- Page 1 User Manual, Operating Instructions and Specifications PrepMaster Mono Service Scraper Kit For PE Pipes ELECTROFUSION • • • • INNOVATION DESIGN MANUFACTURE SUPPLY...
- Page 2 User Manual, Operating Instructions and Specifications PrepMaster Mono Service Scraper Kit for PE Pipe Description: PrepMaster Mono Service Scraper Kit Diameter Size Range: Ø 20-32mm standard kit Ø 20-63mm optional Product Code: 700-000183 P a g e...
-
Page 3: Table Of Contents
Contents Product description ……………………………………………………………………………… Page 3 Health and Safety Introduction …………………………………………………………….. Page 4 Health and safety Information……………………………………………………………….. Page 4 Photo gallery ………………………………………………………………………………………. Page 5 Schematic parts drawing ………………………………………………………………………. Page 6 Parts list and component part numbers …………………………………………………. Page 7 Specifications ……………………………………………………………………………………… Page 8 Operating instructions …………………………………………………………………………. -
Page 4: Product Description
Cutter Bar; the Standard being for normal pipe scraping and the Chamfered offering scraping access for Top Tee outlets where clearance is much tighter. The Hy-Ram PrepMaster Mono range of scraping tools incorporate a hardened steel blade to give a controlled depth of cut over the range of pipe diameters. -
Page 5: Health And Safety Introduction
Caution: Only use the tool for the purpose of its design and on pipes within the specified diameters/SDR’s. Caution: The cutter blade spring tension applied by turning the Cam is factory set and must not be tampered with or adjusted in anyway without prior consent from Hy-Ram or an authorised dealer. P a g e... -
Page 6: Photo Gallery
Photo Gallery Cutter Bar (5) Cam (4) Feed Screw Assy (2) Handle (3) Standard Cutter Bar End (11) Tapered Cutter Bar End (12) 4-Sided Blade (16) 1-Sided Blade (17) Standard Cutter Bar End assembled onto Cutter Bar Feed Screw set for 32mm diameter pipe Mandrel assembled... -
Page 7: Schematic Parts Drawing
Schematic Parts drawing P a g e... -
Page 8: Parts List And Component Part Numbers
Parts list and component part numbers Item Part No: Description 111-045-000317 20-63mm PREPMASTER MONO SERVICE SCRAPER BODY 111-400-000119 FEED SCREW ASSY 111-171-000154 HANDLE 111-073-000002 023-000347 CUTTER BAR SCRW-M8x16mmCAPBZP HEX SOCKET CAP HEAD; M8x16mm BZP SCRW-M6x16mmBHSBZP HEX SOCKET BUTTON HEAD; M6x16 DOWL-4mmx28mm-TypeB DOWEL: Ø4 SPRI-LC 045C 04M... -
Page 9: Specifications
Plastic pipes and fittings – Equipment for fusion jointing polyethylene systems. (Note – this specification is mainly for control units) Note: Hy-Ram Engineering Co. Ltd. operate a policy of continual improvement and therefore reserves the right to modify product specifications without notice... -
Page 10: Operating Instructions
Operating Instructions 1. Check the pipe for any damage or abrasions that may be detrimental to the performance of the joint. Ensure the pipe ends to jointed are cut square to the axis and burrs removed. If required, wash down the pipe ends in excess of the area to be scraped to remove traces of dirt or mud. If using wet wipes, ensure they are in compliance with the relevant specification. -
Page 11: Ukca / Ec Declaration Of Conformity
Modifications to the equipment without prior written approval by the undersigned will render this declaration null and void. For and on behalf of the manufacturer: Being a nominated person appointed by the manufacturer and employed by Hy-Ram Engineering Co Ltd]. Signature: ……………………………………………………………….. -
Page 12: Certificate Of Calibration
The product must be accompanied by written evidence of the date of purchase (see also the form at the rear of this document). Hy-Ram will not be responsible for any loss or damage incurred in connection with the return of the product. - Page 13 In no event will Hy-Ram or its authorised dealers be liable for any loss of profits or special, consequential, or incidental damages even if such damages result from negligence or other fault.
- Page 14 For Sales, Hire and Repair support contact our admin team or scan the QR code for further details www.hyram.com +44 (0) 1623 422982 enquiries@hyram.com Head Office Mansfield (Hire & Repair) Bury (Hire & Repair) Enfield (Hire & Repair) Pelham Street Unit 5 Unit 18 Unit 2...
