- Page 1 User Manual, Operating Instructions and Specifications Range of PatchMaster Multi Mechanical Pipe Scraping tools for PE Pipe ELECTROFUSION • • • • INNOVATION DESIGN MANUFACTURE SUPPLY...
- Page 2 User Manual, Operating Instructions and Specifications PatchMaster Mechanical Pipe Scraping tools for PE Pipe Description Product code PatchMaster Multi: 20 – 63 mm Diameter 700-000185 PatchMaster Multi: 75 – 180 mm Diameter 700-000186 PatchMaster Multi: 90 – 315 mm Diameter 700-000187 P a g e...
-
Page 3: Table Of Contents
Contents Product description ……………………………………………………………………………… Page 3 Health and Safety Introduction …………………………………………………………….. Page 3 Health and safety Information……………………………………………………………….. Page 4 Photo gallery ……………………………………………………………………………………….. Page 5 Schematic parts drawing ……………………………………………………………………….. Page 6-7 Parts list and component part numbers …………………………………………………… Page 8-9 Specifications ……………………………………………………………………………………….. Page 10 Operating instructions ……………………………………………………………………………. -
Page 4: Product Description
PatchMaster Multi: 90 – 315 mm Diameter 700-000187 The Hy-Ram PatchMaster Multi range of scraping tools incorporate a hardened steel blade to give a controlled depth of cut over the range of pipe diameters. The tools remove a layer in the order of 0.20 - 0.30mm thick from the outer surface of the pipe. -
Page 5: Health And Safety Introduction
Caution: Only use the tool for the purpose of its design and on pipes within the specified diameters/SDR’s. Caution: The cutter blade spring force onto the pipe is factory set and must not be tampered with or adjusted in anyway without prior consent from Hy-Ram or an authorised dealer. P a g e... -
Page 6: Photo Gallery
Photo Gallery Knob (7a) Top Carriage Assy (?) Knob (7b) Adjustment Pillar (4) 4-Sided Blade (12) Knob (7c) Bottom Carriage Assy (8) Wheel (10) Axle (9) Circlip (11) Knob (7a) Revolving Grip (3) Top Carriage Assy (1) Knob (7b) 4-Sided Blade (12) Adjustment Pillar (4) Bottom Carriage Assy (8) Knob (7c) -
Page 7: Schematic Parts Drawing
Schematic Parts drawing Ø20-63mm PatchMaster Multi P a g e... - Page 8 Ø75-180mm/90-315mm PatchMaster Multi P a g e...
-
Page 9: Parts List And Component Part Numbers
Parts list and component part numbers Ø20-63mm PatchMaster Multi Item Part No: Description Qty. 046-000077 TOP CARRIAGE ASSEMBLY DOWL-5mmx5mm-SS DOWEL PIN Ø5x5 SS 171-000157 REVOLVING GRIP 096-000030 ADJUSTMENT PILLAR 645-000381 TOP BACK PLATE SCRW-M4x20mmCSKBZP HEX SOCKET C'SUNK HEAD; M4x20, BZP 171-000162 FIXING KNOB 046-000073... - Page 10 Ø90-315mm PatchMaster Multi Item Part No: Description Qty. 046-000089 TOP CARRIAGE ASSEMBLY DOWL-5mmx5mm-SS DOWEL PIN Ø5x5 SS 171-000157 REVOLVING GRIP 096-000032 ADJUSTMENT PILLAR 645-000402 BACK PLATE SCRW-M4x20mmCSKBZP HEX SOCKET C'SUNK HEAD; M4x20, BZP 171-000162 FIXING KNOB 046-000086 BOTTOM CARRIAGE ASSEMBLY 014-000022 AXEL 076-000005...
-
Page 11: Specifications
Plastic pipes and fittings – Equipment for fusion jointing polyethylene systems. (Note – this specification is mainly for control units) Note: Hy-Ram Engineering Co. Ltd. operate a policy of continual improvement and therefore reserves the right to modify product specifications without notice... -
Page 12: Operating Instructions
Operating Instructions 1. Check the pipe for any damage or abrasions that may be detrimental to the performance of the joint. If required, wash down the pipe in excess of the area to be scraped to remove traces of dirt or mud. -
Page 13: Ukca / Ec Declaration Of Conformity
Modifications to the equipment without prior written approval by the undersigned will render this declaration null and void. For and on behalf of the manufacturer: Being a nominated person appointed by the manufacturer and employed by Hy-Ram Engineering Co Ltd]. Signature: ……………………………………………………………….. -
Page 14: Certificate Of Calibration
The product must be accompanied by written evidence of the date of purchase (see also the form at the rear of this document). Hy-Ram will not be responsible for any loss or damage incurred in connection with the return of the product. - Page 15 In no event will Hy-Ram or its authorised dealers be liable for any loss of profits or special, consequential or incidental damages even if such damages result from negligence or other fault.
- Page 16 For Sales, Hire and Repair support contact our admin team or scan the QR code for further details www.hyram.com +44 (0) 1623 422982 enquiries@hyram.com Head Office Mansfield (Hire & Repair) Bury (Hire & Repair) Enfield (Hire & Repair) Pelham Street Unit 5 Unit 18 Unit 2...
