Model
CPU
Intel
Atom D525 Dual core Processor
®
OS
Genuine Windows
Chipset
Intel
ICH8M
®
VGA
NVIDIA
1x2G DDR2-800MHz
Memory
Support DDR2 800MHz, 2x SO-DIMM slots, Max. up to 4GB
320GB
HDD
Support 2.5'' SATA HDD
ODD
DVD Super Multi
Audio
7.1 Ch HD Audio with DTS
LAN
Gigabit LAN
Front I/O
2xUSB 3.0, 1xMIC, 1xHead Phone
Rear I/O
1 x HDMI, 1x D-Sub VGA, 1xDVI , 6xUSB 2.0, 1xS/PDIF
WiFi
802.11b/g/n
Remote
MCE Remote Controller
Controller
Power
65W/19V Adapter
Dimension
195 (W) x 70 (H) x 186 (L) mm
Volume(liters)
2.5L
Weight
1.7 KG
The specification is subject to change without notice. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
ION 3D 152D Series
7 Home Premium (Optional)
®
GT218 Graphics (with 512MB DDR3 Frame buffer memory)
®
ION 3D 152B Series
Intel
Atom D525 Dual core Processor
®
Genuine Windows
7 Home Premium (Optional)
®
Intel
ICH8M
®
NVIDIA
GT218 Graphics (with 512MB DDR3 Frame buffer memory)
®
1x2G DDR2-800MHz
Support DDR2 800MHz, 2x SO-DIMM slots, Max. up to 4GB
320GB
Support 2.5'' SATA HDD
BD Combo
7.1 Ch HD Audio with DTS
Gigabit LAN
2xUSB 3.0, 1xMIC, 1xHead Phone
1 x HDMI, 1x D-Sub VGA, 1xDVI , 6xUSB 2.0, 1xS/PDIF
802.11b/g/n
MCE Remote Controller
65W/19V Adapter
195 (W) x 70 (H) x 186 (L) mm
2.5L
1.7 KG
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ASROCK ION 3D SERIES
Summary of Contents for ASROCK ION 3D SERIES
- Page 1 195 (W) x 70 (H) x 186 (L) mm Volume(liters) 2.5L 2.5L Weight 1.7 KG 1.7 KG The specification is subject to change without notice. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
-
Page 2: Hdmi Connector
ASRock MCE Remote Controller is exclusively able to power on the system at the first Allows two-way transmission direction, WiFi 802.11n provides a wider bandwidth time of the plug-in of AC power. It prides itself on delivering a fast, intuitive, convenient to cover longer distance coverage. - Page 3 ASRock ION 3D HTPC Series deliver the terri c viewing experience. It has a powerful build-in Next-Generation ION graphics which supports 3D display, allowing user to enjoy a vivid 3D entertainment experience! With its amazing 3D display capability, you are able to experience the highest quality movie like never before!
- Page 4 PC games. All you have to do is just to install the ASRock AIWI utility either from ASRock official website or ASRock software support CD to your ION 3D, and also download the AIWI Free from App store to your iPhone/iPod touch.
