Summary of Contents for Veeder-Root 794380-333
- Page 1 Manual No: 576013-616 Revision: K Interstitial Liquid Sensor - Steel Tanks Installation Guide...
- Page 2 If “lost” equipment is delivered at a later date and is not needed, Veeder-Root will allow a Return to Stock without a restocking fee. Veeder-Root will NOT be responsible for any compensation when a customer chooses their own carrier.
-
Page 3: Table Of Contents
Table of Contents Introduction Contractor Certification Requirements ................1 Product Marking Information .....................1 Related Documents ....................1 Documents Required to Install Equipment .............1 Product Label Contents .................2 Safety Warnings .......................3 Safety Symbols .........................3 Sensor Description ......................4 Components Shipped ....................4 Models ........................4 Sensor States ......................4 Installation ...........................5 Appendix A: CCC Certification... -
Page 4: Contractor Certification Requirements
RELATED DOCUMENTS Documents Required to Install Equipment This intrinsically safe apparatus is only for use as part of a Veeder-Root Automatic Tank Gauging System (ATG Console with probes and sensors). To install intrinsically safe apparatus, use the specific control drawing that... -
Page 5: Product Label Contents
Interstitial Liquid Sensor Installation Guide Product Marking Information The control drawings contain information related to the correct installation of the overall intrinsically Safe System. This includes information such as maximum number of apparatus, specific apparatus allowed in the system, maximum cable lengths, references to codes, proper grounding and so on. Control drawings can be foundon the Internet at https://www.veeder.com/us/technical-document-library. -
Page 6: Safety Warnings
Interstitial Liquid Sensor Installation Guide Safety Warnings Safety Warnings To protect yourself and your equipment, observe the following warnings and important information: WARNING This product is to be installed and operated in the highly combustible environment of a gasoline storage tank where flammable liquids and explosive vapors may be present. FAILURE TO COMPLY WITH THE FOLLOWING WARNINGS AND SAFETY PRECAUTIONS COULD CAUSE DAMAGE TO PROPERTY, ENVIRONMENT, RESULTING IN SERIOUS INJURY OR DEATH. -
Page 7: Sensor Description
Sensor Description The Veeder-Root Interstitial Liquid Sensor detects the presence of liquid in the interstitial space of a double-wall tank. When liquid is detected, the sensor sends an alarm signal to the console. The console’s visual and audible built-in alarm indicators immediately tell you where the problem is, so you can quickly take action to help prevent serious safety and environmental problems. -
Page 8: Installation
Installation 1. Turn OFF power to the console. 2. Make sure no liquid is present in the annular space. Important! Do not install the sensor if any liquid is present in the annular space. Failure to comply will lead to an alarm. 3. -
Page 9: Figure 2. Sensor Field Wiring Diagram
Interstitial Liquid Sensor Installation Guide Sensor Description 7. Using wire nuts, connect the two-wire sensor cable to the field wires in the sensor junction box (Figure 2). Seal wire nuts with epoxy sealant following the instructions in Figure 3. From Seal-off Sensor –... -
Page 10: Appendix A: Ccc Certification
Appendix A: CCC Certification 本产品经认证符合 CNCA-C23-01: 2019《强制性产品认证实施规则 防爆电气》的要求。 The product ( s) i s veri f i ed and cert i f i ed accordi ng to C N C A -C 23-01: 2019 C hi na C om pul sory C I m pl em ent at i on Rul e on Expl osi on Prot ect ed El ectri cal Product.
