Summary of Contents for POSX ION BLUETOOTH

  • Page 1 All manuals and user guides at all-guides.com...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents Chapter 1 System Information 1.1 Setup Scanner with PC 1.2 Setup Scanner with Mobile Device 1.3 Configure iOS On-Screen Keyboard 1.4 Memory Mode 1.5 Sleep Settings 1.6 How to Configure the Scanner Chapter 2 System Setup 2.1 Terminator...

  • Page 3: Setup Scanner With Pc

    All manuals and user guides at all-guides.com Chapter 1 - Scanner Setup About this manual This User's Guide provides detailed programming instructions. Barcode scanners are factory programmed for the most common communication settings. If you need to change these settings, programming is accomplished by scanning the barcodes in this guide.

  • Page 4: Setup Scanner With Mobile Device

    All manuals and user guides at all-guides.com 1.2 Setup Scanner with Mobile Device To use the scanner with a mobile device (iOS, Android, or Bluetooth Windows device) use the instructions below. Scan Disconnect Previous Pair Scan HID Mode Scan Pairing Mode Open Bluetooth settings on your mobile device and tap on "Bluetooth Scanner"...

  • Page 5: Memory Mode

    All manuals and user guides at all-guides.com 1.4 Memory Mode The scanner can be configured to store all scanned barcodes in the scanners internal memory. While in memory mode the scanner will not transmit any barcodes until the "Transmit Stored Data" barcode is scanned.

  • Page 6: Sleep Settings

    All manuals and user guides at all-guides.com 1.5 Sleep Settings If the scanner has not been used for a set amount of time the scanner will automatically enter sleep mode. To take the scanner out of sleep mode simply press and hold the trigger for 1 second. To change the amount of time before the scanner enters sleep mode, scan one of the barcodes below.

  • Page 7: How To Configure The Scanner

    All manuals and user guides at all-guides.com 1.6 How to configure the scanner (1) Scan Start Configuration to enter programming mode (2) Scan all necessary barcodes for settings that meet your needs. (3) Scan End Configuration to exit programming mode. Start Configuration End Configuration Default Settings...
  • Page 8 All manuals and user guides at all-guides.com Most of time the scanner only requires one barcode when changing to new values. You will hear two beeps when you successfully change a setting. For some special settings, multiple barcodes are needed to complete the configuration.

  • Page 9: Terminator

    All manuals and user guides at all-guides.com Chapter 2 - Scanner Configuration Start Configuration End Configuration 2.1 Terminator ITEM OPTION None *CR+LF Output Characters...

  • Page 10: Beeper Tone

    All manuals and user guides at all-guides.com 2.2 Beeper Tone Start Configuration End Configuration ITEM OPTION Beep Tone (Default : 09H) * Ref: Appendix (00-10H) Beep Sound Duration (Default : 05H) * Ref: Appendix (00-10H) * Enable Power On Beeper Disable * On Beeper...

  • Page 11: Trigger Mode

    All manuals and user guides at all-guides.com 2.3 Trigger Mode Start Configuration End Configuration ITEM OPTION * Trigger On/Good Read Off Trigger On/Off Continuous/Trigger Off Continuous/Testing Reading Mode Continuous/Trigger On Continuous/Auto Power On Flash Flash/Auto Power On...

  • Page 12: String Options (Prefix & Suffix)

    All manuals and user guides at all-guides.com 2.4 String Options (Prefix & Suffix) This section describes the alterations which can be made to the format of the transmitted data string. A prefix and suffix of 10 direct inputs may be included in front of and at the end of the scanned barcode. Format {Prefix} {Code ID} {Bar Code} {Suffix} How to set up a prefix?

  • Page 13: Setup Insertion

    All manuals and user guides at all-guides.com 2.5 Setup Insertion This section describes how to setup insertion groups. Insertion groups allow you to insert characters into the output from scanned barcodes. NOTE : Max. 10 charters can be inserted each time ...
  • Page 14 All manuals and user guides at all-guides.com Example: To make the above barcode output 12A3456789, insert an "A" character before the third digit (3). How to set the character you want to insert Scan “Start Configuration“ barcode Scan “G1 Insertion character” Scan “4”...
  • Page 15 All manuals and user guides at all-guides.com Start Configuration End Configuration Confirm Configuration ITEM OPTION Preamble (Default：00) Ref: Appendix Postamble (Default：00) Ref: Appendix G1 Insertion Character (Default：00) Ref: Appendix G2 Insertion Character (Default：00) Ref: Appendix G1 Character Position to be Inserted (Default：00) Ref: Appendix G2 Character Position to be...
  • Page 16 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION *Disable Barcode ID Enable * Read 1 Time Accuracy Read 2 Times Positive and Negative Barcodes Negative bar codes *Positive bar codes Code Type Code Type UPC-A Interleaved 25 UPC-E Industrial 25...

  • Page 17: Upc-A

    All manuals and user guides at all-guides.com Chapter 3 - Barcode Settings How to set up a Code ID? (1) Scan Start Configuration bar code (2) Go to the ASCII Table and scan label that represent the desired characters to be inserted. (3) Scan Confirm Configuration bar code (4) Scan End Configuration bar code.
  • Page 18 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * Disable UPC-A Expand to EAN-13 Enable Disable Check Digit Send * Enable * Disable Truncate Leading Zero Enable Truncate Leading (Default:00) Ref: Appendix (00-0DH) Truncate Ending (Default:00) Ref: Appendix (00-0DH) Insert Group Selection...
  • Page 19 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * NONE 2 digits Supplement Digits 5 digits 2 or 5digits Auto-discriminate Supplement...

  • Page 20: 2 Upc-E

    All manuals and user guides at all-guides.com 3.2 UPC-E Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default : G) Ref: Appendix (20-7EH)
  • Page 21 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * Disable UPC-E Expand to UPC-A Enable Disable Check Digit Send * Enable Truncate Leading (Default:00) Ref: Appendix (00-08H) Truncate Ending (Default:00) Ref: Appendix (00-08H) Insert Group Selection (Default:00) Ref: Appendix (00-02H)
  • Page 22 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION *Disable Truncate Leading Zero Enable * None 2 digits Supplement Digits 5 digits 2 or 5 digits Auto-discriminate Supplement...

  • Page 23: 3 Ean-13

    All manuals and user guides at all-guides.com 3.3 EAN-13 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default : H) Ref: Appendix (20-7EH) Disable Check Digit Send * Enable Truncate Leading (Default : 00 ) Ref: Appendix (00-0DH) Truncate Ending (Default : 00 )
  • Page 24 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * None 2 digits Supplement Digits 5 digits 2 or 5 digits Auto-discriminate Supplement * Disable ISBN/ISSN Conversion Enable Insert Group Selection (Default : 00 ) Ref: Appendix (00-02H)

  • Page 25: Ean-8

    All manuals and user guides at all-guides.com 3.4 EAN-8 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default : I) Ref: Appendix (20-7EH) Disable Check Digit Send * Enable Truncate Leading (Default : 00) Ref: Appendix (00-08H)
  • Page 26 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Truncate Ending (Default : 00) Ref: Appendix (00-08H) * None 2 digits Supplement Digits 5 digits 2 or 5 digits Auto-discriminate Supplement Insert Group Selection (Default : 00) Ref: Appendix (00-02H)

  • Page 27: Code

    All manuals and user guides at all-guides.com 3.5 Code 39 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default : J) Ref: Appendix (20-7EH) * Disable Check-sum Verification Enable Disable Check-sum Transmission * Enable...
  • Page 28 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * Disable Append Enable Min. Code Length (Default: 00) Ref: Appendix (00-32H) Max. Code Length (Default: 32H) Ref: Appendix (00-32H) Format * Standard Code39 Code 39 Full ASCII...
  • Page 29 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * Disable Transmit Start/End Character Enable Truncate Leading (Default: 00) Ref: Appendix (00-32H) Truncate Ending (Default: 00) Ref: Appendix (00-32H) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 30: 6 Codabar

    All manuals and user guides at all-guides.com 3.6 Codabar Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default : K) Ref: Appendix (20-7EH)
  • Page 31 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Disable Check-sum Verification * Enable * Disable Check-sum Transmission Enable * Disable Append Enable Truncate Leading (Default:00) Ref: Appendix (00-7EH)
  • Page 32 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Truncate Ending (Default:00) Ref: Appendix (00-7EH) * ABCD/ABCD Start/End type abcd/abcd abcd/tn*e * Disable Start/End Transmission Enable Min. Code Length (Default: 05) Ref: Appendix (00-3CH)
  • Page 33 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Max. Code Length (Default: 3CH) Ref: Appendix (00-3CH) Insert Group Selection (Default: 00) Ref: Appendix (00-02H)

  • Page 34: Code 128

    All manuals and user guides at all-guides.com Code 93 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default : L) Ref: Appendix (20-7EH) Disable Check-sum Verification * Enable...
  • Page 35 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * Disable Check-sum Transmission Enable Min. Code Length (Default: 00) Ref: Appendix (0-50H) Max. Code Length (Default: 50H) Ref: Appendix (0-50H) Truncate Leading (Default: 00) Ref: Appendix (00-7EH) Truncate Ending (Default: 00) Ref: Appendix (00-7EH)
  • Page 36 All manuals and user guides at all-guides.com 3.8 Code 128 Start Configuration End Configuration ITEM OPTION Disable Read * Enable Code ID Setting (Default : M) Ref: Appendix (20-7EH) Disable Check-sum Verification * Enable...
  • Page 37 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * Disable Check-sum Transmission Enable * Disable FNC2 Append Enable * Disable UCC/EAN128 Enable * Disable FNC1 Transmission Enable...
  • Page 38 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Field Separator Defined (GS CHARACTER) Enable Field Separator Ref: Appendix Truncate Leading (Default: 00) Ref: Appendix (00-7FH) Truncate Ending (Default: 00) Ref: Appendix (00-7FH) Min. Code Length (Default: 00) Ref: Appendix (00-7FH) Max.

  • Page 39: Interleaved 2 Of

    All manuals and user guides at all-guides.com Interleaved 2 of 5 Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default : N) Ref: Appendix (20-7EH) Disable Check-sum Verification * Enable Disable Check-sum Transmission * Enable...
  • Page 40 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Truncate Leading (Default : 00) Ref: Appendix (00-7EH) Truncate Ending (Default : 00) Ref: Appendix (00-7EH) Min. Code Length (Default : 04) Ref: Appendix (04-7FH) Max. Code Length (Default : 7FH) Ref: Appendix (00-7FH) Insert Group Selection...

  • Page 41: Industrial 2 Of

    All manuals and user guides at all-guides.com 3.10 Industrial 2 of 5 Start Configuration End Configuration ITEM OPTICON * Disable Read Enable Code ID Setting (Default : O) Ref: Appendix (20-7EH) Min. Code Length (Default : 00) Ref: Appendix (00-32H) Max.
  • Page 42 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Truncate Leading (Default : 00) Ref: Appendix (00-32H) Truncate Ending (Default : 00) Ref: Appendix (00-32H) * Disable Check-sum Verification Enable Disable Check-sum Transmission * Enable Insert Group Selection (Default : 00) Ref: Appendix (00-02H)

  • Page 43: Matrix 2 Of

    All manuals and user guides at all-guides.com 3.11 Matrix 2 of 5 Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default : P) Ref: Appendix (20-7EH) * Disable Check-sum Verification Enable...
  • Page 44 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Disable Check-sum Transmission * Enable Truncate Leading (Default : 00) Ref: Appendix (00-50H) Truncate Ending (Default : 00) Ref: Appendix (00-50H) Min. Code Length (Default : 0B) Ref: Appendix (00-50H) Max.

  • Page 45: China Postage

    All manuals and user guides at all-guides.com 3.12 China Postage Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default : Q) Ref: Appendix (20-7EH) * Disable Check-sum Verification Enable Disable Check-sum Transmission * Enable...
  • Page 46 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Truncate Leading (Default : 00) Ref: Appendix (00-50H) Truncate Ending (Default : 00) Ref: Appendix (00-50H) Min. Code Length (Default : 00) Ref: Appendix (00-50H) Max. Code Length (Default : 50H) Ref: Appendix (00-50H) Insert Group Selection...

  • Page 47: Msi/Plessey

    All manuals and user guides at all-guides.com 3.13 MSI/Plessey Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default : R) Ref: Appendix (20-7EH) * Disable MOD 10 Check-sum Verification MOD 10/10 MOD 11/10...
  • Page 48 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Disable Check-sum Transmission * Enable Truncate Leading (Default : 00) Ref: Appendix (00-3CH) Truncate Ending (Default : 00) Ref: Appendix (00-3CH) Min. Code Length (Default : 00) Ref: Appendix (00-3CH) Max.

  • Page 49: Code

    All manuals and user guides at all-guides.com 3.14 Code 32 Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default:S) Ref: Appendix (20-7EH) Disable Check-sum Verification * Enable Disable Check-sum Transmission * Enable...
  • Page 50 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION Truncate Leading (Default : 00) Ref: Appendix (00-0AH) Truncate Ending (Default : 00) Ref: Appendix (00-0AH) Insert Group Selection (Default : 00) Ref: Appendix (00-02H)
  • Page 51 All manuals and user guides at all-guides.com 3.15 Code 11 Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default:T) Ref: Appendix (20-7EH) Disable Check-sum Verification * Enable...
  • Page 52 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * Disable Check-sum Transmission Enable Truncate Leading (Default : 00) Ref: Appendix (00-50H) Truncate Ending (Default : 00) Ref: Appendix (00-50H) Min. Code Length (Default : 00) Ref: Appendix (00-50H) Max.

  • Page 53: Telepen

    All manuals and user guides at all-guides.com 3.16 Telepen Start Configuration End Configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default:V) Ref: Appendix (20-7EH) Disable Check-sum Verification * Enable Only Numnic Data Format *Full ASCII...
  • Page 54 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION * Disable Check-sum Transmission Enable Truncate Leading (Default : 00) Ref: Appendix (00-40H) Truncate Ending (Default : 00) Ref: Appendix (00-40H) Min. Code Length (Default : 00) Ref: Appendix (00-40H) Max.

  • Page 55: Gs1 Databar

    All manuals and user guides at all-guides.com 3.17 GS1 Data Bar (RSS) Start Configuration End Configuration ITEM OPTION Enable RSS-14 *Disable Enable RSS-14 Limited *Disable Enable RSS-14 Expanded *Disable Enable RSS To UPC/EAN *Disable...
  • Page 56 All manuals and user guides at all-guides.com Start Configuration End Configuration ITEM OPTION *Enable Application ID Transmission Disable *Enable Checksum Transmission Disable...

  • Page 57: Appendix

    All manuals and user guides at all-guides.com Appendix...
  • Page 58 All manuals and user guides at all-guides.com KBD Wedge Character Table Type Type “ & ‘ < >...
  • Page 59 All manuals and user guides at all-guides.com Char. Char. “ & ‘ < >...
  • Page 60 All manuals and user guides at all-guides.com Char. Char. ‘...
  • Page 61 All manuals and user guides at all-guides.com Hex Table Confirm Configuration End Configuration Version: 1.00...
