Elgens PC 2VE Series User Manual

Lpc p-cap panel pc with gen 7/6 core-i7/5/3
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LPC P-cap Panel PC 2VE Series
With Gen 7/6 Core-i7/5/3
Published in Taiwan
Release Date : Sep 2019
Revision : V1.0
User Manual
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC 2VE Series and is the answer not in the manual?

Questions and answers

Related Manuals for Elgens PC 2VE Series

Summary of Contents for Elgens PC 2VE Series

  • Page 1 LPC P-cap Panel PC 2VE Series With Gen 7/6 Core-i7/5/3 User Manual Published in Taiwan Release Date : Sep 2019 Revision : V1.0...
  • Page 2 This information in this document is subject to change without notice. In no event shall ELGENS Co., Ltd. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Getting Started 1.1 Brief Description of LPC P-cap 2VE Series 1.2 System Specifications 1.3 Dimension 1.4 General Rear IO Placement 1.5 Front View of LPC- Pcap Series 1.6 Rear View of LPC- Pcap Series 1.7 Top / Bottom IO View 1.8 Installation of HDD Chapter 2 BIOS Setup 2.1 Entering Setup...
  • Page 4 2.3.14 USB Configuration Legacy USB Support XHCI Hand-off Port 60/64 Emulation Device power-up delay 2.4 Chipset 2.4.1 System Agent (SA) Configuration VT-d Above 4GB MMIO BIOS assignment 2.4.2 Graphics Configuration of System Agent (SA) Primary Display Aperture Size DVMT Pre-Allocated DVMT Total Gfx Mem 2.4.3 Memory Information of System Agent (SA) 2.4.4 PCH-IO Configuration...

  • Page 5: Chapter 1 Getting Started

    Chapter 1 Getting Started 1.1 Brief Description of LPC P-cap 2VE Series The LPC P-cap 2VE series is a power-optimized and delivers robust performance-per- watt for embedded HMI, powered by a Gen 7/6 Core-i7/5/3/Celeron U-Series processor. It comes with a Bezel-Free design, mSATA slot and a SATA 2.5-inch lockable HDD tray, up to 16GB DDR4 memory, audio jack, 2 Ethernet, DC input, and 4 USB 3.0 ports.
  • Page 6 Win 7 Pro/ WES7 / Win 8 / Win 10 (Gen6/7) OS support Win 10 (Gen 7) Touch Screen Type USB P-cap Touch Light Transmission Power Supply ■ DC9~36V Wide Range Power Input ■ Input on board fuse ■ Power Input Input reverse protection ■...
  • Page 7 Bezel-Free P-cap Panel PC with i5-6300U, DC 9~36V Power Input, including a 3-Pin Power LPC-Pxxxx-2VE3 Adapter Bezel-Free P-cap Panel PC with i7-6600U, DC 9~36V Power Input, including a 3-Pin Power LPC-Pxxxx-2VE4 Adapter Bezel-Free P-cap Panel PC with i7-7600U, DC 9~36V Power Input, including a 3-Pin Power LPC-Pxxxx-2VE5 Adapter ( Only work with Win 10 )

  • Page 8: Dimension

    1.3 Dimension LPC-P150S-2VEX Drawing...
  • Page 10 LPC-P156W-2VEX Drawing LPC- P170S- 2VEX Drawing...
  • Page 11 LPC-P173W-2VEX Drawing...
  • Page 13 LPC-P185W-2VEX Drawing LPC- P190S- 2VEX Drawin...

  • Page 14: General Rear Io Placement

    1.4 General Rear IO Placement...
  • Page 15 COM 1 is default RS-485 as below pin definition, adjustable to RS-RS232/422 by BIOS. Power input terminal block pin definition is as below. 1.5 Front View of LPC- Pcap Series...

  • Page 16: Front View Of Lpc- Pcap Series

    1.6 Rear View of LPC- Pcap Series 1.7 Top / Bottom IO View...

  • Page 17: Installation Of Hdd

    1.8 Installation of HDD Chapter 2 BIOS Setup...

  • Page 18: Chapter 2 Bios Setup

    2.1 Entering Setup BIOS provides an interface for users to check and change system configuration. The BIOS setup program is accessed by pressing the <Del> key when POST display output is shown. Figure 4-1 : Entering Setup Screen 2.2 Main Menu The main menu displays BIOS version and system information.

  • Page 19: Advanced Function

    System Time Set the Time. Use Tab to switch between Time elements. 2.3 Advanced Function Select Advanced tab to enter advanced BIOS Setup options such as CPU configuration SATA configuration, and USB configuration. Figure 4-3 : BIOS Advanced Menu 2.3.1 ACPI Setting Figure 4-3-1 : ACPI Settings Enable Hibernation Enables or disables system's ability to hibernate (OS/S4 Sleep State).

  • Page 20: Amt Configuration

    2.3.2 AMT Configuration Figure 4-3-2 : Intel AMT Settings Intel AMT Enable/disable Intel Active Management Technology BIOS Extension. Note: iAMT H/W is always enabled. This option just controls the BIOS extension execution. If enabled, this requires additional firmware in the SPI device. 2.3.3 PCH-FW Configuration Figure 4-3-3 : PCH-FW Settings ME Unconfig on RTC Clear State...

  • Page 21: Smart Settings

    2.3.4 SMART Settings Figure 4-3-4 : SMART Settings SMART Self Test Run SMART Self Test on all HDDs during POST. 2.3.5 IT8786 Super IO Configuration Figure 4-3-5 : Super IO Settings Serial Port 1 Configuration Set parameters of serial port 1 (COM 1). Serial Port 2 Configuration Set parameters of serial port 2 (COM 2).

  • Page 22: Serial Port Console Redirection

    Figure 4-3-6 : Hardware Monitor Settings 2.3.7 Serial Port Console Redirection Figure 4-3-7 : Serial Port Console Redirection Settings Console Redirection Console redirection enable or disable. Console Redirection Settings The settings specify how the host computer and the remote computer (which the user is using) will exchange data.

  • Page 23: Hyper-Threading

    Figure 4-3-8 : CPU Function Settings Hyper-threading Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and disabled for other OS (OS not optimized for Hyper-Threading Technology). When disabled only one thread per enabled core is enabled. Active Processor Cores Number of cores to enable in each processor package.

  • Page 24: Intel Txt(Lt) Suppor

    Intel TXT(LT) Suppor Enables or disabled Intel TXT(LT) support. 2.3.9 Intel TXT iformation Display Intel TXT information. Figure 4-3-9 : Intel TXT Information 2.3.10 SATA Configuration Figure 4-3-10 : SATA Devices Settings Hyper-threading Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and disabled for other OS (OS not optimized for Hyper-Threading Technology).

  • Page 25: Software Feature Mask Configuration

    Enable or disable SATA Device. SATA Mode Selection Determines how SATA controller(s) operate. Software Feature Mask Configuration RAID OROM/RST driver will refer to the SWFM configuration to enable or disable the storage features. Aggressive LPM Support Enable PCH to aggressively enter link power state. Options for each SATA port : Port 0 Enable or disabled SATA Port.

  • Page 26: Ipv4 Pxe Support

    Ipv4 PXE Support Enable Ipv4 PXE Boot Support. If disabled IPV4 PXE boot option will not be created. Ipv6 PXE Support Enable Ipv6 PXE Boot Support. If disabled IPV6 PXE boot option will not be created. PXE boot wait time Wait time to press ESC key to abort the PXE boot.

  • Page 27: Other Pci Devices

    Storage Controls the execution of UEFI and Legacy Storage OpROM. Video Controls the execution of UEFI and Legacy Video OpROM. Other PCI devices Determines OpROM execution policy for devices other than network, storage, or video. 2.3.14 USB Configuration Figure 4-3-14 : USB Settings Network Stack Enable/disable UEFI Network Stack.

  • Page 28: Device Power-Up Delay

    Device power-up delay Maximum time the device will take before it properly reports itself to the host controller. 'Auto' uses default value: for a root port it is 100 ms, for a hub port the delay is taken from hub descriptor. 2.4 Chipset Figure 4-4 : BIOS Chipset Menu System Agent (SA) Configuration...

  • Page 29: Above 4Gb Mmio Bios Assignment

    Above 4GB MMIO BIOS assignment Enable/disable above 4GB Memory MappedIO BIOS assignment. This is disabled automatically when Aperture Size is set to 2048MB. 2.4.2 Graphics Configuration of System Agent (SA) Figure 4-4-1 : USB Settings Graphics Turbo IMON Current Graphics turbo IMON current values supported (14-31). Skip Scaning of External Gfx Card If enable, it will not scan for External Gfx Card on PEG and PCH PCIE Ports.

  • Page 30: Memory Information Of System Agent (Sa)

    2.4.3 Memory Information of System Agent (SA) Figure 4-4-3 : Memory Information Display memory information. 2.4.4 PCH-IO Configuration Figure 4-4-4 : USB Settings PCH LAN Controller Enable or disable onboard NIC. Wake on LAN Enable or disable integrated LAN to wake the system. (The Wake On LAN cannot be disabled if ME is on at Sx state).

  • Page 31: Pci Express Configuration Of Pch-Io

    2.4.5 PCI Express Configuration of PCH-IO Figure 4-4-5 : PCH-IO Settings DMI Link ASPM Control Enable/disable the control of Active State Power Management on SA side of the DMI Link. Intel Ethernet Controller I210 Intel Ethernet Controller I210 Settings. Mini PCIe Slot with SIM Mini PCIe Slot with SIM Settings.

  • Page 32: Sata Raid Rom

    SATA RAID ROM Legacy ROM: Legacy option ROM UEFI Driver: UEFI Raid Driver Both: Run the legacy Option ROM and UEFI driver. 2.4.8 LVDS Configuration Figure 4-4-8 : LVDS Panel Settings LCD Panel Type Select LCD Panel Resolution. 2.5 Security Figure 4-5 : BIOS Security Menu Administrator Password Set Administrator Password.

  • Page 33: Hdd Security Configuration

    2.5.1 HDD Security Configuration Figure 4-5-1 : HDD Security Settings Set User Password Set HDD user password. Advisable to Power Cycle System after Setting Hard Disk Passwords. Discard or save changes option in setup does not have any impact on HDD when password is set or removed.

  • Page 34: Save & Exit

    Boot Option #x Sets the system boot order. New Boot Option Policy Controls the placement of newly detected UEFI boot options. Hard Drive BBS Priorities Set the order of the legacy devices in this group. 2.7 Save & Exit Figure 4-7 : Bios Save and Exit Menu Save Changes and Exit Exit system setup after saving the changes.

  • Page 35: Restore User Defaults

    Restore/load default values for all the setup options. Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup optio...

  • Page 36: Chapter 3 Software Install

    Chapter 3 Software install Software Package contain There are three folders as follows: 1. Driver folder includes x86 and x64 version. 2. DLL and head file for software developer or System Integration. 3. C# and C++ sample program. A.4 Driver Install This driver only supports 32-bit version that are WinXP and Win7 32-bit version.
  • Page 37 In the 64-bit version, there will be a window for driver certification. Please agree to this license to finish the install process. After driver installation process is complete, you must restart the system to get DIO driver activated.

  • Page 38: Appendix A : Isolated Dio Guide

    APPENDIX A : ISOLATED DIO GUIDE A.1 I/O Pin Definition I/O Pin GPIO 77~74 GPIO 87~84 GPIO 73~70 GPIO 83~80 Base Adr. 0xA06 [7:4] 0xA07 [7:4] 0xA06 [3:0] 0xA07 [3:0] Usage DIO 2 Output DIO 2 Input DIO 1 Output DIO 1 Input A.2 Function Description The EMBC-1000 offers a 16-bit DIO (8-DI/8-DO) on two wafer connector.

This manual is also suitable for:

Lpc-p150s-2vexLpc-p156w-2vexLpc-p170s-2vexLpc-p173w-2vexLpc-p185w-2vexLpc-p190s-2vex
