AIRES SPLIT DUCTED UNIT
Outdoor
Installation and Commissioning Guide
CAUTION:
The system is charged with flammable
refrigerant, safety checks are necessary to
ensure that the risk of ignition is minimised.
Model Numbers
Single Phase
Three Phase
CRS10AS
CRS13AS
CRS15AS
CRS17AS
IMPORTANT NOTE:
This unit is designed for use with R-32 refrigerant only.
Please read the R-32 Safety Manual and this manual carefully
before installing or operating your air conditioning unit.
Information in this manual is to be used in conjunction with
the R-32 Safety Manual.
Make sure to save this manual for future reference.
CRS13AT
CRS15AT
CRS17AT
CRS20AT
CRS23AT
