- Page 1 LPC-2CxM Series P-cap Panel PC LGA1151 9 Gen., Core-i7/5/3 User Manual Published in Taiwan Release Date : Nov 2022 Revision : V0.1...
- Page 2 Disclaimer This information in this document is subject to change without notice. In no event shall ELGENS Co., Ltd. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.
-
Page 3: Table Of Contents
Installation Drivers ............39 Chipset Driver Installation ......................39 4.1.1 Select “INF(v10.1.17968.8131_Public) ” folder and execute “Setupchipset.exe”....39 4.1.2 Please follow the red blank....................39 Graphics Driver Setup ........................42 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 4 Please follow the red blank....................48 ME Driver Setup ..........................51 4.5.1 Go to “ME(v12.0.2.1087_Corp)” and choose ”SetupME.exe” ........... 51 4.5.2 Please follow the red blank....................51 History ..................... 54 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 5: Chapter 1 Getting Started
Ethernet, and 4 USB 3.1 ports. The unit supports Windows 10 operation system. The Elgens’ fanless touch panel computer is ideal for use as Web Browser, Terminal, HMI at all levels of automation control or a high-performance system that working on rash environment. - Page 6 Aluminum Heatsink and Metal Case IP Rating Front Panel compliant IP65 Mounting Panel Mount & VESA Environmental Operating -30~70 °C Temperature Storage -30~70 °C Temperature Storage 10~90% @40 °C non-condensing Humidity ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 7: Naming Rule
3-Pin Power Adapter WFK-024 Wi-Fi kits w/ cable & Antenna (2.4GHz, 802.11 b/g/n, 1T1R) WFK-524 Wi-Fi kits w/ cable & Antenna (2.4 & 5GHz, 802.11 a/b/g/n/ac + BT, 2T2R) Order Code ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 8 H = High Brightness 1000 nits LED backlight (Optional, up to 1600 nits backlight, by LCD limited) OB = Optical Bonding (Optional) AG = Anti-Glare (Optional) AR = Anti-Reflection (Optional) V = Vandal Proof Glass (Optional) ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 9: Dimension
Dimension LPC-P150S-2CxM Drawing ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 10: Top / Bottom Io View
Top / Bottom IO View Top View Bottom View ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 11: Motherboard Layout
Motherboard Layout It may cause system/board damage if change the Jumper/Connector setting. Please do NOT change the setting if you are not very clear to know the Jumper/Connector used for. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 12 29 : Front Panel Audio Header 30 : SPDIF Header 31 : CPU FAN Connector (+12V) 32 : Chassis FAN Connector (+12V) 33 : SATA3 Connectors (SATA3_1, SATA3_2) 34 : LPC Header ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 13: Chapter 2 Installation
2. It is easy to cause damage after the heatsink had removed. Please be carefully do not drop tools and/or parts on it while heatsink had removed. 3. Make sure all parts and screws are secured before you cover up. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 14: Installation Of Dram
Please do not intermix different voltage SO-DIMMs on this motherboard. Step 3. Firmly insert the SO-DIMM into the slot until the retaining clips at both ends fully snap back in place and the SO-DIMM is properly seated. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 15: Installation Of Hdd
Installation of HDD Step 1. Following CH2.1 to open case. Step 2. Screwed Storage on bracket Step 3. Screwed the assembled parts of step2 into system ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 16 Step 4. Connect storage Cables with Boards ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 17: Installation Of Low-Profile Pci-Express Cards
Installation of Low-Profile PCI-Express Cards Step 1. Following CH2.1 to open case. Step 2. Loosen screws to remove cover brackets. Step 3. Plug Low-Profile PCI-Express cards into slot. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 18 Step 4. Make sure the card’s bracket had plugged into groove and screw in the three M3*5 screws tight to secure the add-on cards. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 19: Chapter 3 Uefi Setup Utility
The items under each BIOS category described in this chapter are under continuous update for better system performance. Therefore, the description may be slightly different from the latest BIOS and should be held for reference only. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 20 The BIOS setup program provides a General Help screen. You can call up this screen from any menu by simply pressing <F1>. The Help screen lists the appropriate keys to use and the possible selections for the highlighted item. Press <Esc> to exit the Help screen. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 21: Main
This setting allows you to set the system date. The date format is <Day>, <Month> / <Date> / <Year>. System Time This setting allows you to set the system time. The time format is <Hour> / <Minute> / <Second>. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 22: Advanced
FAT32/16/12 file system. If you execute Instant Flash utility, the utility will show the UEFI files and their respective information. Select the proper UEFI file to update your UEFI BIOS and reboot your system after UEFI update process completes. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 23: Cpu Configuration
Use this item to enable or disable Intel Turbo Boost Mode Technology. Turbo Boost Mode allows processor cores to run faster than marked frequency in specific conditions. The default value is [Enabled]. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 24 You may select [Enabled] to enable CPU internal thermal control mechanism to keep the CPU from overheating. Hardware Prefetcher Use this item to turn on/off the MLC streamer prefetcher. Adjacent Cache Line Prefetch Use this item to turn on/off prefetching of adjacent cache lines. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 25: Chipset Configuration
Active LVDS is changed to ENABLE (F9 load default is also set to ENABLE) Change the setting from [Enable] to [Disable], and then press <F10> to save the setting and ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 26 Onboard Digital Audio Enable or disable Onboard Digital Audio. Deep Sleep Mobile platforms support Deep S4/S5 in DC only and desktop platforms support Deep S4/S5 in AC only. The default value is [Disabled]. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 27: Pci/Pcie Device Configuration
Use this item to configure SATA Aggressive Link Power Management. Hard Disk S.M.A.R.T. Use this item to enable or disable the S.M.A.R.T. (Self-Monitoring, Analysis, and Reporting Technology) feature. Configuration options: [Disabled] and [Enabled]. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 28: Super Io Configuration
Use this to set parameters of COM4. Type Select Use this to select COM3 port type: [RS232], [RS422] or [RS485]. WDT Timeout Reset Use this to set the Watch Dog Timer. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 29: Amt Configuration
Un-Configure ME without password. The default is [Disabled]. WatchDog Use this to enable or disable AMT WatchDog Timer. The default is [Disabled]. Activate Remote Assistance Process Trigger CIRA boot. The default is [Disabled]. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 30 Use this to set resolution for non-UI text mode. UI Mode Resolution Use this to set resolution for UI text mode. Graphics Mode Resolution Use this to set resolution for graphics mode. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 31: Acpi Configuration
Use this item to enable or disable PCIE devices to turn on the system from the power-soft-off mode. RTC Alarm Power On Use this item to enable or disable RTC (Real Time Clock) to power on the system. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 32: Usb Configuration
[UEFI Setup Only] - USB devices are allowed to use only under UEFI setup and Windows / Linux XHCI Hand-off This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 33: Trusted Computing
3.3.8 Trusted Computing Security Device Support Enable or disable BIOS support for security device. Onboard TPM Use this to enable or disable onboard TPM. The default is [Enabled]. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 34: Hardware Health Event Monitoring Screen
[Disabled]. Clear Status This option appears only when the case open has been detected. Use this option to keep or clear the record of previous chassis intrusion status. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 35: Security
Set or change the password for the user account. Users are unable to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password. Secure Boot Use this item to enable or disable support for Secure Boot. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 36: Boot
If this item is set to [On], it will automatically activate the Numeric Lock function after boot-up. Full Screen Logo Use this item to enable or disable OEM Logo. The default value is [Disabled]. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 37: Csm (Compatibility Support Module)
Select UEFI only to run those that support UEFI option ROM only. Select Legacy only to run those that support legacy option ROM only. Select Do not launch to not execute both legacy and UEFI option ROM. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 38: Exit
Load UEFI default values for all the setup questions. F9 key can be used for this operation. Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shell64.efi) from one of the available filesystem devices. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... -
Page 39: Chapter 4 Installation Drivers
Chapter 4 Installation Drivers Chipset Driver Installation 4.1.1 Select “INF(v10.1.17968.8131_Public) ” folder and execute “Setupchipset.exe” 4.1.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 40 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
- Page 41 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 42: Graphics Driver Setup
Graphics Driver Setup 4.2.1 Select “ VGA(v25.20.100.6617)” folder and execute “igxpin.exe” 4.2.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 43 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
- Page 44 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
- Page 45 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 46: Audio Driver Setup
Audio Driver Setup 4.3.1 Select “Audio 9057_FF00” folder and execute “Setup.exe” 4.3.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 47 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 48: Lan Driver Setup
LAN Driver Setup 4.4.1 Go to ”Intel_LAN(v23.5.2) ” folder and choose ” Autorun.exe” 4.4.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 49 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
- Page 50 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 51: Me Driver Setup
ME Driver Setup 4.5.1 Go to “ME(v12.0.2.1087_Corp)” and choose ”SetupME.exe” 4.5.2 Please follow the red blank. ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual... - Page 52 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
- Page 53 ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
-
Page 54: History
History Revision Date Modification Note 2022/11/01 Release ELGENS CO., LTD. LPC P-cap 2CxM Series User Manual...
