- Page 1 QUICK START GUIDE IONFIX PRO STATIC GENERATOR WITH REMOTE MONITORING AND CONTROL INTERFACE...
-
Page 3: Table Of Contents
Technical Specifications Troubleshooting Safety The Fraser IONFIX PRO has been designed in accordance with the safety requirements of EN 62368-1:2014. The high-voltage output of the generator is a Class 2 electrical energy source, as defined in EN 62368 1:2014. This means that it is capable of causing pain if contact is made with a body part, but is not likely to cause an injury requiring medical attention. -
Page 4: Introduction
Introduction This manual provides a brief installation and commissioning guide for the Fraser IONFIX PRO Static Generator product range (30 and 60 kV variants). Please refer to the full manual for information on all functions of the generator and detailed instructions for remote interfacing and machinery integration. - Page 5 • Current Limit +/- Buttons: Allow the output current limit level of the generator to be adjusted. • • 4-way keypad and OK Button: Used to access the generator configuration menu and change parameters. © Fraser Anti-Static Techniques Ltd 2017...
- Page 6 Operating the generator Power up the generator, using the main power switch. After a start-up message, the screen will show the voltage and current setpoint values (indicated by ‘SP’ after the values). • To adjust the output voltage, use the ‘Voltage +’ and ‘Voltage –‘ buttons. •...
-
Page 7: Remote Interface
Reserved, do not connect Reserved, do not connect Arc/Limit open collector Arc/Limit open emitter Operating open collector Operating open emitter Reserved, do not connect GND (0 V) Not connected Reserved, do not connect Not connected © Fraser Anti-Static Techniques Ltd 2017... -
Page 8: Technical Specifications
0-30 kV DC, 5 mA max. Output rating, 60 kV variants: 0-60 kV DC, 2.5 mA max. Output connector type: 4 x Fraser 30/60 kV tubular spring-contact HV connector. Remote interface connector: 25-pin subminiature D-type, female. Mating plug Amphenol L717DB25P or equivalent. -
Page 9: Troubleshooting
‘UNDER VOLTAGE’ shown on display All LEDs flashing Supply voltage too high. Check supply voltage. ‘OVER VOLTAGE’ shown on display All LEDs flashing Internal fault with generator. Contact distributor. Any other message shown on display © Fraser Anti-Static Techniques Ltd 2017... - Page 12 For more information about static and to view the full range of our products, please visit www.fraser-antistatic.com Scotts Business Park, Bampton, Devon, GB, EX16 9DN T + 44 (0) 1398 331114 F + 44 (0) 1398 331411 E sales@fraser-antistatic.co.uk W www.fraser-antistatic.com...
