  • Page 1 Version 1.01 | January 19, 2017 User Manual PowerLine AV2 2000 Gigabit Passthrough Starter Kit DHP-P701AV...
  • Page 2: Preface

    Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Revision Date Description 1.00 August 10, 2016 • Initial release for hardware A1 1.01...
  • Page 3: Table Of Contents

    Table of Contents Table of Contents Preface ................2 Manual Revisions ................2 Trademarks ..................2 Product Overview .............. 4 Package Contents ................. 4 Minimum Requirements ............4 Introduction ................... 5 Features .................... 5 Hardware Overview ..............6 LEDs ................... 6 Connection ................
  • Page 4: Product Overview

    Section 1 - Product Overview Product Overview Package Contents Two PowerLine AV2 2000 Gigabit Passthrough Adapters (DHP-P700AV) Two Ethernet Cables Quick Install Guide If any of the above items are missing, please contact your reseller. Minimum Requirements • Ethernet Network Interface (10/100/1000 Mbps) •...
  • Page 5: Introduction

    Additional D-Link PowerLine AV2 series products are required to add new devices to the network. A minimum of two D-Link PowerLine AV2 series products are required to create a network.
  • Page 6: Hardware Overview

    Section 1 - Product Overview Hardware Overview LEDs Plug in and power devices. This outlet contains a noise filter to help Passthrough Outlet limit interference with your Powerline network. • Solid: The device is receiving electrical power. • Blinking: The device is in power saving mode or in the Simple Power LED Connect process.
  • Page 7: Connection

    Section 1 - Product Overview Hardware Overview Connection Connect to an Ethernet device such as a router, computer, video Gigabit Ethernet Port game console, network storage device, or a media player. Press and hold the button for 5 seconds to reset to the factory Reset Button default settings.
  • Page 8: Hardware Installation

    Section 2 - Hardware Installation Hardware Installation Recommendations • For best results, use in a regular wall outlet. Connecting this product to a power strip or a surge protector may adversely affect the performance of this device. • Avoid using the PowerLine adapters in an electrical outlet that is located near an appliance that uses a lot of power such as a washer, dryer, refrigerator, microwave, hair dryer, or air conditioning unit.
  • Page 9 Section 2 - Hardware Installation 2. Plug in the other DHP-P700AV adapter in the room that you want to extend your network. The Power LED will turn on. DHP-P700AV Computer 3. Verify that the PowerLine LEDs on both adapters are lit. If they are, the adapters are connected. If not, try another outlet. 4.
  • Page 10 The DHP-P700AV will automatically go into Power Saving Mode when there is no activity for five minutes. The Power LED will blink intermittently while the device is in Power Saving Mode. Note: D-Link PowerLine devices cannot be configured while in Power Saving Mode. DHP-P701AV User Manual...
  • Page 11: Push Button Security

    PowerLine adapters on the same network must use an identical encryption key. The default encryption key of each DHP-P700AV is HomePlug AV. All PowerLine AV2 2000 Gigabit Adapters with default encryption keys can communicate with each other. It’s recommended that you create a private encryption key for network security purposes. The private encryption key allows you to protect your network from unauthorized access via the PowerLine network.
  • Page 12 Section 2 - Hardware Installation 5. Adding More Adapters (Optional) If you would like to add more than two adapters, press the Simple Connect button of the additional adapter for 1 second. The Power LED will start blinking after you release the button. Then press the Simple Connect button of any adapter in your existing PowerLine network for 1 second. The Power LED will start blinking after you release the button.
  • Page 13: Powerline Installation Considerations

    Section 2 - Hardware Installation PowerLine Installation Considerations Plan the location of your PowerLine devices: 1. Connect PowerLine devices into electrical outlets that are not controlled by a wall switch. This will help you to avoid accidentally turning off power to the device. 2.
  • Page 14: Safety

    Section 2 - Hardware Installation Safety Please read all of the safety and operating instructions before using your devices: 1. Do not open the devices or attempt to repair or service them. 2. Use the devices in a dry location, and avoid placing them in humid environments. 3.
  • Page 15: Troubleshooting

    Section 3 - Troubleshooting Troubleshooting If I do not see LEDs light up? If the Power LED is off, make sure the PowerLine devices are plugged into outlets with power. Also make sure the PowerLine devices are not plugged into an extension cord, power strip, or surge protector. If the PowerLine LED is off, the devices are unable to find each other.
  • Page 16: Technical Specifications

    Appendix A - Technical Specifications Technical Specifications General • IEEE 802.3 • IEEE 1901 Standards • IEEE 802.3u • HomePlug AV • IEEE 802.3x • HomePlug AV2 Ethernet Interface • 10/100/1000Mbps Gigabit Ethernet Functionality • Power • Powerline • Ethernet Security •...
  • Page 17: Contacting Technical Support

    • Serial Number (s/n number located on the label on the bottom of the box). You can find software updates and user documentation on the D-Link website as well as frequently asked questions and answers to technical issues. For customers within the United States:...
  • Page 18: Warranty

    Warranty Period or ninety (90) days, whichever is longer, and is subject to the same limitations and exclusions. If a material defect is incapable of correction, or if D-Link determines that it is not practical to repair or replace the defective Hardware, the actual price paid by the original purchaser for the defective Hardware will be refunded by D-Link upon return to D-Link of the defective Hardware.
  • Page 19 D-Link further warrants that, during the Software Warranty Period, the magnetic media on which D-Link delivers the Software will be free of physical defects. The customer’s sole and exclusive remedy and the entire liability of D-Link and its suppliers under this Limited Warranty will be, at D-Link’s option, to replace the non-conforming Software (or defective media) with software that substantially conforms to D-Link’s...
  • Page 20 • USA residents send to 17595 Mt. Herrmann, Fountain Valley, CA 92708. D-Link will not be held responsible for any packages that are lost in transit to D-Link. The repaired or replaced packages will be shipped to the customer via UPS Ground or any common carrier selected by D-Link.
  • Page 21 FOR WARRANTY SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NONCONFORMING PRODUCT.
  • Page 22 No part of this publication or documentation accompanying this product may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems, Inc., as stipulated by the United States Copyright Act of 1976 and any amendments thereto.
  • Page 23: Registration

    Appendix D - Registration Registration Register your product online at registration.dlink.com Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights. Version 1.01 January 19, 2017 DHP-P701AV User Manual...
