Gigabyte 7VM333M-RZ User Manual

Gigabyte 7VM333M-RZ User Manual

Amd sempron, athlon, athlon xp, duron socket a processor motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
7VM333M-RZ
AMD Sempron
/Athlon
/Athlon
XP/Duron
Socket A Processor Motherboard
™
™
™
™
User's Manual
Rev. 1004
12ME-VM333MRZ-1004
Copyright
© 2004 GIGABYTE TECHNOLOGY CO., LTD
Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or transmitted in
any from without the expressed, written permission of GBT.
Trademarks
Third-party brands and names are the property of their respec tive owners.
Notice
Please do not remove any labels on motherboard, this may void the warranty of this motherboard.
Due to rapid change in technology, some of the specifications might be out of date before publication of this booklet.
The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make
a commitment to update the information contained herein.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7VM333M-RZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gigabyte 7VM333M-RZ

Summary of Contents for Gigabyte 7VM333M-RZ

  • Page 1 User's Manual Rev. 1004 12ME-VM333MRZ-1004 Copyright © 2004 GIGABYTE TECHNOLOGY CO., LTD Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or transmitted in any from without the expressed, written permission of GBT. Trademarks Third-party brands and names are the property of their respec tive owners.

  • Page 3: Preparing Your Computer

    Preparing Your Computer Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions when- ever you work on your computer. 1. Unplug your computer when working on the inside.

  • Page 4: Table Of Contents

    Table of Contents Chapter 1 Introduction ... 5 Features Summary ... 5 7VM333M-RZ Motherboard Layout... 6 Block Diagram ... 7 Hardware Installation Process ... 8 Step 1: Set System Jumper (JP1) ... 8 Step 2: Install the Central Processing Unit (CPU) ... 9 Step 2-1: CPU Installation ...

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction Features Summary — Socket A for AMD Sempron — 200/266/333MHz FSB — Supports 1.4GHz and faster Chipset — Northbridge : VIA KM 266 Pro — Southbridge : VIA VT8235/VT8237R Memory — 2 184-pin DDR DIMM sockets, supports up to 2GB DRAM (Max) —...

  • Page 6: 7Vm333M-Rz Motherboard Layout

    7VM333M-RZ Motherboard Layout KB_MS I T8705 BIOS F_AUDIO CD_IN CODEC SUR_CEN COMB SPDIF 7VM333M-RZ Motherboard 22.3 cm CPU_FAN SOCKET A VIA KM266 Pro PCI1 VIA VT8235/ PCI2 JP 1 PCI3 F_U SB1 F_U SB2 GAME PWR_LED - 6 - SYS_FAN...

  • Page 7: Block Diagram

    Block Diagram AGP 4X VGA Port AGPCLK 66MHz 3 PCI VT6103 PCI BUS 33MHz 6 Channel CODEC PCICLK (33MHz) PCICLK (33MHz) USBCLK (48MHz) 14.318 MHz 33 MHz CPUCLK+/- (100/133/166MHz) AMD-K7 Host CPU System Bus 200/266/333Hz FSB HCLK+/- (100/133/166MHz) KM266 Pro NBGCLK66 MHz 33 MHz 14.318 MHz...

  • Page 8: Hardware Installation Process

    Step 5 Step 4 Step 1: Set System Jumper (JP1) The system bus frequency can be switched at 100/133/166MHz by adjusting system jumper (JP1). (The internal frequency depend on CPU.) 7VM333M-RZ Motherboard Step 2 Step 3 Step 5 Step 1...

  • Page 9: Step 2: Install The Central Processing Unit (Cpu)

    Step 2: Install the Central Processing Unit (CPU) Before installing the processor, adhere to the following warning: 1. Please make sure the CPU type is supported by the motherboard. 2. The processor will overheat without the heatsink and/or fan, resulting in permanent irreparable damage.

  • Page 10: Step 3: Install Memory Modules

    To install the memory module, just push it vertically into the DIMM socket. The DIMM module can only fit in one direction due to the notch. Memory size can vary between sockets. 7VM333M-RZ Motherboard Notch 1. The DIMM socket has a notch, so the DIMM memory module can only fit in one direction.

  • Page 11: Step 4: Install Agp Card

    Step 4: Install AGP Card 1. Read the relate AGP card's instruction document before install the AGP card into the computer. 2. If your AGP card has "AGP 4X(1.5V) notch"(show below), please make sure your AGP card is AGP 4X(1.5V). 3.

  • Page 12: Step 5-2: Connectors Introduction

    Step 5-2: Connectors Introduction 1) ATX 2) CPU_FAN 3) SYS_FAN 4) FDD 5) IDE1 / IDE2 6) PWR_LED 7) F_PANEL 8) F_AUDIO 7VM333M-RZ Motherboard 9) SUR_CEN 10) SPDIF 11) CD_IN 12) COMB 13) GAME 14) F_USB1 / F_USB2 15) CLR_CMOS 16) BAT...
  • Page 13 1) ATX (ATX Power) AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard. 2) CPU_FAN (CPU Fan Connector) Please note, a proper installation of the CPU cooler is essential to prevent the CPU from running under abnormal condition or damaged by overheating.
  • Page 14 The red stripe of the ribbon cable m ust be the sam e side with the Pin1. 6) PWR_LED PWR_LED is connect with the system power indicator to indicate whether the system is on/off. It will blink when the system enters suspend mode. 7VM333M-RZ Motherboard IDE2 IDE1 Pin No.
  • Page 15 7) F_PANEL (2 x 10 pins Connector) Please connect the power LED, PC speaker, reset switch and power switch etc. of your chassis front panel to the F_PANEL connector according to the pin assignment below. HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RES (Reset Switch) PW (Soft Power Connector)
  • Page 16 SPDIF cable, incorrect connection between the cable and connector will make the device unable to work or even damage it. For optional SPDIF cable, please contact your local dealer. 11) CD_IN (CD In Connector) Connect CD-ROM or DVD-ROM audio out to the connector. 7VM333M-RZ Motherboard Pin No. Definition SUR OUTL...
  • Page 17 12) COMB (COM B Connector) Be careful with the polarity of the COMB connector. Check the pin assignm ent carefully while you connect the COMB cable, incorrect connection between the cable and connector will make the device unable to work or even damage it. For optional COMB cable, please contact your local dealer. 13) GAME (Game Connector) This connector supports joystick, MIDI keyboard and other relate audio devices.
  • Page 18 You may clear the CMOS data to its default values by this jumper. To clear CMOS, temporarily shor 1- 2 pin. Default doesn't include the "Shunter" to prevent from improper use this jumper. 16) BAT (Battery) 7VM333M-RZ Motherboard 1-2 close: Clear CMOS Open: Normal...

  • Page 19: Chapter 2 Bios Setup

    Chapter 2 BIOS Setup BIOS Setup is an ov erv iew of the BIOS Setup Program. The program that allow s users to modify the basic sy stem configuration. This ty pe of information is stored in battery -backed CM OS RAM so that it retains the Setup information w hen the pow er is turned off.
  • Page 20 • Save & Exit S etup Sav e CMOS v alue settings to CMOS and ex it s etup. • Exit Without S aving Abandon all CM OS v alue changes and ex it s etup. 7VM333M-RZ Motherboard - 20 -...

  • Page 21: Standard Cmos Features

    Standard CMOS Features CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware Date (mm:dd :yy) Time (hh:mm :ss) } IDE P rimary M aster } IDE P rimary S lave } IDE S econdary M aster } IDE S econdary Slave Driv e A Driv e B Flopp y 3 Mode S uport...
  • Page 22 640K for sy stems w ith 640K or more memory installed on the motherboard. Extended Memory The BIOS determines how much ex tended memory is present during the POST. This is the am ount of memory located abov e 1 MB in the CPU 's memory address map. 7VM333M-RZ Motherboard - 22 -...

  • Page 23: Advanced Bios Features

    Advanced BIOS Features CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware Firs t Boot D evice Seco nd Boot D evice Thir d Boot D evice Pas sword C heck higf: M ove Enter: Select F5: P revious V alues First / Second / Third Boot Device Floppy Selec t y our boot dev ic e priority by Floppy .

  • Page 24: Integrated Peripherals

    Disabled Disable USB 2. 0 controller. USB Keyboard Support Enabled Enable USB key board support. Disabled Disable USB key board support. (Default v alue) 7VM333M-RZ Motherboard Inte grated Periphe rals [Enab led] [Enab led] [Au to] [Enab led] [Enab led]...
  • Page 25 USB Mouse Support Enabled Enable USB mouse support. Disabled Disable USB m ouse support. (Default v alue) On-Chi p LAN Boot ROM This function decide w hether to inv oke the boot ROM of the onboard LAN chip. Disabled Disable this function. (Default Value) Enabled Enable this func tion.

  • Page 26: Power Management Setup

    Mouse P ower On Disabled Disabled this function. (Default v alue) Enabled Pow er on sy stem by mouse ev ent. 7VM333M-RZ Motherboard Powe r Manag ement S etup [S1(P OS)] Disa bled [Blin king] [Instan t-Off]...

  • Page 27: Pnp/Pci Configurations

    PME Event Wake Up When set at Enabled, any PCI-PM ev ent can aw ak e the sy stem from a PCI-PM controlled stated. This feature requires an ATX pow er supply that prov ides at least 1A on the +5VSB lead. Disabled Disable this function.

  • Page 28: Pc Health Status

    Fan w arning function enable. SYSTEM FAN Fail Warning Disabled Fan w arning function disable. (Default v alue) Enabled Fan w arning function enable. 7VM333M-RZ Motherboard PC H ealth St atus 4687 RPM 0 RPM [Disa bled] [Disa bled] +/-/ PU/PD: V alue...

  • Page 29: Frequency/Voltage Control

    Frequency/Voltage Control CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware Auto Detect PCI/DIMM Clk Spre ad Spec turm CPU Host Cl ock Con trol x CPU C lock DRAM Clock( MHz) AGP OverVolt age Con trol DIMM OverVol tage Con trol higf: M ove Enter: Select...

  • Page 30: Load Fail-Safe Defaults

    F8: Q- Flash Selecting this field loads the factory defaults for BI O S and Chipset Features w hich t h e sy stem automatically detects. 7VM333M-RZ Motherboard Load Fail-Sa fe Defa ults Load Optimiz ed Defa ults Set Supervis or Pass word Set U ser Pass word Save &...

  • Page 31: Set Supervisor/User Password

    Set Supervisor/User Password CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware Stan dard CM OS Feat ures Adva nced BI OS Feat ures Inte grated Periphe rals Powe r Manag ement S etup PnP/ PCI Con figurat ions Ente r Passw ord: PC H ealth St atus Frequ ency/Vol tage Con trol...

  • Page 32: Save & Exit Setup

    F8: Q- Flash Ty pe "Y" w ill quit the Setup Utility w ithout sav ing to RTC CMOS. Ty pe "N" w ill return to Setup Utility . 7VM333M-RZ Motherboard Load Fail-Sa fe Defa ults Load Optimiz ed Defa ults...

  • Page 33: Chapter 3 Driver Installation

    Revision History Chapter 3 Install Drivers Install Drivers Pictures below are shown in Windows XP Insert the driver CD-title that came with your motherboard into your CD-ROM drive, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe.
  • Page 34 Pack. After install Windows Service Pack, it will show a question mark "?" in "Universal Serial Bus controller" under "Device Manager". Please remove the question mark and restart the system (System will auto-detect the right USB2.0 driver). 7VM333M-RZ Motherboard Driver install finished ! You have to reboot system !
  • Page 35 TEL: +886 (2) 8912-4888 FAX: +886 (2) 8912-4003 Tech. Support : http://tw.giga-byte.com/TechSupport/ServiceCenter.htm Non-Tech. Support (Sales/Marketing) : http://ggts.gigabyte.com.tw/nontech.asp WEB address (English): http://www.gigabyte.com.tw WEB address (Chinese): http://chinese.giga-byte.com — U.S.A. G.B.T. INC. Address: 17358 Railroad St, City of Industry, CA 91748. TEL: +1 (626) 854-9338 FAX: +1 (626) 854-9339 Tech.
  • Page 36 — China NINGBO G.B.T. TECH. TRADING CO., LTD. Tech. Support : http://cn.giga-byte.com/TechSupport/ServiceCenter.htm Non-Tech. Support (Sales/Marketing) : http://ggts.gigabyte.com.tw/nontech.asp WEB address : http://www.gigabyte.com.cn Shanghai TEL: +86-021-63410999 FAX: +86-021-63410100 Beijing TEL: +86-010-82886651 FAX: +86-010-82888013 Wuhan TEL: +86-027-87851061 FAX: +86-027-87851330 GuangZhou TEL: +86-020-87586074 FAX: +86-020-85517843...
