TECHNICAL SPECIFICATION

Power supply
Working frequency
Amplifier linearity
"A" / "B" antenna input : 8+8 BNC type connector
antenna output
Impedance
Input/output Gain
Noise Figure
Antenna booster
powering
Configuration/monitor
interfaces
Display
Dimension
Weight
13
AC connector 90÷264Vac / T2A, 47÷63Hz
: DC connector 10÷ 28 VDC (fuse protected) 12A max (optional)
Max power consumption 120W
: 150 ÷ 1160 MHz
: ± 1 dB (typical)
: 8 BNC type connector
50 Ω
6 dB (Combiner 8:1), OIP3=30dBm typ.
: 0 dB (Combiner 8:4), OIP3=24dBm typ.
6 dB (2 Combiners 4:2), OIP3=30dBm typ
5.5dB (each channel)
+12Vcc / 800mA MAX.(ports 1A, 1B and 5A, 5B)
:
+12Vcc / 230mA MAX.(other ports)
: 10/100 Base TX Ethernet port
: 64 x 256 OLED (yellow)
: Standard rack (aluminum) 19" / 1U.
: 4,4 Kg
