Pelsis Insect-O-Cutor Halo Shades Manual

Please read these instructions carefully and store in a safe place for
future reference.
HALO SHADES
Insect-O-Cutor
As part of the ®
Shades are a versatile professional flykiller which utilises highly effective
UV tubes and is designed for use with a high specification glupac
glueboard. Halo Shades are available in a slimline model which can be
wall or desk mounted.
CONTENTS OF PACKAGE
- 1 x Halo Shades flykiller
- 1x Glupac ® pheromone impregnated glueboard
- 1 x Mains cable
- 1 x Removable aluminium debris tray
- 2 x High powered UV tubes (Fitted)
- 4 x Screws and wall plugs
- 2 x Vertical mount glueboard retaining pins
- 2 x Desk mount feet and feet fixing pins
- 1 x Servicing key fob and mains cable tidy tie wrap wire
WARNING - THIS APPLIANCE MUST BE EARTHED (CLASS 1)
INSECT CONTROL PRODUCTS
Halo Shades utilise high powered ultra violet tubes to attract flying insects
and retains the caught insects on a pheromone impregnated glueboard
for inspection or hygienic disposal.
WARNING
Halo Shades are not to be used by children or persons with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction.
Children should be supervised to ensure they do not play with the
appliance.
If the mains cable is damaged it must be replaced by a specialist mains
cable available from Pelsis Ltd or your supplier.
Not suitable for applications where potentially explosive environments
may exist.
POSITIONING AND GUIDANCE FOR USING HALO SHADES
THIS UNIT IS FOR INDOOR USE ONLY.
Halo Shades should ideally be fixed around two meters above the
ground, preferably in the darkest place within the area to be protected.
ENSURE THERE IS A MINIMUM OF 550mm BETWEEN ONE SIDE OF HALO
SHADE AND THE ADJACENT SURFACE, TO PROVIDE ENOUGH SPACE TO
INSERT THE GLUEBOARD (SEE MOUNTING INSTRUCTIONS.) Do not position
the unit close to windows, skylights or other sources of light, or where it
may be obscured by furniture, doors or other obstacles. Ideally, Halo
Shades should be visible from every part of the area to be protected.
Halo Shades should ideally be in operation for 24 hours a day, ensuring
your premises are kept free of flying insects. Insects are most attracted
to Halo Shades at night when there is no competition from daylight or
other light sources.
GUARANTEE
Halo Shades has a three year guarantee and if maintained as
recommended in these instructions should continue to work for many
years.* Use of non-approved consumables may invalidate the
guarantee. Ensure genuine glupac
with this product.
*Excludes tubes, glueboards and starters. Does not cover breakdown due to misuse, incorrect
operation or use in an incorrect application
brand of insect control products, Halo
® glueboards are used in conjunction
INSTALLATION
INSTALLATION SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY.
To ensure Halo Shades reach you in perfect condition, a protective film
covers the aluminium door. Remove this film before use.
For wall mounting, use the supplied wall mounting plugs and screws,
®
making sure correct wall plugs are used for specialist mounting materials,
such as plasterboard.
Wall Mounting - Halo Shades can be wall mounted horizontally or
vertically. For horizontal mounting use the two inside cut outs on the
debris tray to mark the correct wall mounting points. For vertical wall
mounting, insert the two large plastic glueboard retaining pins in the two
holes on the glueboard runners, to stop the glueboard falling out of the
unit. (Supplied in the fixing kit)
Desk mounting - Halo Shades can be installed onto a horizontal surface
by using the two supplied black steel feet. The feet can be secured in
position by using the two large plastic fixing pins. (Supplied in the fixing
kit)
Once Halo Shades are installed in position, fit the glupac
place as described in the glueboard replacement section of this
document. Use the removable mains lead and plug to connect the
Halo Shades to an appropriate power supply. Use the supplied black
mains cable tidy tie wrap wire to hide any excess mains cable behind
the product if required.
To maximise the effectiveness of Halo Shades in catching flying insects,
the top of the product has light apertures to increase the UV irradiance
emitted from the product. However, these apertures can be covered to
protect the glueboard from debris and prolong its life, by simply sliding
the reflective aluminium cover forward.
CLEANING
CLEANING SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY,
AFTER ENSURING THAT THE UNIT IS DISCONNECTED FROM THE MAINS
SUPPLY.
It is recommended that cleaning is carried out regularly when the
glueboard is replaced. Once the glueboard is removed, the unit should
be thoroughly wiped down with a damp cloth, removing any build up of
dirt. Ensure the unit is completely dry before reconnecting it to the
power supply.
Professional Glueboard Insect Control
Wall Mounting
Light Apertures &
Cable Management
® glueboard in
