier Integrated Washer Dryer Our Integrated Washer Dryer has been designed to provide you with the best combination of style, reliability and performance to give you years of trouble-free use. You may be familiar with a similar product, but please take time to read these instructions carefully before installing or using your Integrated Washer Dryer to ensure you get the most from your purchase.

  • Page 3: Table Of Contents

    Carefully read this manual for correct and Contents safe appliance use and for helpful tips on efficient maintenance. 1. GENERAL SAFETY RULES 2. INSTALLATION Only use the washing machine 3. DETERGENT DRAWER after carefully reading these instructions. 4. PRACTICAL HINTS We recommend you always keep this manual on hand and in good condition for 5.

  • Page 4: General Safety Rules

    1. GENERAL SAFETY Children shall not play with the RULES appliance. Cleaning and user l This appliance is intended maintenance shall not be and designed for domestic made by children without household use only. supervision. - Any different use of this l...
  • Page 5 l Items such as foam rubber WARNING: (latex foam), shower caps, never stop a washer dryer before waterproof textiles, rubber the end of the drying cycle backed articles and clothes or unless all items are quickly pillows fitted with foam rubber removed and spread out so that pads should not be dried in the the heat is dissipated.
  • Page 6 l To consult the product technical l Do not pull on the power cord specification please refer to the or appliance to unplug the manufacturer website. machine. l Make sure there is no water in Electrical connections the drum before opening the safety instructions door.

  • Page 7: Installation

    2. INSTALLATION l Remove the 2 or 4 transportation screws (A) on the back and remove the 2 or 4 flat washers, rubber bungs and plastic spacer tubes (B) as illustrated in figure 1. l If the washing machine is built-in, unscrew the 3 or 4 transportation screws (A) and remove the 3 or 4 flat washers, rubber bungs and...
  • Page 8 Instructions for mounting the furniture door Position the template onto the reverse of the furniture door. It is possible to mount the hin g es and closure ma g net on the ri ght or left-hand side dependin g on your requirements.
  • Page 9 l Mount the furniture door to the front of the washer using the hinges. Fix the spacers (I) in place with the 2 screws (J) and then fix the hinges with 2 screw (H). We suggest mounting the furniture door so that it opens towards the left, which is the same direction as the porthole door.
  • Page 10 Hydraulic connections l Connect the water hose to the water supply tap (fig. 3) only using the hose supplied with the appliance (do reuse old hose-sets). l SOME MODELS may include one or more of the following features: l HOT&COLD (fig. 4): water mains connection settings with hot and cold water for higher energy savings.
  • Page 11 Setting l The washing machine should be installed in its final position such that the water fill hose is not kinked or trapped. The corrugated drain hose should be inserted into suitable drain pipe of between 50 cm and 85 cm height above the floor using the curved drain hose support.

  • Page 12: Detergent Drawer

    3. DETERGENT DRAWER detergent draw split into compartments as illustrated in figure 9: l compartment "1": for prewash detergent; l compartment “ ” : for special additives, softeners, starch fragrances, etc.; WARNING: only use liquid products; the washing machine is set to automatically dose additives at each cycle during the last rinse.

  • Page 13: Practical Hints

    Maximise the load size 4. PRACTICAL HINTS l Achieve the best use of energy, water, Load tips detergent time using recommended maximum load size. When sorting laundry, make sure: Save up to 50% energy by washing a full load instead of 2 half loads. - have eliminated metallic objects such as hair clips, pins, coins, from laundry;...
  • Page 14 The use of ecological detergents without When washing heavily soiled whites, phosphates cause following we recommend using cotton programs of effects: 60°C or above and a normal washing powder (heavy duty) that contains - cloudier rinse drain water: This effect is bleaching agents that at medium/high tied to the suspended zeolites which do temperatures provide excellent results.

  • Page 15: Cleaning And Maintenance

    l 5. CLEANING AND Remove and clean the filter; when finished, replace it turning it clockwise. MAINTENANCE The filter handle will be locked when it is not possible to turn any further and the Looking after your appliance correctly can handle is horizontal.

  • Page 16: Quick User Guide

    6. QUICK USER GUIDE 7. CONTROLS AND PROGRAMS This washing machine automatically adjusts the level of the water to the type and quantity of washing. This system gives a reduction in energy consumption and a saving in washing times. Program selection l...
  • Page 17 l Press to start the selected cycle . Opening the door When the START/PAUSE button has A special safety device prevents the been pressed, the appliance can take door from being opened immediately few seconds before it starts working. after the end of the cycle. Wait for 2 minutes after the wash cycle has finished and the "Door PAUSING THE MACHINE...
  • Page 18 time the button is pressed, until h24 If you exceed the maximum dryable appears on the display, at which point load of laundry indicated in the pressing the button again will reset the programme table, the laundry may not delay start to zero. be dried satisfactory.
  • Page 19 RAPID / STAIN LEVEL button To prevent damage to the fabrics, it is not possible to increase the speed This button allows you to choose between over the maximum allowed for the two different options, depending on the programme. selected programme. l...
  • Page 20 3) DOOR LOCKED INDICATOR LIGHT Digital Display l The indicator light is illuminated when the door is fully closed. The display’s indicator system allows you to be constantly informed about the status of the machine. Close the door BEFORE selecting the START/PAUSE button.
  • Page 21 - adjusts the rhythm of drum rotation for 6) WASH TEMPERATURE INDICATOR the type of fabric being washed; LIGHTS This shows the washing temperature of the - recognises the presence of too much selected programme that can be changed soap suds, and if necessary, adjust the (where allowed) by the relevant button.
  • Page 22 Table of programmes (MAX.) PROGRAMME (see control panel) (MAX.) Whites 90° Cotton + Prewash 60° ECO 40-60 60° Wash and Dry (ECO 40-60 + 20°C 20° Mixed 60° Delicates 40° Rinse Spin Drain 30° Rapid 30° 14-30-44 Min. 40° Shirts 30°...
  • Page 23 Please read these notes: INFORMATION FOR THE TEST Maximum load capacity of dry clothes, LABORATORIES according to the model used (see control panel). STANDARD PROGRAMMES ACCORDING TO Directive 96/60/CE When a programme is selected, on the display is shown the WASHING: display shows the recommended ECO 40 - 60...
  • Page 24 Mixed Programmes selection The washing and rinsing optimise the speed and rhythm of the drum action and water To clean different types of fabrics and levels. The gentle spin, ensures a reduced various levels of dirt, the washing machine formation of creases in the fabric. has specific programs to meet every need of washing (see table of programmes).
  • Page 25 DRYING Cool air is used during the last 10/20 minutes of the drying cycle to minimize creasing. WARNING: Dispensers used concentrated Synthetics Dry powders and liquid detergents must be temperature drying programme removed from drum before recommended for synthetics and mixed commencing tumble drying...

  • Page 26: Drying Cycle

    8. DRYING CYCLE The correct way to dry l Drying guidance advice is general, but l Open the door. practical experience of using the product will help you to achieve the best drying l Fill with the laundry, not exceeding the results.
  • Page 27 l l The washer dryer will calculate the time Open the door and remove the laundry. needed for drying and the level of moisture remaining laundry, l Turn off the tap. according to the load and drying type selected. CANCELLING THE DRYING PROGRAMME l...

  • Page 28: Automatic Washing/Drying Cycle

    l 9. AUTOMATIC When the programme is finished the word "End" will appear on the display. After 5 WASHING/DRYING minutes the appliance will go into CYCLE standby mode (on certain models, the display will show two lines). You cannot exceed the maximum l...

  • Page 29: Troubleshooting And Warranty

    10. TROUBLESHOOTING AND WARRANTY If you believe the washing machine is not working correctly, consult the quick guide provided below which includes some practical tips on how to fix the most common problems. ERROR CODE FORMAT l Models with a display: the error is shown by a number preceded by the letter “E” (example: E2 = Error 2).
  • Page 30 OTHER ANOMALIES Problem Possible causes and practical solutions Make sure the product is plugged into a working supply socket. The washing machine Make sure power is on. does not work / start Make sure the wall socket is working, testing it with another appliance such as a lamp.
  • Page 31 It is always recommended to use original By placing the mark on this spare parts, that are available at our product, we are confirming compliance Authorised Customer Service Centres. to all relevant European safety, health and environmental requirements which are applicable in legislation for this Warranty product.
  • Page 32 MIWD75 Model identifier: General product parameters: Parameter Value Parameter Value Rated capacity (kg) Rated Dimensions in cm Height capacity Rated Width washing Depth capacity Energy Efficiency 80,0 Energy efficiency class Index 82,0 Washing efficiency 1,031 Rinsing effectiveness ( g/ kg dry...
  • Page 33 Maximum Rated Maximum temperature inside Rated temperature inside washing the treated textile (°C) for the capacity the treated textile capacity washing cycle of the household (°C) for the washing washer-dryer, using the wash Half cycle and dry cycle. Quarter Half household washer- dryer, using the eco 40-60 programme...
  • Page 34 Your 2 year Manufacturer’s guarantee THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS. Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the first 24 months from date of purchase provided that: Any claim is accompanied by evidence of the model reference, model serial number and proof of purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24 months prior to the date of claim.
  • Page 35 Montpellier Domestic Appliances Ltd. Unit 1, Tewkesbury Retail Park, Northway Lane, Tewkesbury, Gloucestershire GL20 8JU www.montpellier-appliances.com The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
