2.Install the wheel
D
F
Flip the car body, insert the rear axle into the
car body, put the axle sleeve and gasket, put
the drive wheel on the left side, put the ordinary
wheel on the right side, put the gasket on, lock
with the opening pin, cover the wheel
cover.The front wheel operates the same way.
(10X18X0.8 Shim *8 & 2.5X3 Cotter pin *4 ）

4.Install steering wheel

B
Insert the steering wheel into the steering
lever, screw it tight.(M5 Nut*1 &5x38
Screw *1)
6.Install a spade
Put the spade into the slot on the side of
the car.
C
3.Install steering lever
E
E
Put the steering lever with a shim to
through the car's body.(10x20x2 Shim *1)
5.Install the mixing drum
Install the mixing drum on the car body
until it is stuck.
7.Iine connection
Electronic box
Open the seat, connect the cable speed on
the battery box, open the battery box, add
the dry battery, and close the seat.
(3x1.5V# AA dry cell).
