Bauer 201522E-B Owner's Manual & Safety Instructions

8" bench grinder with led light
Hide thumbs

Advertisement

Table of Contents

Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
8" BENCH GRINDER
WITH LED LIGHT
email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2024 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
201522E-B
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
24f
57287

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 201522E-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bauer 201522E-B

Summary of Contents for Bauer 201522E-B

  • Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. 201522E-B 8" BENCH GRINDER WITH LED LIGHT Visit our website at: http://www.harborfreight.com...

  • Page 2: Table Of Contents

    table of contents Safety ............2 Maintenance ..........12 Specifications ..........6 Parts List and Diagram ......14 Setup ............6 Warranty ............ 16 Operation ............ 8 WarninG SyMBOLS anD DeFinitiOnS This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 3 13. DON’T OVERREACH. table a: recOMMenDeD MiniMuM Wire GauGe Keep proper footing and balance at all times. FOr eXtenSiOn cOrDS (120 VOLt) 14. MAINTAIN TOOLS WITH CARE. Keep eXtenSiOn cOrD tools sharp and clean for best and safest naMepLate performance. Follow instructions for LenGtH aMpereS lubricating and changing accessories.
  • Page 4 Grounding instructions tO preVent eLectric SHOcK anD DeatH FrOM incOrrect GrOunDinG Wire cOnnectiOn reaD anD FOLLOW tHeSe inStructiOnS: 110-120 Vac Grounded tools: tools with three prong plugs 1. In the event of a malfunction or breakdown, 6. Repair or replace damaged or grounding provides a path of least resistance for worn cord immediately.
  • Page 5 Grinder tool Safety Warnings For your Own Safety read instruction 15. Only use safety equipment that has been approved Manual Before Operating tool Grinder by an appropriate standards agency. Unapproved safety equipment may not provide adequate 1. Wear eye protection. protection.

  • Page 6: Specifications

    Specifications Electrical Rating 120VAC / 60Hz / 4.8A Motor No Load Speed 3,600 RPM Max. Accessory Diameter 8″ Arbor Size 5/8″ Setup - Before use: read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn: turn the power Switch of the tool off and unplug the tool from its electrical outlet before performing any procedure in this section.
  • Page 7 Functions Lamp Shield Wheel cover Spark Guard Grinding Wheel Work rest Work rest Support inner Wheel power Switch Guard 57287 For technical questions, please call 1-888-866-5797. Page 7...

  • Page 8: Operation

    Operating instructions read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. tool Set up tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn: turn the power Switch of the tool off and unplug the tool from its electrical outlet before performing any procedure in this section.
  • Page 9 11. Place the Grinding Wheel with the WarninG: to prevent serious injury, do Outer Flange onto the Arbor. not overtighten nut. Overtightening can 12. Thread the Nut onto the Arbor. Wrench damage the wheel, causing wheel failure. tighten only enough so that the Wheel is securely held on the Arbor.
  • Page 10 Workpiece and Work area Set up 1. Designate a work area that is clean and well lit. 3. There must not be objects, such as utility lines, The work area must not allow access by children nearby that will present a hazard while working. or pets to prevent distraction and injury.
  • Page 11 General Operating instructions 1. Make sure that the Switch is in the 5. Turn the Power Switch on . off-position, then plug in the tool. 6. Allow the tool to come up to full speed 2. Adjust the spark arrestor and the work before touching the wheel.

  • Page 12: Maintenance

    Maintenance and Servicing procedures not specifically explained in this manual must be performed only by a qualified technician. tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn: turn the power Switch of the tool off and unplug the tool from its electrical outlet before performing any procedure in this section.
  • Page 13 troubleshooting problem possible causes Likely Solutions Tool will not start. 1. Cord not connected. 1. Check that cord is plugged in. 2. No power at outlet. 2. Check power at outlet. If outlet is unpowered, turn off tool and check circuit breaker. If breaker is tripped, make sure circuit is right capacity for tool and circuit has no other loads.

  • Page 14: Parts List And Diagram

    parts List and Diagram pLeaSe reaD tHe FOLLOWinG careFuLLy THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
  • Page 15 assembly Diagram 57287 For technical questions, please call 1-888-866-5797. Page 15...

  • Page 16: Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
