Hydrel Tierra IGF6 Installation Manual

Installation Guide
.READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER
• To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/abrasions, and other
hazards please read all warnings and instructions included with and on the fixture box and all fixture labels.
• Before installing, servicing, or performing routine maintenance upon this equipment, follow these general precautions.
Installation and service of luminaires should be performed by a qualified licensed electrician.
•
• Maintenance of the luminaires should be performed by person(s) familiar with the luminaires' construction and operation and
any hazards involved. Regular fixture maintenance programs are recommended.
• It will occasionally be necessary to clean the outside of the refractor/lens. Frequency of cleaning will depend on ambient dirt
level and minimum light output which is acceptable to user. Refractor/lens should be washed in a solution of warm water and
any mild, non-abrasive household detergent, rinsed with clean water and wiped dry. Should optical assembly become dirty on
the inside, wipe refractor/lens and clean in above manner, replacing damaged gaskets as necessary.
• DO NOT INSTALL DAMAGED PRODUCT! This luminaire has been properly packed so that no parts should have been damaged
during transit. Inspect to confirm. Any part damaged or broken during or after assembly should be replaced.
• Recycle: For information on how to recycle LED electronic products, please visit www.epa.gov.
These instructions do not purport to cover all details or variations in equipment nor to provide every possible contingency to
•
meet in connection with installation, operation, or maintenance. Should further information be desired, or should particular
problems arise which are not covered sufficiently for the purchaser's or owner's purposes, this matter should be referred to
Acuity Brands Lighting, Inc.
!
• Disconnect or turn off power before installation or servicing.
• Verify that supply voltage is correct by comparing it with the
luminaire label information.
• Make all electrical and grounded connections in accordance
with the National Electrical Code (NEC) and any applicable
local code requirements.
• All wiring connections should be capped with UL approved
recognized wire connectors.
!
• Wear gloves and safety glasses at all times when removing
luminaire from carton, installing, servicing or performing
maintenance.
• Avoid direct eye exposure to the light source while it is on.
NOTE: HYDREL RESERVES THE RIGHT TO MODIFY SPECIFICATION WITHOUT NOTICE.
Any dimension on this sheet is to be assumed as a reference dimension:
"Used for information purposes only. It does not govern manufacturing or inspection requirements." (ANSI Y14.5-1973)
Architectural In-Grade
Model IGF6
INSTALLATION
WARNING
RISK OF ELECTRIC
CAUTION
WARNING
RISK OF BURN
!
• Disconnect or turn off power before installation or servicing.
• Verify that supply voltage is correct by comparing it with the
luminaire label information.
• Make all electrical and grounded connections in accordance
with the National Electrical Code (NEC) and any applicable
local code requirements.
• All wiring connections should be capped with UL approved
recognized wire connectors.
!
• Keep combustible and other materials that can burn, away
from lamp/lens.
• Do not operate in close proximity to persons, combustible
materials or substances affected by heat or drying.
