- Page 1 OPERATING INSTRUCTIONS X-SERIES IONISING BARS WITH INTEGRATED REMOTE MONITOR...
-
Page 2: Table Of Contents
Contents Fraser static control equipment has been designed to give you many years of productive service. However, the science of static control has unique rules, which must be followed to allow the equipment to give a good return on your investment. -
Page 3: Introduction
Intelligence Control: Intelligence ON/OFF . Features and Benefits The 24 V DC power supply and remote monitoring The Fraser X-SERIES Range of bars is a high-performance family of products connections are made via an designed for short or long-range neutralisation of electrostatically charged M12 5-pin connector . -
Page 4: Safety
• The bar is intended for use in indoor factory environments only. It is not suitable connections and risk shocks to the operator and damage to the bar. Only use the for outdoor use . Fraser external Power Supply Unit (Part No. NEOS-PSU). © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN... -
Page 5: Positioning Of The Bar
Remember that static can be regenerated if the material passes over with the changing geometry so that you can neutralise the reel from the core to rollers or through a process after neutralising. A Static Meter such as the Fraser the finished diameter at the end of the wind. - Page 6 . © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN...
-
Page 7: Installation
Electrical connections to the bar are made via the M12 5-pole male connector on the endcap of the bar . If using the Fraser Anti-Static external Power Supply Unit (Part No. NEOS-PSU), connect the M12 cable from the Power Supply Unit to the bar and ensure that the supplementary ground wire is connected to the installation protective earth before connecting mains power. -
Page 8: Electrical Connections
The pin assignment and typical wire colours are given in the table below. The table refers to cables supplied by Fraser. Other cables can have different colour schemes. The 24 V supply connection (Pin 1, brown wire) must be fitted with a 2.5 A fuse. -
Page 9: Status Leds
Positive Intelligence. Scrolling right, green Active The speed is proportional to the level of intelligence. Negative Intelligence. Scrolling left, green Active The speed is proportional to the level of intelligence. © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN... -
Page 10: Operation, Maintenance And Safety
X-12F DISTANCE MODE RECOMMENDATIONS Control X-12F Neutralisation Distance Position Frequency 40 mm - 100 mm 50 Hz 80 mm - 150 mm 20 Hz 125 mm - 250 mm 1 Hz © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN... - Page 11 Position The bar operates in Manual mode . The bar operates in Intelligent mode . Warning! For X-33 Bars - Turn off the bar when changing the setting. © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN...
- Page 12 125 - 250 mm 250 - 500 mm 350 - 750 mm Distance to the target 5000 - 1,000 mm 750 - 1,500+ mm Distance to the target © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN...
-
Page 13: Commissioning
• Move the bar further from metal parts • Our Fraser cleaning kit (Part No. 81220) is ideal for use, alternatively a = X-33 toothbrush or nail brush can be used. Do not use a wire brush as this could damage the bar . -
Page 14: Remote Interface And Wiring Examples
WHITE = FAULT Caution! Voltage applied to the outputs must not exceed 28 V DC and must be of the GREY = DISABLE correct polarity . BLUE = 0 V/GROUND © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN... - Page 15 3-wire AC mains supply, Live + Neutral + Ground, and that the extra Earth wire from the power supply is bonded to Ground. With this optional supply an interface cable is required to access the remote monitor feature. © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN...
-
Page 16: Specification And Dimensions
Bar OK, ‘Clean Me’, Fault, Bar not powered Protection (All X-SERIES Models) Under-voltage/over-voltage lockout, surge protection, reverse supply polarity protection. Internal protection Over-temperature protection. HV supplies protected against overload. Signalling outputs protected against short-circuiting. © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN... -
Page 17: Certification And Ce Declaration Of Conformity
ABOVE 500mm ±0.75mm ANGLE OVERALL LENGTH = ACTIVE LENGTH 52.8 ALL DIMENSIONS IN MILLIMETRES © Fraser Anti-Static Techniques Ltd 2024 X-SERIES OI – Iss1 – EN TITLE SURFACE FINISHES TO BS1134 REVISION SPECIFICATION AND SYMBOLS TO BS308 ALL SHARP EDGES AND CORNERS TO BE REMOVED... -
Page 18: Spare Parts And Accessories
14. Spare Parts and Accessories 14. Spare Parts and Accessories A range of accessories to assist with installation and maintenance of the Bar is available from Fraser Anti-Static Techniques. Please contact your Technical Sales Liaison with any pricing and Item Picture Description Part No. - Page 19 For more information about static and to view the full range of our products, please visit www.fraser-antistatic.com Fraser Anti-Static Techniques Ltd Scotts Business Park, Bampton, Devon, EX16 9DN, UK +44 (0) 1398 331 114 sales@fraser-antistatic.co.uk www.fraser-antistatic.com © Fraser Anti-Static Techniques Ltd 2024 | X-Series OI - Iss.1 - EN...
