Gigabyte 7ZMMP-TU User Manual
Gigabyte 7ZMMP-TU User Manual

Gigabyte 7ZMMP-TU User Manual

Amd athlon agp motherboard

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854- 9338/ (818) 854-9339
hereby declare s that the product
Product Name:
Mother Board
Model Number:
GA - 7ZMMP
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
E r i c L u
Signature:
Date:
Sep. 22, 2000
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
This
equipment
and
can
radiate
radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7ZMMP-TU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gigabyte 7ZMMP-TU

  • Page 1 FCC Compliance Statement: This equipment has been tested and found to DECLARATION OF CONFORMITY Per FCC Part 2 Section 2. 1077(a) comply with limits for a Class B digital device , pursuant to Part 15 of the FCC rules. These Responsible Party Name: G.B.T.
  • Page 2 Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-7ZMMP is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive EN 55011...
  • Page 3 7ZMMP-TU Athlon AGP Motherboard USER'S MANUAL Athlon Socket A Processor Motherboard REV. 0.2 First Edition R-02-01-000904...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: Manual revision information 1) Revision History Product item list 2) Item Checklist Product information & specification 3) Features Instructions on setting up the motherboard 4) Hardware Setup Product performance &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 7ZMMP-TU Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition Performance List P.22 Block Diagram P.23 Suspend to RAM Installation P.24 Four Speaker & SPDIF Introduction P.30...
  • Page 8: Revision History

    Revision History Revision Revision Note Date Initial release of the 7ZMMP-TU motherboard user’s Sep. 2000 manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein.
  • Page 9: Item Checklist

    Item Checklist Item Checklist þThe 7ZMMP-TU motherboard þCable for IDE / floppy device þDiskettes or CD (TUCD) for motherboard driver & utility þ7ZMMP-TU user’s manual...
  • Page 10: Summary Of Features

    7ZMMP-TU Motherboard Summary Of Features Form Factor 24.4 cm x 22.7 cm Micro ATX size form factor, 4 layers Ÿ AMD Athlon/Duron (K7) Socket A Processor Ÿ 256K/64K 2 cache on die Ÿ Supports 500MHz ~ 1GHz and faster Ÿ...
  • Page 11 Summary of Features PS/2 Connector ® ® PS/2 Keyboard interface and PS/2 Mouse interface Ÿ On-Board VGA NVIDIA TNT2 M64 Ÿ On-Board Sound Creative CT5880 sound Ÿ Line In/Line Out/Mic In/AUX In/CD In/TEL/Game Port Ÿ /Four Speaker & SPDIF BIOS Licensed AMI BIOS, 2M bit flash ROM Ÿ...
  • Page 12: 7Zmmp-Tu Motherboard Layout

    7ZMMP-TU Motherboard 7ZMMP-TU Motherboard Layout PS/2 Socket A CPU VT8363 JP13 7ZMMP-TU Creative CT5880 TNT2 BAT1 PCI1 PCI2 VT82C BIOS 686A JP12 PCI3 USB2 JP11 COM B...
  • Page 13 7ZMMP-TU Motherboard Layout Page Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors Game & Audio Port COM A / COM B / VGA / LPT Port USB 1 Connector USB 2 Connector PS/2 Keyboard & PS/2 Mouse Connector P.10...
  • Page 14: Cpu Speed Setup

    7ZMMP-TU Motherboard CPU Speed Setup The system bus speed is selectable at 100~133MHz. The user can select the system bus speed by DIP switch S W 1. Set System Bus Speed SW1 (Optional): O : ON, X : OFF é...
  • Page 15: Connectors

    Connectors Connectors Game & Audio Port Game Port Line Out1 Line In/Line Out2 Line Out 1: Line Out or SPDIF (The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder). In general, Line Out 1 is normally Line Out, when SPDIF connector is inserted, it will be change to SPDIF Out automatically (see page 32 for more information).
  • Page 16: Usb 1 Connector

    7ZMMP-TU Motherboard USB 1 Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 5 6 7 8 USB D1- USB D1+ USB 2 Connector Pin No. Definition USB D2- USB D2+ USB D3+ USB D3-...
  • Page 17: Definition

    Connectors PS/2 Keyboard & PS/2 Mouse Connector PS/2 PS/2 Mouse Mouse/Keyboard Pin No. Definition Data VCC(+5V) Clock PS/2 Keyboard J3: CPU Fan Pin No. Definition Control +12V SENSE...
  • Page 18: Jp6: Power Fan

    7ZMMP-TU Motherboard JP6: Power Fan Pin No. Definition Control +12V J2: System Fan Pin No. Definition Control +12V SENSE...
  • Page 19: Atx Power

    Connectors ATX Power Pin No. Definition 3,5,7,13, 15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off) Floppy Port Red Line FDD1...
  • Page 20: Ide1 (Primary), Ide2 (Secondary) Port

    7ZMMP-TU Motherboard IDE1 (Primary), IDE2 (Secondary) Port Red Line IDE 1 IDE 2 J8 TEL: The connector is for Modem with internal voice connector Pin No. Definition Signal-In Signal-Out...
  • Page 21: J7 (Aux_In)

    Connectors J7 : AUX_IN Pin No. Definition AUX-L AUX-R J9: CD Audio Line In Pin No. Definition CD-L CD-R...
  • Page 22: J13 (Ring Power On)

    7ZMMP-TU Motherboard J13: Ring Power On (Internal Modem Card Wake Up) Pin No. Definition Signal J12: Wake On LAN Pin No. Definition +5V SB Signal...
  • Page 23: Jp8 / Led1: Str Led Connector & Dimm Led

    Connectors JP8 / LED1: STR LED Connector & DIMM LED STR LED Connector External. DIMM LED J4: IR Pin No. Definition VCC (+5V) IR Data Input IR Data Output...
  • Page 24: Panel And Jumper Definition

    7ZMMP-TU Motherboard Panel And Jumper Definition J11: 2x11 Pins Jumper S P K P − P − P+ GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode(−) Pin 1: LED anode(+) (IDE Hard Disk Active LED) Pin 2: LED cathode(−)
  • Page 25: Jp4: Usb Device Wake Up Selection

    Panel and Jumper Definition JP11 / JP12 / J16: AMR (Primary or Secondary) Select (Optional) (AMRà Audio Modem Riser) JP12 JP11 JP12 JP11 Onboard AC97 AMR (Primary) Onboard AC97 MR (Secondary) (Default) JP4: USB Device Wake up Selection Pin No. Definition 1-2 Close Normal (Default) 2-3 Close USB Device Wake up...
  • Page 26: Jp7: Str Function Enabled

    7ZMMP-TU Motherboard JP7: STR Function Enabled Pin No. Definition 1-2 close STR Enabled 2-3 close Normal (Default) JP9: BIOS Write Protection Pin No. Definition 1-2 close Write Protect Enable 2-3 close Write Protect Disable (Default) M Please Set Jumper JP9 to ”Open” to enabled BIOS Write Function when you update new BIOS or new device.
  • Page 27: Jp13: Pci Sound

    Panel and Jumper Definition JP13: PCI Sound Pin No. Definition 1-2 close Enabled PCI Sound (Default) 2-3 close Disabled PCI Sound JP3 : Clear CMOS Function Pin No. Definition 1-2 close Normal (Default) 2-3 close Clear CMOS...
  • Page 28: Bat1: Battery

    7ZMMP-TU Motherboard BAT1: Battery Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer. + Dispose of used batteries according to the manufacturer’s instructions.
  • Page 29: Performance List

    Performance List Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) •...
  • Page 30: Block Diagram

    7ZMMP-TU Motherboard Block Diagram 100 MHz Socket A System Bus 100MHz NVIDIA VT8363 TNT2 3.3V SDRAM 100 / 133MHz 100 / 133MHz 100 / 133MHz 33MHz CYPRESS W230H 33MHz 3 PCI ATA66 IDE Channels 33MHz 14.318MHz 4 USB Ports 48MHz...
  • Page 31: Suspend To Ram Installation

    Suspend to RAM Installation Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 32 7ZMMP-TU Motherboard Step 2: (If you want to use STR Function, please set jumper JP7 Closed.) Pin No. Definition 1-2 close STR Enabled 2-3 close Normal (Default) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup.
  • Page 33 Suspend to RAM Installation A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B.
  • Page 34 7ZMMP-TU Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 35 Suspend to RAM Installation C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button. A.4 How to recover from the STR sleep mode? There are five ways to “wake up”...
  • Page 36 7ZMMP-TU Motherboard A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). Your SDRAM must be PC-100 compliant.
  • Page 37: Four Speaker & Spdif Introduction

    Four Speaker & SPDIF Introduction Four Speaker & SPDIF Introduction Four Speaker Introduction W hat is Four Speaker? The Creative CT5880 audio chip can support 4 speaker output, if you select “Four speaker” out, Line in will be change to another line out. How to use Four Speaker? a.
  • Page 38 7ZMMP-TU Motherboard c. Two speaker (Default) d. Click “Four speaker” item. Four Speaker Application The four speaker function will only support in application software that use Microsoft DirectX and Creative EAX. For example, the game titles, software DVD player and MP3 player. Those...
  • Page 39 Four Speaker & SPDIF Introduction SPDIF Introduction What is SPDIF? The SPDIF output is capable of providing digital a udio to external speakers or compressed AC3 data to an external Dolby digital decoder. How to use SPDIF? a. Press your mouse right button in “My Computer” and then select the “Properties” item. b.
  • Page 40 7ZMMP-TU Motherboard c. Press “S ound, video and game controllers” item and then select the “Creative Sound Blaster PCI128” item. d. Press “Settings” item and then select the “Output Mode” item.
  • Page 41 Four Speaker & SPDIF Introduction e. Click “Digital” item, Line Out will be change to SPDIF Out. f. Recommend you to select “Autosense”, it will auto detect the audio jack you plug in to Line Out is mono or stereo, and then change to SPDIF Out or Speaker out automatically.
  • Page 42: Memory Installation

    7ZMMP-TU Motherboard Memory Installation The motherboard has 3 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 43: Page Index For Bios Setup

    BIOS Setup $ Page Index for BIOS Setup Page The Main Menu P.38 Standard CMOS Setup P.40 BIOS Features Setup P.43 Chipset Features Setup P.45 Power Management Setup P.49 PNP/ PCI Configuration P.52 Load BIOS Defaults P.53 Load Setup Defaults P.54 Integrated Peripherals P.55...
  • Page 44 7ZMMP-TU Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.
  • Page 45: The Main Menu

    BIOS Setup GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 46 7ZMMP-TU Motherboard • Chipset Features Setup This setup page includes all the items of chipset special features. • Power Management Setup This setup page includes all the items of Green function features. • PnP/PCI Configurations This setup page includes all the configurations of PCI & PnP ISA resources.
  • Page 47: Standard Cmos Setup

    BIOS Setup Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 48 7ZMMP-TU Motherboard • Time The times format in <hour> <minute> <second>. The time is calculated b ase on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. • Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 49 BIOS Setup • Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 50: Bios Features Setup

    7ZMMP-TU Motherboard BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device Floppy 2nd Boot Device IDE-0 3rd Boot Device CDROM S.M.A.R.T. for Hard Disks Disabled BootUp Num-Lock...
  • Page 51 BIOS Setup • S.M.A.R.T. for Hard Disks Enabled Enabled S.M.A.R.T. Hard for Disks. Disabled Disabled S.M.A.R.T. Hard for Disks. (Default Value) • Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. • Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks.
  • Page 52: Chipset Features Setup

    7ZMMP-TU Motherboard Chipset Features Setup AMIBIOS SETUP – CHIPSET FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved *********DRAM Timing*** CAS# Drive 12 mA Top Performance Disabled RAS# Drive 24 mA DRAM Frequency 100MHz SDRAM CAS# Latency AGP Mode AGP Comp.
  • Page 53 BIOS Setup • AGP Mode Set AGP Mode to 4X. (Default Value) Set AGP Mode to 1X. Set AGP Mode to 2X. • AGP Comp. Driving Auto Set AGP Comp. Driving is Auto. (Default Value) Manual Set AGP Comp. Driving is Manual. If AGP Comp.
  • Page 54 7ZMMP-TU Motherboard • DRAM Drive Strength Auto Set DRAM Drive Strength to Auto. (Default Value) Manual Set DRAM Drive Strength to Manual. If DRAM Drive Strength is Manual, then you can adjust item below. • MD Bus Strength High Set MD Bus Strength to High. (Default Value) Set MD Bus Strength to Low.
  • Page 55 BIOS Setup • RAS# Drive 16 mA Set RAS# Drive to 16 mA. 24 mA Set RAS# Drive to 24 mA. (Default Value)
  • Page 56: Power Management Setup

    7ZMMP-TU Motherboard Power Management Setup AMIBIOS SETUP – POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Sleep Type S1/POS RTC Alarm Date Every Day USB Dev Wakeup From S3-S5 Disabled RTC Alarm Hour Suspend Time Out(Minute)
  • Page 57 BIOS Setup Enabled Suspend Time Out after 50min. Enabled Suspend Time Out after 60min. • Display Activity Ignore Ignore Display Activity. (Default Value) Monitor Monitor Display Activity. • IRQ 3~IRQ15 Ignore Ignore IRQ3 ~IRQ15. Monitor Monitor IRQ3~IRQ15. • Soft-off by Power Button Instant-off Press power button then Power off instantly.
  • Page 58 7ZMMP-TU Motherboard • Resume On RTC Alarm You can set “Resume On RTC Alarm” item to enabled and key in Data/time to power on system. Disabled Disabled this function. (Default Value) Enabled Enabled alarm function to POWER ON system. If the “Resume On RTC Alarm” is Enabled.
  • Page 59: Pnp/Pci Configuration

    BIOS Setup PNP/PCI Configuration AMIBIOS SETUP – PNP / PCI CONFIGURATION ( C ) 1999 American Megatrends, Inc. All Rights Reserved PnP OS Installed Reset Configuration Data VGA Boot from PCI VGA Palette Snoop Disabled ↑↓→ ← : Select Item ESC: Quit : Help PU/PD+/-/ : Modify...
  • Page 60: Load Bios Defaults

    7ZMMP-TU Motherboard Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP...
  • Page 61: Load Setup Defaults

    BIOS Setup Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION...
  • Page 62: Integrated Peripherals

    7ZMMP-TU Motherboard Integrated Peripherals AMIBIOS SETUP – INTEGRATED PERIPHERALS ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard Serial Port A Auto OnBoard Serial Port B Auto Normal Serial PortB Mode àDuplex Mode OnBoard Parallel Port Auto Parallel Port Mode...
  • Page 63 BIOS Setup • Serial Port B Mode Normal Normal operation. (Default Value) IrDA Onboard I/O chip supports IrDA. ASK IR Onboard I/O chip supports ASK IR. • Duplex Mode Half Duplex IR function. Half Duplex Disabled this function. (Default Value) Full Duplex IR function.
  • Page 64 7ZMMP-TU Motherboard • AC97 Audio Auto Enabled On Board AC97 Audio. (Default Value) Disabled Disabled On Board AC97 Audio. • MC97 Modem Auto Enabled On Board MC97 Modem. (Default Value) Disabled Disabled On Board MC97 Modem.
  • Page 65: Hardware Monitor

    BIOS Setup Hardware Monitor AMIBIOS SETUP – HARDWARE MONITOR SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Hardware Monitor CPU Temperature 54°C/129°F 36 ° C/96 ° F System Temperature CPU Fan Speed 7123 RPM System Fan Speed 0 RPM Vcore 1.70 V...
  • Page 66 7ZMMP-TU Motherboard Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved...
  • Page 67: Ide Hdd Auto Detection

    BIOS Setup IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Tue Jan 25, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Not Installed Pri Slave...
  • Page 68: Save & Exit Setup

    7ZMMP-TU Motherboard Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP...
  • Page 69: Exit Without Saving

    BIOS Setup Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY -VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION...
  • Page 70: Appendix

    7ZMMP-TU Motherboard Appendix Appendix A : VIA Chipsets Driver Installation A.VIA 4 in 1 Service Pack Utility: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen.
  • Page 71 Appendix 8.Click “Next”. 7.Click “Next”. 10.Click “Finish” to restart computer. 9.Click “Next”. (10)
  • Page 72 Appendix Appendix B: Creative Sound Driver Installation Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Audio 2.Click “OK”. 1.Click “Creative 5880 Sound Driver”.
  • Page 73 Appendix 7.Click “Finish” to restart computer.
  • Page 74 Appendix Appendix C: Install DirextX 7.0 Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 2.Click “Yes”. 1.Click “Install DirextX 7.0”. 3.Click “ReInstall DirextX”.
  • Page 75 Appendix Appendix D: Install Display Drivers Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 2.Click “Next”. 1.Click “Install Display Driver”. 4.Click “OK”.
  • Page 76 C:\utility \ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing> ü Once the process is finished, reboot the system MNote: Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file.
  • Page 77 Appendix Appendix F: Issues To Beware Of When Installing AMR Please use inverse AMR card like the one in order to avoid mechanical problem. (See Figure A) PCI Slot Figure A: Inverse AMR Card (Default) PCI Slot Figure B: Non inverse AMR Card...
  • Page 78 Appendix Appendix G: Acronyms Acor. Meaning ACPI Advanced Configuration and Power Interface POST Power-On Self Test Local Area Network Extended Capabilities Port Advanced Power Management Direct Memory Access Megahertz ESCD Extended System Configuration Data Central Processing Unit Symmetric Multi-Processing Universal Serial Bus Operating System Error Checking and Correcting Integrated Dual Channel Enhanced...
  • Page 79 Appendix Acor. Meaning Peripheral Component Interconnect RIMM Rambus in-line Memory Module Dual Retention Mechanism Industry Standard Architecture Memory Translator Hub CRIMM Continuity RIMM...
