  • Page 1 VT5500 INSTALLATION GUIDE THE UK'S MOST AWARD-WINNING CAMERA TELEMATICS COMPANY www.visiontrack.com...
  • Page 2: Table Of Contents

    Important Information Overview Required Tools What’s in the box VT5500 Details Pre-Installation Checks VT5500 Wiring Power Supply Antennas Camera Connections Positioning and Mounting Panic Button Cable Routing Commissioning Notes t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
  • Page 3: Important Information

    Approved Accreditation Bodies and may also affect the vehicle manufacturers warranty. Under no circumstances may any part of the product be installed inside the engine compartment area. t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
  • Page 4 Important Information: List of do’s and don’t’s when installing a VisionTrack MDVR. Power: All VisionTrack devices MUST be wired to their own power supply and not connected/shared to an existing power pickup point. We recommend that the vehicle power pickup points should be located using the vehicle manufactures instructions. *THIS MEANS YOU CANNOT USE ANOTHER TELEMATICS PROVIDERS POWER SUPPLY OR PICK UP POINTS TO POWER A VISIONTRACK DEVICE.
  • Page 5: Overview

    VT5500 5-CHANNEL FULL HD 1080P MOBILE DVR The VT5500 is a full HD 1080p ruggedised, 5-channel mobile digital video recorder (MDVR) designed for vehicle surveillance and monitoring, with built-in 4G connectivity, advanced video compression, GPS positioning technology for live tracking. The MDVR fully integrates with VisionTrack’s Platform and has as a built-in three-axis G-shock sensor as standard,...
  • Page 6: Required Tools

    Plastic Cutter Wire Cutter Wire Stripper Solder Wire Crimping Connectors Soldering Iron Crimping Tool Electrical Tape Multimeter Amalgamating Tape Round File Plastic Lever Heat Gun (Gas) Heatshrink Reinforced Tape t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
  • Page 7: What's In The Box

    VT5500 INSTALLATION GUIDE What’s in the box: VT5500 Mobile DVR VT5500 Mounting Arms and Screws S-VT5500 3G Antenna S-VT5500 GPS Antenna VT5500 Key S-VT5500 Power Input VT5500 Fuses t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
  • Page 8: Vt5500 Details

    GPS and 3G / 4G / Wi-Fi Power Input Alarm Trigger Cable Input Sensor & Serial Monitor Output Non AHD and AHD A/V OUT Input - A/V IN 4 IP Camera Input t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
  • Page 9: Pre-Installation Checks

    VT5500 INSTALLATION GUIDE Pre-Installation Checks: Please follow these checks before installation is started. Validate that the vehicle presented matches the vehicle details on the VisionTrack Service Portal. Take note of and document any damage to where the camera(s) will be fitted, e.g.
  • Page 10: Vt5500 Wiring

    VT408-AHD Left Side A/V IN 1 VT408-AHD Right Side A/V IN 2 VT646-AHD Rear A/V IN 3 Side-facing Cameras (VT408-AHD Image) Rear-facing Camera (VT646-AHD Image) Forward-facing Camera (VT-C20-IPC Image) t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
  • Page 11: Power Supply

    VT5500 INSTALLATION GUIDE Power Supply: The power connection for the VT5500 is simple, it consists of three wires and connections: • Permanent Power (12/24V) • Ignition ACC • Ground NOTE: Always test the wires with multimeter prior to making the connections.
  • Page 12: Antennas

    VT5500 INSTALLATION GUIDE Antennas: The VT5500 comes with two stand-alone antennas. One GPS and one 3G/4G GSM. These need to be installed covertly, i.e. behind panels, in the vehicle and connected to the DVR. The GPS antenna must be installed with the adhesive pad facing down.
  • Page 13: Camera Connections

    The rubber sheaths alone are not enough to make the connection waterproof. Amalgamating tape should also be used. This is particularly important for connections that are made outside the vehicle. t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
  • Page 14: Positioning And Mounting

    NOTE: The DVR has an internal accelerometer to measure harsh driving events so you must ensure that it is firmly secured in the vehicle. t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
  • Page 15: Panic Button

    The VT-PANIC button is connected to the VT5500 via the Alarm In/Out Cable as shown below. It should be enabled by default but must be checked during the commissioning call.
  • Page 16: Cable Routing

    Orange (Sensor In 6) VT-CP4 / RS232-RS485 Convertor Blue/Black (Sensor In 5) MIC (Voip and dial in accessory) Blue/White (Sensor In 6) NOTE: All Sensor In wires are voltage on/off (5-12V). t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
  • Page 17: Commissioning

    Otherwise it will not boot up. Start the engine and wait for 5 minutes and call the VisionTrack technical support team on 01246 225 858 to commission the device. Please follow the checklist below during the commissioning call with VisionTrack:...
  • Page 18: Notes

    VT5500 INSTALLATION GUIDE Notes: VisionTrack National Engineering Manager Steve Moseley | +44 7500 073299 | smoseley@visiontrack.com t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com...
