Technical Datasheet
DESCRIPTION
Pond volume
Weight/ Reactor Dimensions
Treatment Chamber
Weight of the chamber filled
Chamber UVc volume
Input/ Output
Material
Service pressure
Pressure max.
Electrical box
Specificity
Electrical consumption
Voltage Supply
Ambiant temperature
Lamp UVc
Number of lamps
Lamp reference
Germicidal Power
Lamp lifetime
Varioclean Pro-X 120/190/285
PRO-X 120
PRO-X 190
3
3
70 m
100 m
10 Kg
10 Kg
23 Kg
14 liters
3"-DN80
Stainless Steel 316L
1 bar
2 bars
Remote
140 à 200 Wh
220-240V AC – 50-60Hz
0 - 40 °C
2
2
2G11-PLL60W
2G11-PLL95W
38 W UVc
54 W UVc
9000 hours
9000 hours
Page 1/7
PRO-X 285
3
150 m
12Kg
23 Kg
13.3 liters
3"-DN80
Stainless Steel 316L
1 bar
2 bars
Remote
300 Wh
220-240V AC– 50-60Hz
0 - 40 °C
3
2G11-PLL95W
81 W UVc
9000 hours
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Auga Varioclean Pro-X 120
Summary of Contents for Auga Varioclean Pro-X 120
- Page 1 Technical Datasheet Varioclean Pro-X 120/190/285 DESCRIPTION PRO-X 120 PRO-X 190 PRO-X 285 Pond volume 70 m 100 m 150 m 12Kg Weight/ Reactor Dimensions 10 Kg 10 Kg Treatment Chamber Weight of the chamber filled 23 Kg 23 Kg 14 liters 13.3 liters...
- Page 2 Technical Data Varioclean Pro-X 120/190/285 Table of Contents Pages PRESENTATION General Operation Mode INSTALLATION Troubleshooting Maintenance lamp remplacements Maintenance quartz sleeve replacements PRESENTATION AND OPERATION The bactericidal UVc concept has for principale to generate ultraviolet rays inside a treatment chamber. These beams irradiate the living cells that are present in the liquid crossing the device, without modifying their physical-chemical criteria and without generating any residual solution.The activation of the system is via a 220V outlet controlled filtration.
-
Page 3: Terms Of Use
Technical Datasheet Varioclean Pro-X 120/190/285 WARNING Do not use the UVC lamps outside the treatment chamber Do not expose your eyes directly to the UVC light Never start the systems electricaly before the water is in The outflow of the water should be on top of the unit ... -
Page 4: Installation
Technical Data Varioclean Pro-X 120/190/285 INSTALLATION Hydraulic Installation Ensure that the device is fixed to the floor in the recommended position (vertical) We recommend avoiding drilling water for filling up the pools The power of the pump must of course be related to the volume of water considered in order to be able to treat it as a whole within a reasonable time (3 to 4 hours) ... - Page 5 Technical Datasheet Varioclean Pro-X 120/190/285 Lamp replacement 1 – Turn off the device 2 – Cut water from the installation Derlin Ring Needle screw 3 – Unscrew the needle screw then the delrin ring 4 – Remove the cap and lamp assembly from the device Cap seal 5 –...
- Page 6 Technical Data Varioclean Pro-X 120/190/285 Quartz Sleeve Replacement 1 – Turn Off the device 2 – Cut water from the installation 3 – Unscrew the needle screw then the delrin ring 4 – Remove the cap and lamp assembly from the device 5 –...
- Page 7 Technical Datasheet Varioclean Pro-X 120/190/285 CONTRACTUAL GUARANTEE All our products are guaranteed 12 months from the date of our invoice. Trading supplies (which are not of our construction) are only guaranteed within the limit of the guarantee of our suppliers.
