- Page 1 Flow control valve type SJ Product documentation Screw-in valve Operating pressure p 315 bar Flow rate Q 15 lpm D 7395 11-2013-1.1...
- Page 2 The forwarding and reproduction of this document, as well as the use and communication of its contents, are forbidden unless expresse- ly permitted. Any breach or infringement will result in liability for damages. All rights reserved concerning patent or utility model application. © HAWE Hydraulik SE 2/12 D 7395 - SJ - 11-2013-1.1...
-
Page 3: Table Of Contents
Contents Overview of 2-way ow control valve type SJ...................... 4 Available versions, main data..........................5 Screw-in cartridge (basic version).......................... 5 Housing version..............................6 Parameters................................. 7 Dimensions................................ 9 Screw-in cartridge (basic version).......................... 9 Valve with housing...............................9 Mounting hole..............................9 Assembly, operation and maintenance recommendations..................10 Intended application............................ -
Page 4: Overview Of 2-Way Ow Control Valve Type Sj
Flow control valves are a type of ow valve. They generate a set constant ow rate, largely independently of the load. Type SJ ow control valves are screw-in valves. They can be integrated into the line system using housing. For purely pump circuits, the excess oil ow on the inow side must be discharged via a pressure-limiting valve. -
Page 5: Available Versions, Main Data
Response current Q from ... to (lpm) SJ 0 0.5 ... 0.9 0.25 ... 0.5 1.0 ... 1.6 1.6 ... 2.5 2.5 ... 4 4 ... 6.4 6.4 ... 10 10 ... 15 © HAWE Hydraulik SE D 7395 - SJ - 11-2013-1.1 5/12... -
Page 6: Housing Version
Table 2 Model (housing version) Flow rate setting Table 1 Type and response ow Type and size Table 1 Type and response ow Table 2 Model (housing version) Coding Model Circuit symbol © HAWE Hydraulik SE 6/12 D 7395 - SJ - 11-2013-1.1... -
Page 7: Parameters
+70°C. Pressure and volumetric ow Operating pressure = 315 bar Static overload nominal volume Approx. 2 x p Volumetric ow Chapter 2.1, "Screw-in cartridge (basic version)" Table 1 © HAWE Hydraulik SE D 7395 - SJ - 11-2013-1.1 7/12... - Page 8 Screw-in valve Type SJ 0..C = 35 g Housing version Type SJ 0.. G = 130 g SJ 0.. E = 130 g SJ 0.. F = 130 g © HAWE Hydraulik SE 8/12 D 7395 - SJ - 11-2013-1.1...
-
Page 9: Dimensions
Fitting seal G 1/4 NBR Fitting seal G 1/4 NBR SJ 0.. G 4.3 Mounting hole 60° bevels to help the thread seal slip in, only on type SJ 0(00) C © HAWE Hydraulik SE D 7395 - SJ - 11-2013-1.1 9/12... -
Page 10: Assembly, Operation And Maintenance Recommendations
Risk to life caused by sudden movement of the hydraulic drives when dismantled incorrectly! Risk of serious injury or death. Depressurise the hydraulic system. ■ Perform safety measures in preparation for maintenance. ■ © HAWE Hydraulik SE 10/12 D 7395 - SJ - 11-2013-1.1... -
Page 11: Operating Instructions
Conduct a visual inspection at regular intervals, but at least once per year, to check if the hydraulic connections are damaged. If external leakages are found, shut down and repair the system. Clean the device surface of dust deposits and dirt at regular intervals, but at least once per year. © HAWE Hydraulik SE D 7395 - SJ - 11-2013-1.1 11/12... -
Page 12: Other Information
6.1 Accessories, spare parts and separate components Housing coding For type Order number SJ 0 7395 017 SJ 01 ... 090 6920 110 E, F SJ 0.. 6920 210 b © HAWE Hydraulik SE 12/12 D 7395 - SJ - 11-2013-1.1... - Page 13 ■ Flow control valve type DSJ: D 7825 ■ HAWE Hydraulik SE Streitfeldstraße 25 | 81673 München | Postfach 80 08 04 | 81608 München | Germany Tel +49 89 379100-1000 | Fax +49 89 379100-91000 | info@hawe.de | www.hawe.com...
