Basic Settings - Fnirsi HS-02A User Manual

6.Operating Instructions

6.1 Basic Settings

●Power on: Power on, the screen
displays the boot logo, and then
automatically jump to the standby
interface. If prompted to insert the
soldering iron tip page, the interface will
automatically jump to the standby page
after inserting the soldering iron tip.
●Adaptive power mode: To enter this mode, you need to long press the right button to power on until the boot logo
appears and press the OK button to start, in this mode, no other operations can be performed, and the power will
increase by 1% until the device restarts.
Notice: Accurate temperature control is not possible in this mode, please do not touch the soldering iron head during
this period!
Boot logo
insert the soldering iron tip page
30
standby page
