Frame Kit
Greensmaster
Model No. 140-9344
Installation
Preparing the Machine
1.
Park the machine on a level surface.
2.
Engage the parking brake.
3.
Shut off the engine.
1. Frame
© 2021—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
®
1021 or Flex
Removing the Existing
Frame and Installing the
New Frame
To remove the existing frame and install the new
frame, refer to the instructions in the traction
unit Service Manual for removing and installing
components that connect to the frame, including the
drum drive, transmission, and cutting unit, among
other components. Refer to
(page 2)
to install the handle to the frame.
Figure 1
Greensmaster frame and the surrounding
components.
Figure 1
Register at www.Toro.com.
™
1021 Mower
Installation Instructions
for instructions to use loose parts in this kit
shows an overview of the fixed-head
Original Instructions (EN)
Printed in the USA
All Rights Reserved
Form No. 3448-690 Rev A
Installing the Handle
g368081
*3448-690*
