ahead RC Crawler MK23 Front
Cab TRX4M
Assembly Manual

ahead RC
1
of
13

Advertisement

loading
Need help?

Need help?

Do you have a question about the Crawler MK23 Front Cab TRX4M and is the answer not in the manual?

Questions and answers

Summary of Contents for ahead RC Crawler MK23 Front Cab TRX4M

  • Page 1 RC Crawler MK23 Front Cab TRX4M Assembly Manual
 ahead RC...
  • Page 2 Required tools and hardware  Tools  1.5mm Hex Driver  2.0mm Hex Driver  Needle Nosed Pliers  Instant Glue  Electronics  3mm White LED x4  3mm Orange LED x2  Hardware  Hardware Quantity Check  M2*5 Socket head M2*10 Socket head 47(23 if using 1  piece wheels) M2.5*10 Socket head ahead RC...
  • Page 3: Before You Begin

    Before you begin  Be sure to read through the manual and familiarise yourself  with the instructions  Visualise a plan to assemble all the pieces  Make sure you have all of the hardware and tools  Be sure to have enough instant glue  Dry fit all parts before painting and assembling  Tip: It will help to paint all of the parts before final assembly  ahead RC...
  • Page 4 Assembling the front cab interior M2x10mm     x3
 ahead RC...
  • Page 5 Installing the fenders and cab joiners
 Repeat on the  other cab joiner M2x10mm     x6 ahead RC...
  • Page 6 Assembling the grille
 ahead RC...
  • Page 7 Installing the lights M2x5mm     x4 Orange 3mm  White 3mm  LED x2 LED x2 Repeat on the  other fender  cover
 ahead RC...
  • Page 8 Assembling and installing the bumper
 M2x10mm     x4 White 3mm  Repeat on the other  LED x2 bumper mount M2x5mm     x2 M2x10mm     x4 ahead RC...
  • Page 9 Assembling and installing the bumper and doors Repeat on the  other side M2x10mm     x6
 ahead RC...
  • Page 10 Installing the mirrors and details
 Repeat on the  other side M2x5mm     x4 ahead RC...
  • Page 11 Assembling and mounting the wheels and tyres // front
 chassis brace Mount tyres M2x10mm      ahead RC...
  • Page 12
 Repeat on the  other body mount M2.5x10mm      ahead RC...
  • Page 13 Body is now fully complete. Thank you for selecting ahead RC  products.   If you have any questions or need help with the assembly,  please do not hesitate to contact us at:  aheadrc@gmail.com  or visit us at:  www.aheadrc.com  Best of luck with your build! ahead RC...
