Harman JBL PROFESSIONAL GSB8 Installation Manual

GSB8 & GSB12 In-Ground Landscape Subwoofers
CAUTION: Installation must be done by qualified persons using safe
The installer is responsible for proper selection and use of hardware and to
Wire Connection
CABLE-- The GSB speakers come with a captive multi-conductor 1-meter-long cable with bare-wire ends for connection via an
•
external installer-provided weather-proof junction box.
o Connection Method – Use professional wire nuts or other safe, long-term connectors that are appropriate for the
installation conditions and that are sized properly for wire gauge(s) and for the number of wires to be connected
together in the connector.
Installation Guide
installation standards.
install the speakers in a safe and durable manner.
CABINET
HANDLES (x2)
Important: Cut off all unused wires in a way that ensures that none of them will short to any of the
•
other wires.
Δ
Code Requirements -- Typical wiring entails protected connections inside installer-provided water-
•
proof junction box, with cable entering junction box via water-tight fitting that is sized appropriately for
wire jacket diameter (see below). However, always wire in accordance with code requirements.
PORT CAP
PORT
CABLE
BASE PLATE with 4 x EDGE TABS
