Form No. 3351–417
14-38Z, 16-42Z, or 17-42Z
)
TimeCutter
Z with Side Discharge Mower
Model No. 74301—Serial No. 240000894 and Up
Model No. 74330—Serial No. 240001180 and Up
Model No. 74350—Serial No. 240000179 and Up
Operator's Manual
Register your product at www.Toro.com
Original Instructions (EN)

Advertisement

Table of Contents
loading

Related Manuals for Toro 14-38Z

Summary of Contents for Toro 14-38Z

  • Page 1 Form No. 3351–417 14-38Z, 16-42Z, or 17-42Z TimeCutter Z with Side Discharge Mower Model No. 74301—Serial No. 240000894 and Up Model No. 74330—Serial No. 240001180 and Up Model No. 74350—Serial No. 240000179 and Up Operator’s Manual Register your product at www.Toro.com...

  • Page 2: Table Of Contents

    Operating the Power Take Off (PTO) ..Dealer or Toro Customer Service and have the model and The Safety Interlock System ....

  • Page 3: Safety

    serial numbers of your product ready. Figure 1 illustrates Safety the location of the model and serial numbers on the product. This machine meets or exceeds the B71.1–1998 specifications of the American National Standards Institute, in effect at the time of production. However, improper use or maintenance by the operator or owner can result in injury.
  • Page 4 Be alert, slow down and use caution when making Children turns. Look behind and to the side before changing Tragic accidents can occur if the operator is not alert to the directions. presence of children. Children are often attracted to the Use extra care when loading or unloading the machine machine and the mowing activity.

  • Page 5: Toro Riding Mower Safety

    Mower blades are sharp and can cut. Wrap the blade(s) or wear gloves, and use extra caution when servicing them. Use only genuine Toro replacement parts to ensure that original standards are maintained. Toro Riding Mower Safety The following list contains safety information specific to Toro products or other safety information that you must know that is not included in the ANSI standards.

  • Page 7: Slope Chart

    Slope Chart...

  • Page 9: Safety And Instruction Decals

    Replace any decal that is damaged or lost. Note: If needed, a Decal Kit, 106–8708, and French manual are available. Order the Decal Kit from the Toro Parts Department and the French manual from either the Toro Parts Department or online at www.toro.com.
  • Page 10 106-8743 1. Height of cut 106-7026 Battery Symbols 106-8716 Some or all of these symbols are on your battery. 1. Explosion hazard 7. Wear eye protection; explosive gases can 2. No fire, open flames, or cause blindness and smoking. other injuries 3.

  • Page 11: Gasoline And Oil

    Gasoline and Oil Recommended Gasoline Warning Use UNLEADED Regular Gasoline suitable for automotive use (87 pump octane minimum). Leaded regular gasoline Gasoline is harmful or fatal if swallowed. may be used if unleaded regular is not available. Long–term exposure to vapors can cause serious injury and illness.

  • Page 12: Operation

    Operation Controls Become familiar with all of the controls (Fig. 3 and 4) Note: Determine the left and right sides of the machine before you start the engine and operate the machine. from the normal operating position. Think Safety First Please carefully read all of the safety instructions and decals in the safety section.

  • Page 13: Starting And Stopping The Engine

    Starting and Stopping the Engine Starting the Engine 1. Sit down on the seat and move the motion controls to m–4268 the brake position. Figure 7 2. Move the PTO (power take off) to Off (Fig. 5). 1. Off 3. Start 2.

  • Page 14: The Safety Interlock System

    3. While sitting on the seat, move the PTO to Off, and lock the motion control levers in neutral. Start the engine. While the engine is running, move the motion control levers to the center, unlocked position, engage the PTO, and rise slightly from the seat; the engine should stop.

  • Page 15: Stopping The Machine

    Backward 1. Move the levers to the center, unlocked position. 2. To go backward, slowly pull the motion control levers rearward (Fig. 9). To go straight, apply equal pressure to both motion control levers (Fig. 9). To turn, release the pressure on the motion control lever 4–1/2 inch (114 mm) toward the direction you want to turn (Fig.

  • Page 16: Positioning The Seat

    Positioning the Seat The seat can move forward and backward. Position the seat where you have the best control of the machine and are most comfortable. 1. Raise the seat and loosen the adjustment knobs (Fig. 12). 2. Move the seat to the desired position and tighten the knobs.

  • Page 17: Adjusting The Footrest

    Removing and Installing the Engine Hood 1. To remove the hood, loosen the knobs and then pull the hood back and up (Fig. 16). m–6480 m–7276 Figure 14 1. Lever position for pushing 2. Lever position for the machine operating the machine Figure 16 1.

  • Page 18: Tips For Mowing Grass

    If a blade is Mowing Direction damaged or worn, replace it immediately with a genuine Toro replacement blade. Alternate mowing direction to keep the grass standing straight. This also helps disperse clippings which enhances...

  • Page 19: Maintenance

    Maintenance Note: Determine the left and right sides of the machine from the normal operating position. Recommended Maintenance Schedule Maintenance Service Maintenance Procedure Interval Check the engine oil level. Each use Check the safety system. Clean the mower housing. After first 5 hours Change the engine oil.

  • Page 20: Servicing The Engine Oil

    Servicing the Engine Oil Check the oil level daily or after every 8 hours. Change the oil after the first 5 operating hours and every 50 operating hours thereafter. Oil Type: Detergent oil (API service SF, SG, SH, SJ, or higher) Crankcase Capacity: 48 oz./1-1/2 qt.

  • Page 21: Servicing The Air Cleaner

    3. Disengage the PTO and set the parking brake. 2. Remove the old filter and wipe the filter adapter gasket surface (Fig. 21). 4. Stop the engine, remove the key, and wait for all moving parts to stop before leaving the operating 3.

  • Page 22: Servicing The Spark Plug

    Important Replace the foam element if it is torn or worn. Cleaning the Paper Element: 1. Lightly tap the element on a flat surface to remove dust and dirt. 2. Carefully clean the rubber seal on the paper element to prevent debris from entering the engine.

  • Page 23: Servicing The Cutting Blades

    Check the cutter blades daily for sharpness, and for any wear or damage. File down any nicks and sharpen the blades as necessary. If a blade is damaged or worn, replace it immediately with a genuine Toro replacement blade. For m–6419 convenient sharpening and replacement, you may want to Figure 24 keep extra blades on hand.
  • Page 24 (Fig. 27). Measure from a level surface to the the machine, use genuine Toro replacement blades. cutting edge, position A, of the blades (Fig. 27). Note Replacement blades made by other manufacturers may this dimension.

  • Page 25: Greasing And Lubrication

    3. Clean the grease fittings with a rag. Make sure to scrape any paint off of the front of the fitting(s). 4. Connect a grease gun to the fitting. Pump grease into the fittings until grease begins to ooze out of the m–1854 bearings.

  • Page 26: Servicing The Battery

    Servicing the Battery Warning Warning Incorrect battery cable routing could damage the tractor and cables causing sparks. Sparks can CALIFORNIA cause the battery gasses to explode, resulting in personal injury. Proposition 65 Warning Always disconnect the negative (black) battery Battery posts, terminals, and related accessories cable before disconnecting the positive (red) contain lead and lead compounds, chemicals cable.
  • Page 27 5. Slide the red terminal boot onto the positive (red) 3. Remove the vent caps from the battery (Fig. 34). battery post. 4. Slowly pour distilled water into each battery cell until 6. Secure the battery with the hold-down (Fig. 33). the electrolyte level is up to the Upper line (Fig.

  • Page 28: Draining The Fuel Tank

    Draining the Fuel Tank Replacing the Fuel Filter Replace the fuel filter after every 100 operating hours or Danger yearly, whichever occurs first. Never install a dirty filter if it is removed from the fuel line. In certain conditions, gasoline is extremely 1.

  • Page 29: Adjusting The Front-To-Rear Blade Slope

    2. Move the motion control levers to the brake position, stop the engine, remove the key, and wait for all moving parts to stop before leaving the operating position. 3. Check the air pressure of all four tires. If needed, adjust to the recommended inflation;...
  • Page 30 4. Check and adjust the side-to-side blade level if you m–6427 have not checked the setting; refer to Leveling the Mower from Side-to-Side, page 28. 5. Measure the length of the rod extending out of the adjusting block on the sides of the chassis (Fig. 41). 6.

  • Page 31: Inspecting The Belts

    Inspecting the Belts Inspect all belts every 100 hours. Check the belts for cracks, frayed edges, burn marks, or any other damage. Replace damaged belts. Replacing the Mower Belt Squealing when the belt is rotating, blades slipping when cutting grass, frayed belt edges, burn marks, and cracks are signs of a worn mower belt.

  • Page 32: Installing The Mower

    2. Move the motion control levers to the brake position, stop the engine, remove the key, and wait for all moving parts to stop before leaving the operating position. 3. Slide the mower under the tractor. 4. Lower the height-of-cut lever to the lowest position. 5.

  • Page 33: Washing The Underside Of The Mower

    Washing the Underside of the Warning Mower A broken or missing washout fitting could expose After each use, wash the underside of the mower to prevent you and others to thrown objects or blade contact. grass buildup for improved mulch action and clipping Contact with blade or thrown debris can cause dispersal.
  • Page 34 Important The grass deflector must be spring loaded in the down position. Lift the deflector up to test that it snaps to the full down position. m–6461 Figure 49 1. Grass deflector 5. Nut, 3/8 inch 2. Grass deflector bracket 6.

  • Page 35: Wiring Diagram

    Wiring Diagram...

  • Page 36: Cleaning And Storage

    Cleaning and Storage crank the engine and distribute the oil inside the cylinder. Install the spark plug(s). Do not install the wire on the spark plug(s). 1. Disengage the PTO, set the parking brake, stop the engine, and remove the key. 12.

  • Page 37: Troubleshooting

    Troubleshooting Problem Possible Causes Corrective Action The engine overheats. 1. The engine load is excessive. 1. Reduce ground speed. 2. The oil level in the crankcase is 2. Add oil to the crankcase. low. 3. The cooling fins and air 3.
  • Page 38 Problem Possible Causes Corrective Action The engine loses power. 1. The engine load is excessive. 1. Reduce ground speed. 2. The air cleaner is dirty. 2. Clean the air cleaner element. 3. The oil level in the crankcase is 3. Add oil to the crankcase. low.
  • Page 39 Problem Possible Causes Corrective Action The blades do not rotate. 1. The drive belt is worn, loose or 1. Install a new drive belt. broken. 2. The drive belt is off of the 2. Install the drive belt and check pulley.

  • Page 40: The Toro Total Coverage Guarantee

    If for any reason you are dissatisfied with your Distributor’s service or have difficulty obtaining guarantee information, contact the Toro importer. If all other remedies fail, you may contact us at Toro Warranty Company.
