Installing the Tiller Pin
The supplied tiller bolt is suitable for a quadrant or tiller arm thickness of 12 to 16 mm (0.47 to 0.63 in.).
1 Drill a 12.2 mm (0.48 in.) hole in the quadrant or tiller arm
2 Place the tiller bolt
nut .
It is recommended to apply LOCTITE 638, or an equivalent retaining compound, to the tiller bolt where it
passes through the quadrant or tiller arm.
3 Place the drive unit rod
4 Fasten the rod to the tiller bolt with the other M12 washer
Connecting the Drive Unit to a Garmin Autopilot
The cables connected to the drive unit should not be cut, because cutting the drive-unit cables voids your
warranty.
Consult the installation instructions provided with your Garmin autopilot to install the autopilot components
and to connect the drive unit to the correct component.
into the quadrant or tiller arm, and secure it with the M12 washer
on the tiller bolt.
(not included) for the tiller bolt.
and the locking pin
NOTICE
and the M12 lock
.
