CALIBRATION PROCEDURE
NI 9201/9221
Français
This document contains the verification and adjustment procedures for the National
Instruments 9201 and National Instruments 9221. In this document, the NI 9201 and the NI 9221
are referred to inclusively as the NI 9201/9221. For more information about calibration
solutions, visit
ni.com/calibration
Contents
Software.................................................................................................................................... 1
Documentation.......................................................................................................................... 2
Test Equipment......................................................................................................................... 3
Test Conditions......................................................................................................................... 3
Initial Setup............................................................................................................................... 4
Verification ............................................................................................................................... 4
Accuracy Verification....................................................................................................... 4
Adjustment................................................................................................................................ 6
Accuracy Adjustment ....................................................................................................... 6
EEPROM Update ..................................................................................................................... 7
Re-Verification ......................................................................................................................... 7
Accuracy Under Calibration Conditions .................................................................................. 7
Where to Go for Support .......................................................................................................... 8

Software

Calibrating the NI 9201/9221 requires the installation of NI-DAQmx 9.2 or later on the
calibration system. You can download NI-DAQmx from ni.com/downloads. NI-DAQmx
supports LabVIEW, LabWindows
install NI-DAQmx, you only need to install support for the application software that you intend
to use.
Deutsch
ni.com/manuals
.
™
™
/CVI
, C/C++, C#, and Visual Basic .NET. When you
