- Page 1 TYMOOV Solar 5 SO / 10 SO Photovoltaic panel and battery...
- Page 2 - Keep the instructions for this product so you can refer back to them in future. - Delta Dore battery packs are only designed for TYMOOV Solar motors. - Verify that solar powered roller shutters meet the conditions of the «Renewable Energy»...
- Page 3 1/ Technical characteristics Solar panel • Voltage <25 V • Class III insulation • Max. power: 3.9 W • Rated current: 217 mA +/-10% • Protection rating: IP x4 • Operating temperature: -20°C to +60°C - Storage temperature: -20°C to +70°C Battery - Rated voltage: 12 V •...
- Page 4 2/ Photovoltaic solar panel installation Installation instructions: The entire surface of the solar panel must always be positioned on the shutter casing (or nearby using an extension) so that it is exposed to the most favourable sunlight. Be sure to take into account the proximity to various obstacles that may generate permanent shade (fence walls, trees, gutters, balconies, overhanging roofs, etc.).
-
Page 5: Installation
3/ Installing the batt ery 3.1 Installati on The electrical installati on instructi ons are set by nati onal standards or standard IEC60364. The batt ery must be installed inside the roller shutt er casing and att ached using fi xings ref. 7011749 for the 1200mAh pack or ref. - Page 6 www.deltadore.com...
