3.Product Parameters

HS-02A
Product name
Working voltage
9-20V
Temperature range
100-450℃ （180-842℉）
Screen
0.96 IPS HD color screen
Weight
≈61g
※HS-02A and HS-02B have the same shell, but the internal motherboard and soldering iron tips are different , cannot be compatible or
interchangeable for use.

4.Power Selection

Using the PD fast charging protocol power adapter, the soldering iron can be set to obtain the working voltage of any level
of 9V, 12V, 15, or 20V from the adapter (default setting of 20V), if there is a restart phenomenon, you can enter the adaptive
power adjustment page, or manually enter the settings to reduce voltage or power.
Attention:
●The default working voltage obtained by the intelligent soldering iron is 20V. If the maximum output voltage of your
adapter is less than 20V, then will obtain the highest output voltage. If your adapter has a maximum output of 12V, then
obtain 12V.
HS-02B
Power supply
Fast charging protocol
Power
soldering iron tip
26
Type-C
PD/QC
100W(max)
HS02A-XX HS02B-XX
