- Page 1 LPC-2AxM Series P-cap Panel PC LGA1700 13 Gen., Core-i7/5/3 User Manual Published in Taiwan Release Date : Oct., 2023 Revision : V0.1...
- Page 2 Disclaimer This information in this document is subject to change without notice. In no event shall ELGENS Co., Ltd. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.
-
Page 3: Table Of Contents
4.1.2 Please follow the red blank....................38 Graphics Driver Setup ........................41 4.2.1 Select “ Intel_VGA(v31.0.101.4146)” folder and execute “GFX_win_101.4146.exe” ..41 4.2.2 Please follow the red blank....................41 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 4 Please follow the red blank....................46 ME Driver Setup ..........................50 4.5.1 Go to “ME(v16.0.15.1620_CORP_SW_DCH)” and choose ”SetupME.exe” ......50 4.5.2 Please follow the red blank....................50 History ..................... 53 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 5: Chapter 1 Getting Started
2 Ethernet, 2 USB 3.2 (Gen2) and 2 USB2.0 ports. The unit supports Windows 10 operation system. The Elgens’ fanless touch panel computer is ideal for use as Web Browser, Terminal, HMI at all levels of automation control or a high-performance system that working on rash environment. - Page 6 IP Rating Front Panel compliant IP65 Mounting Panel Mount & VESA Environmental Operating -20~60 °C Temperature -30~70 °C (Optional by Heat-Pipe Model) Storage -30~70 °C Temperature Storage 10~90% @40 °C non-condensing Humidity ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 7: Naming Rule
Dual Storage Tray, DC LPC-Pxxxx-2A5MT 24V Power Input, including a 3-Pin Power Adapter Bezel-Free P-cap Panel PC with Gen., Core i7, Dual Storage Tray, DC LPC-Pxxxx-2A7MT 24VPower Input, including a 3-Pin Power Adapter ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 8 H = High Brightness 1000 nits LED backlight (Optional, up to 1600 nits backlight, by LCD limited) OB = Optical Bonding (Optional) AG = Anti-Glare (Optional) AR = Anti-Reflection (Optional) V = Vandal Proof Glass (Optional) ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 9: Dimension
Dimension LPC-P150S-2AxMT Drawing ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 10 LPC-P170S-2AxMT Drawing ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
- Page 11 LPC-P215W-2AxMT Drawing ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 12: Top / Bottom Io View
Top / Bottom IO View Top View (by P150S) Bottom View (by P150S) ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 13: Motherboard Layout
Motherboard Layout It may cause system/board damage if change the Jumper/Connector setting. Please do NOT change the setting if you are not very clear to know the Jumper/Connector used for. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 14 31 : 2-pin UPS Module Power Input Connector 32 : SPDIF Header 33 : Front Panel Audio Header 34 : 3W Audio AMP Output Wafer 35 : USB2.0 Header (USB2_5_6) 36 : USB3.2 Gen1 Header (USB3_4_9) ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 15: Chapter 2 Installation
2. It is easy to cause damage after the heatsink had removed. Please be carefully do not drop tools and/or parts on it while heatsink had removed. 3. Make sure all parts and screws are secured before you cover up. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 16: Installation Of Dram
Please do not intermix different voltage SO-DIMMs on this motherboard. Step 3. Firmly insert the SO-DIMM into the slot until the retaining clips at both ends fully snap back in place and the SO-DIMM is properly seated. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 17: Installation Of Hdd (For 2Axm Series)
Installation of HDD (for 2AxM Series) Step 1. Following CH2.1 to open case. Step 2. Screwed Storage on bracket Step 3. Screwed the assembled parts of step2 into system ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 18 Step 4. Connect storage Cables with Boards ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 19: Installation Of Low-Profile Pci-Express Cards (For 2Axm Series)
Installation of Low-Profile PCI-Express Cards (for 2AxM Series) Step 1. Following CH2.1 to open case. Step 2. Loosen screws to remove cover brackets. Step 3. Plug Low-Profile PCI-Express cards into slot. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 20 Step 4. Make sure the card’s bracket had plugged into groove and screw in the three M3*5 screws tight to secure the add-on cards. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 21: Chapter 3 Uefi Setup Utility
To set up the security features Boot To set up the default system device to locate and load the Operating System Exit To exit the current screen or the UEFI SETUP UTILITY ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 22: Control In Uefi
The BIOS setup program provides a General Help screen. You can call up this screen from any menu by simply pressing <F1>. The Help screen lists the appropriate keys to use and the possible selections for the highlighted item. Press <Esc> to exit the Help screen. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 23: Main
This setting allows you to set the system date. The date format is <Day>, <Month> / <Date> / <Year>. System Time This setting allows you to set the system time. The time format is <Hour> / <Minute> / <Second>. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 24: Advanced
FAT32/16/12 file system. If you execute Instant Flash utility, the utility will show the UEFI files and their respective information. Select the proper UEFI file to update your UEFI BIOS and reboot your system after UEFI update process completes. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 25: Cpu Configuration
Intel SpeedStep technology is Intel’s new power saving technology. Processors can switch between multiple frequencies and voltage points to enable power saving. The default value is [Enabled]. Configuration options: [Enabled] and [Disabled]. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 26 You may select [Enabled] to enable CPU internal thermal control mechanism to keep the CPU from overheating. Hardware Prefetcher Use this item to turn on/off the MLC streamer prefetcher. Adjacent Cache Line Prefetch Use this item to turn on/off prefetching of adjacent cache lines. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 27: Chipset Configuration
PCIE1 Bandwidth Mode Select the bandwidth mode for PCIE1. Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up. IGPU Multi-Moniter ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 28 Onboard Digital Audio Enable or disable Onboard Digital Audio. Deep Sleep Mobile platforms support Deep S4/S5 in DC only and desktop platforms support Deep S4/S5 in AC only. The default value is [Disabled]. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 29: Storage Configuration
Use this item to configure SATA Aggressive Link Power Management. Hard Disk S.M.A.R.T. Use this item to enable or disable the S.M.A.R.T. (Self-Monitoring, Analysis, and Reporting Technology) feature. Configuration options: [Disabled] and [Enabled]. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 30: Super Io Configuration
Use this to select COM3 port type: [RS232], [RS422] or [RS485]. COM3 Configuration Use this to set parameters of COM3. COM4 Configuration Use this to set parameters of COM4. WDT Timeout Reset Use this to set the Watch Dog Timer. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 31: Acpi Configuration
Use this item to enable or disable PCIE devices to turn on the system from the power-soft-off mode. RTC Alarm Power On Use this item to enable or disable RTC (Real Time Clock) to power on the system. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 32: Usb Configuration
3.3.6 USB Configuration USB Power Control Use this option to control USB power. M.2 Key_B USB Configuration Enable or disable M.2 Key_B USB Configuration. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 33: Trusted Computing
3.3.7 Trusted Computing Security Device Support Enable or disable BIOS support for security device. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 34: Hardware Health Event Monitoring Screen
[Disabled]. Clear Status This option appears only when the case open has been detected. Use this option to keep or clear the record of previous chassis intrusion status. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 35: Security
Set or change the password for the user account. Users are unable to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password. Secure Boot Use this item to enable or disable support for Secure Boot. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 36: Boot
If this item is set to [On], it will automatically activate the Numeric Lock function after boot-up. Full Screen Logo Use this item to enable or disable OEM Logo. The default value is [Disabled]. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 37: Exit
Load UEFI default values for all the setup questions. F9 key can be used for this operation. Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shell64.efi) from one of the available filesystem devices. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... -
Page 38: Chapter 4 Installation Drivers
Because motherboard settings and hardware options vary, use the setup procedures in this chapter for general reference only. Refer your OS documentation for more information. Chipset Driver Installation 4.1.1 Select “Chipset-10.1.19165.8332-Public-MUP” folder and execute “SetupChipset.exe” 4.1.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 39 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
- Page 40 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 41: Graphics Driver Setup
Graphics Driver Setup 4.2.1 Select “ Intel_VGA(v31.0.101.4146)” folder and execute “GFX_win_101.4146.exe” 4.2.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 42 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
- Page 43 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 44: Audio Driver Setup
Audio Driver Setup 4.3.1 Select “Audio(9239_FF00)” folder and execute “Setup.exe” 4.3.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 45 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 46: Lan Driver Setup
LAN Driver Setup 4.4.1 Go to ” Intel LAN 27.7” folder and choose ” Autorun.exe” 4.4.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 47 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
- Page 48 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
- Page 49 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 50: Me Driver Setup
ME Driver Setup 4.5.1 Go to “ME(v16.0.15.1620_CORP_SW_DCH)” and choose ”SetupME.exe” 4.5.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual... - Page 51 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
- Page 52 ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
-
Page 53: History
History Revision Date Modification Note 2023/10/11 Release ELGENS CO., LTD. LPC P-cap 2AxM Series User Manual...
