- Page 1 User Manual AmbiColour Smart TV Backlight LED Strip CSH-LTVSY-279...
-
Page 2: What's In The Box
WHAT’S IN THE BOX • TV backlight box • 6m LED light strip • 1m HDMI cable • Power adaptor • User manual What you will need: • TV • External device with HDMI output • Smartphone or tablet with Bluetooth and connected to 2.4GHz band Wi-Fi network •... - Page 3 OVERVIEW 1. Power button 2. Wi-Fi connection status indicator 3. HDMI In 4. HDMI Out 5. USB port for light strip 6. Power input 7. Microphone (on the front panel)
-
Page 4: Installation
⚠ Ensure back of the TV is free of dust and water before installing. 2. Connect cables. Plug in: • An HDMI cable from the external device (gaming console, set top box, DVD/Blu-Ray player) to the HDMI IN port on the backlight box. - Page 5 TV. • The USB jack on the light strip to the LIGHT BELT port. 3. Connect the power adapter to a power source and press the Power button on the backlight box to turn on the lights.
- Page 6 CONNECT WITH THE APP 1. Get the app. 2. Register or login to app.
- Page 7 CONNECT WITH THE APP continued... 3. Recommended app settings. 4. Turn on Bluetooth and Wi-Fi on your smartphone. Make sure you are connected to a 2.4GHz Wi-Fi access point. Only 2.4G Wi-Fi networks are supported...
- Page 8 CONNECT WITH THE APP continued... 5. Connecting lights to app. If light not flashing, hold down power button until light blinks rapidly to enter pairing mode. AmbiColour Smart TV Backlight LED Strip Connect Smarthome AmbiColour Smart TV Backlight LED Strip...
- Page 9 CONNECT WITH THE APP continued... 6. Using lights with the app. AmbiColour Smart TV Backlight LED Strip AmbiColour Smart TV Backlight LED Strip...
- Page 10 CONNECT WITH THE APP continued... 7. Removing light strip from the app. AmbiColour Smart TV Backlight LED Strip AmbiColour Smart TV Backlight LED Strip SCROLL DOWN...
-
Page 11: Troubleshooting
TROUBLESHOOTING THE LIGHT STRIP DOES NOT APPEAR ON THE APP: • If the lights are not blinking rapidly, hold down the power button until the lights flash rapidly to reset it. • Ensure Bluetooth and Wi-Fi are enabled on your smartphone. •... - Page 12 TROUBLESHOOTING continued... and 5GHz bands. Usually, there will be an option to configure each band individually. Change the SSID for one or both bands to make them distinct. For instance, “NetworkName_2.4GHz” and “NetworkName_5GHz”. • If you are using Telstra Smart Modem, refer to the following guide to resolve band steering issues: https://www.laserco.com.au/Telstra- NBN-Gen-Smart-Modem-Fix...
-
Page 13: Warnings And Cautions
WARNINGS AND CAUTIONS 1. For indoor use only. 2. Ensure back of the TV is free of dust and water before installing. 3. Use the backlight box in a dry and ventilated place, away from damp or humid environments. 4. It is normal for the control box to get hot after a few hours of operations. -
Page 14: Specifications
SPECIFICATIONS Input: AC 100-240V 50/60Hz Power adaptor Output: DC 24V 2A (max.) Dimensions of the L194*W163*H68mm control box Length of the 6m (suitable for up to light strip 85” TV) Length of the HDMI cable Wi-Fi Standard 802.11 b/g/n Wi-Fi Frequency 2.4GHz 3840x2160@60Hz;... - Page 15 Visit our website www.connectsmarthome.com.au Check us out at...
