ION Bluetooth
1D Wireless Linear lmager
v1
Configuration Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ION Bluetooth and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for POSX ION Bluetooth

Summary of Contents for POSX ION Bluetooth

  • Page 1 ION Bluetooth 1D Wireless Linear lmager Configuration Guide...
  • Page 2 Revision History Revision Description Date Initial Release January 2017...

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 System Information 1.1 About this anual 1.2 How to onfigure the Scanner Chapter 2 General Setup 2.1 Pairing with the radle 2.2 Pairing multiple scanners 2.3 Pairing with a Bluetooth evice 2.4 Enabling on-screen eyboard with obile evices 2.5 Scanning Mode Selection Chapter 3 Barcode Parameter Settings...

  • Page 4: Chapter 1 System Information

    Chapter 1 - System Information 1.1 About this manual This configuration guide provides detailed instructions for programming your barcode scanner to meet your application’s requirements. Barcode scanners are factory programmed for the most common communication settings, but If you need to change these settings, programming is accomplished by scanning the barcodes in this guide.
  • Page 5 1.2 How to Configure the Scanner (Cont.) In most cases the scanner will only need to scan one programming barcode to change a parameter, but for some parameters multiple programming barcodes must be scanned to complete programming. For example: Hexadecimal barcodes. For example: prefix, suffix, etc. Numeric barcodes.

  • Page 6: Chapter 2 General Setup

    Chapter 2 – General Setup 2.1 Pairing with the cradle By default the scanner will come paired to the included cradle, if you need to re-pair your cradle or add additional scanners to your cradle use the steps below. To pair more then one scanner to your cradle, scan the barcode on page 7 with the paired scanner, before pairing any additional scanners.

  • Page 7: Pairing Multiple Scanners

    6. Scan "Save BT SPP Setting" 7. Scan "End BT SPP Setting" After 10 seconds the scanner LED will change to purple to signify a successful pairing. If the scanner LED is still red, the scanner did not pair to the cradle. 2.2 Paring Multiple Scanners If pairing more then one scanner to the cradle, scan the barcode below with the scanner that is currently paired to...

  • Page 8: Pairing With A Bluetooth Evice

    2.3 Pairing with a Bluetooth device 1. Scan "Start Configuration" 2. Scan "Open HID Connection" 3. Scan "Disconnect Previous Pairing" 4. Scan "Enable BT Visibility" 5. Scan "Save BT HID Configuration" 6. Scan "End BT HID Configuration" 7. Open up the Bluetooth settings on your device and search for available connections.

  • Page 9: Enabling On-Screen Eyboard With Obile Evices

    2.4 Enabling on screen keyboard with mobile devices When using this scanner with iOS and Android devices the on-screen keyboard will no longer show. If the on-screen keyboard is still necessary use the directions below to enable it. Scan the "Toggle iOS Keyboard Emulation" barcode below. Android On your Android device open up "Settings", "Languages &...

  • Page 10: Scanning Mode Selection

    Start Configuration End Configuration 2.5 Scanning mode selection ITEM OPTION * Trigger On/Good Read Off Trigger On/Off Continuous/Trigger Off Reading Mode Continuous/Testing Continuous/Trigger On Continuous/Auto Power On Flash Flash/Auto Power On...
  • Page 11 Start Configuration End Configuration 2.6 Terminator ITEM OPTION None CR+LF Output Characters...
  • Page 12 2.7 String Options (Prefix & Suffix) This section describes the alterations which can be made to the format of the transmitted data string. A maximum of 10 prefix and suffix characters may be included in front of and at the end of a scanned barcode. Format {Prefix} {Code ID} {Bar Code} {Suffix} How to set up a prefix...
  • Page 13 2.8 Insertion Groups This section describes how to setup an insertion group. An insertion group adds characters into the transmitted string at a designated point. NOTE: Maximum of 10 characters can be inserted at each position Maximum of 2 Insertion groups Insertion groups (01) and (02) can be used in different symbologies at the same time...
  • Page 14 Example: Insert “A” before the third digit (3) to make the decoded data “12A3456789.” Setting Up the Insertion Character Scan Start Configuration barcode. Scan “G1 Insertion Character.” Scan “4” and “1” (Hex command for ‘A’) from FULL ASCII Table. Scan Confirm Configuration barcode. Scan End Configuration barcode Setting Up the Insertion Position Scan Start Configuration barcode.
  • Page 15 Start Configuration End Configuration Confirm Configuration ITEM OPTION Preamble (Default：00) Ref: Appendix Postamble (Default：00) Ref: Appendix G1 Insertion Character (Default：00) Ref: Appendix G2 Insertion Character (Default：00) Ref: Appendix G1 Character Position (Default：00) Ref: Appendix G2 Character Position (Default：00) Ref: Appendix...
  • Page 16 Start Configuration End Configuration ITEM OPTION *Disable Barcode ID Enable * Read 1 Time Accuracy Read 2 Times Negative bar codes Positive and negative bar codes *Positive bar codes Code Type Code Type UPC-A Interleaved 25 UPC-E Industrial 25 EAN-13 Matrix 25 EAN-8 China Postal Code...

  • Page 17: Upc-A

    Chapter 3 - Barcode Parameters How to Set Up a Code ID (1) Scan Start Configuration barcode. Scan the Code ID Setting barcode from the corresponding symbology section in this manual. Use the ASCII Table to find the hex values that correspond with the characters to be inserted and scan the corresponding numeric barcodes in the back of this guide.
  • Page 18 Start Configuration End Configuration ITEM OPTION * Disable UPC-A Expand to EAN-13 Enable Disable Check Digit Send * Enable * Disable Truncate Leading Zero Enable Truncate Leading (Default:00) Ref: Appendix (00-0DH) Truncate Ending (Default:00) Insert Ref: Appendix (00-0DH) Group Selection Ref: Appendix（00—02H）...
  • Page 19 Start Configuration End Configuration ITEM OPTION * NONE 2 digits Supplement digits 5 digits 2 or 5digits Auto-discriminate Supplement...

  • Page 20: Upc-E

    3.2 UPC-E Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID setting (Default: G) Ref: Appendix (20-7EH)
  • Page 21 Start Configuration End Configuration ITEM OPTION * Disable UPC-E Expand to UPC-A Enable Disable Check Digit Send * Enable Truncate Leading (Default:00) Ref: Appendix (00-08H) Truncate Ending (Default:00) Ref: Appendix (00-08H) Insert group selection (Default:00) Ref: Appendix (00-02H)
  • Page 22 Start Configuration End Configuration ITEM OPTION *Disable Truncate Leading Zero Enable * None 2 digits Supplement Digits 5 digits 2 or 5 digits Auto-discriminate Supplement...

  • Page 23: Ean-13

    3.3 EAN-13 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default: H) Ref: Appendix (20-7EH) Disable Check Digit Send * Enable Truncate Leading (Default: 00) Ref: Appendix (00-0DH) Truncate Ending (Default: 00) Ref: Appendix (00-0DH)
  • Page 24 Start Configuration End Configuration ITEM OPTION * None 2 digits Supplement Digits 5 digits 2 or 5 digits Auto-discriminate Supplement * Disable ISBN/ISSN Conversion Enable Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 25: Ean-8

    3.4 EAN-8 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default: I) Ref: Appendix (20-7EH) Disable Check Digit Send * Enable Truncate Leading (Default: 00) Ref: Appendix (00-08H)
  • Page 26 Start Configuration End Configuration ITEM OPTION Truncate Ending (Default: 00) Ref: Appendix (00-08H) * None 2 digits Supplement Digits 5 digits 2 or 5 digits Auto-Discriminate Supplement Insert Group Selection (Default: 00) Ref: Appendix (00-02H)
  • Page 27 3.5 Code 39 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default: J) Ref: Appendix (20-7EH) * Disable Check-Sum Verification Enable Disable Check-Sum Transmission * Enable...
  • Page 28 Start Configuration End Configuration ITEM OPTION * Disable Append Enable Min. Code Length (Default: 00) Ref: Appendix (00-32H) Max. Code Length (Default: 32H) Ref: Appendix (00-32H) * Standard Code39 Format Code 39 Full ASCII...
  • Page 29 Start Configuration End Configuration ITEM OPTION * Disable Transmit Start/End Character Enable Truncate Leading (Default: 00) Ref: Appendix (00-32H) Truncate Ending (Default: 00) Ref: Appendix (00-32H) Insert group selection (Default: 00) Ref: Appendix (00-02H)
  • Page 30 3.6 Codabar Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default: K) Ref: Appendix (20-7EH)
  • Page 31 Start Configuration End Configuration ITEM OPTION * Disable Check-Sum Verification Enable * Disable Check-Sum Transmission Enable * Disable Append Enable Truncate Leading (Default:00) Ref: Appendix (00-7EH)
  • Page 32 Start Configuration End Configuration ITEM OPTION Truncate Ending (Default:00) Ref: Appendix (00-7EH) * ABCD/ABCD Start/End type abcd/abcd abcd/tn*e * Disable Start/End Transmission Enable Min. Code Length (Default: 05) Ref: Appendix (00-3CH)
  • Page 33 Start Configuration End Configuration ITEM OPTION Max. Code Length (Default: 3CH) Ref: Appendix (00-3CH) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 34: Code 128

    Code 93 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default: L) Ref: Appendix (20-7EH) Disable Check-Sum Verification * Enable...
  • Page 35 Start Configuration End Configuration ITEM OPTION * Disable Check-Sum Transmission Enable Min. Code Length (Default: 00) Ref: Appendix (0-50H) Max. Code Length (Default: 50H) Ref: Appendix (0-50H) Truncate Leading (Default: 00) Ref: Appendix (00-7EH) Truncate Ending (Default: 00) Ref: Appendix (00-7EH) Insert Group Selection Ref: Appendix (00-02H)
  • Page 36 3.8 Code 128 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default: M) Ref: Appendix (20-7EH) Disable Check-Sum Verification * Enable...
  • Page 37 Start Configuration End Configuration ITEM OPTION * Disable Check-Sum Transmission Enable * Disable FNC2 Append Enable * Disable UCC/EAN128 Enable * Disable FNC1 Transmission Enable...
  • Page 38 Start Configuration End Configuration ITEM OPTION FIELD SEPARATOR DEFINED (GS CHARACTER) Enable Field Separator Ref: Appendix Truncate Leading (Default: 00) Ref: Appendix (00-7FH) Truncate Ending (Default: 00) Ref: Appendix (00-7FH) Min. Code Length (Default: 00) Ref: Appendix (00-7FH) Max. Code Length (Default: 7FH) Ref: Appendix (00-7FH) Insert Group Selection...

  • Page 39: Interleaved 2 Of

    Interleaved 2 of 5 Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default: N) Ref: Appendix (20-7EH) * Disable Check-Sum Verification Enable Disable Check-Sum Transmission * Enable...
  • Page 40 Start Configuration End Configuration ITEM OPTION Truncate Leading (Default: 00) Ref: Appendix (00-7EH) Truncate Ending (Default: 00) Ref: Appendix (00-7EH) Min. Code Length (Default: 04) Ref: Appendix (04-7FH) Max. Code Length (Default: 7FH) Ref: Appendix (00-7FH) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 41: Industrial 2 Of

    3.10 Industrial 2 of 5 Start Configuration End Configuration ITEM OPTICON * Disable Read Enable Code ID Setting (Default: O) Ref: Appendix (20-7EH) Min. Code Length (Default: 00) Ref: Appendix (00-32H) Max. Code Length (Default: 32H) Ref: Appendix (00-32H)
  • Page 42 Start Configuration End Configuration ITEM OPTION Truncate Leading (Default: 00) Ref: Appendix (00-32H) Truncate Ending (Default: 00) Ref: Appendix (00-32H) * Disable Check-Sum Verification Enable Disable Check-Sum Transmission * Enable Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 43: Matrix 2 Of

    3.11 Matrix 2 of 5 Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default: P) Ref: Appendix (20-7EH) * Disable Check-Sum Verification Enable...
  • Page 44 Start Configuration End Configuration ITEM OPTION Disable Check-Sum Transmission * Enable Truncate Leading (Default: 00) Ref: Appendix (00-50H) Truncate Ending (Default: 00) Ref: Appendix (00-50H) Min. Code Length (Default: 0B) Ref: Appendix (00-50H) Max. Code Length (Default: 50H) Ref: Appendix (00-50H) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 45: China Postal Code

    3.12 China Postal Code Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default: Q) Ref: Appendix (20-7EH) * Disable Check-Sum Verification Enable Disable Check-Sum Transmission * Enable...
  • Page 46 Start Configuration End Configuration ITEM OPTION Truncate Leading (Default: 00) Ref: Appendix (00-50H) Truncate Ending (Default: 00) Ref: Appendix (00-50H) Min. Code Length (Default: 00) Ref: Appendix (00-50H) Max. Code Length (Default: 50H) Ref: Appendix (00-50H) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 47: Msi/Plessey

    3.13 MSI/Plessey Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default: R) Ref: Appendix (20-7EH) * Disable MOD 10 Check-Sum Verification MOD 10/10 MOD 11/10...
  • Page 48 Start Configuration End Configuration ITEM OPTION Disable Check-Sum Transmission * Enable Truncate Leading (Default: 00) Ref: Appendix (00-3CH) Truncate Ending (Default: 00) Ref: Appendix (00-3CH) Min. Code Length (Default: 00) Ref: Appendix (00-3CH) Max. Code Length (Default: 3CH) Ref: Appendix (00-3CH) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 49: Code

    3.14 CODE 32 Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default: S) Ref: Appendix (20-7EH) Disable Check-Sum Verification * Enable Disable Check-Sum Transmission * Enable...
  • Page 50 Start Configuration End Configuration ITEM OPTION Truncate Leading (Default: 00) Ref: Appendix (00-0AH) Truncate Ending (Default: 00) Ref: Appendix (00-0AH) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)
  • Page 51 3.15 CODE 11 Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default: T) Ref: Appendix (20-7EH) Disable Check-Sum Verification * Enable...
  • Page 52 Start Configuration End Configuration ITEM OPTION * Disable Check-Sum Transmission Enable Truncate Leading (Default: 00) Ref: Appendix (00-50H) Truncate Ending (Default: 00) Ref: Appendix (00-50H) Min. Code Length (Default: 00) Ref: Appendix (00-50H) Max. Code Length (Default: 50H) Ref: Appendix (00-50H) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 53: Telepen

    3.16 Telepen Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default: V) Ref: Appendix (20-7EH) Disable Check-Sum Verification * Enable Only Numeric Data Format *Full ASCII...
  • Page 54 Start Configuration End Configuration ITEM OPTION * Disable Check-Sum Transmission Enable Truncate Leading (Default: 00) Ref: Appendix (00-40H) Truncate Ending (Default: 00) Ref: Appendix (00-40H) Min. Code Length (Default: 00) Ref: Appendix (00-40H) Max. Code Length (Default: 40H) Ref: Appendix (00-40H) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 55: Gs1 Databar

    3.17 GS1 Data Bar (RSS) Start Configuration End Configuration ITEM OPTION Enable RSS-14 *Disable Enable RSS-14 Limited *Disable Enable RSS-14 Expanded *Disable Enable RSS to UPC/EAN *Disable...
  • Page 56 Start Configuration End Configuration ITEM OPTION *Enable Application ID Transmission Disable *Enable Checksum Transmission Disable...
  • Page 57 Appendix A –...
  • Page 58 KBD Wedge Character Table Char Char Char L-Ctrl L-Shift L-Alt L-GUI R-Ctrl R-Shift R-Alt R-GUI Caps Lock Print Screen Scroll Lock Pause Insert Delete Home Page Up Page Down Left Arrow Right Arrow Up Arrow Down Arrow Num Lock(keypad) 1(keypad) 2(keypad) 3(keypad) 4(keypad)
  • Page 59 Char. Char. “ & ‘ < >...
  • Page 60 Char. Char. ‘...
  • Page 61 Table-Hex HEXADCIMAL Confirm Configuration End Configuration...
