Scott Aerator AquaSweep Float Manual

We at Scott Aerator thank you for your purchase. It is our goal to ensure that you are completely
satisfied with your new AquaSweep and that it continues to operate smoothly for many years
to come. Please take a few moments to read through this document for proper assembly,
installation and maintenance to maximize the operating life of the unit.
Assembly Instructions
1. Remove 5/16" x 1" hex cap bolt, washer and locking nut from the float bracket. Tilt the float bracket to align
holes to the desired angle of water flow, typically 45°, and resecure. Fig. 1
2. The next step is to fasten the stainless-steel basket to the intake side of the gray AquaSweep housing.
This is easily done by aligning the 3 basket eyelets with the pre-drilled holes on the housing and fastening
with the small self-tapping screws provided. Fig. 2
3. Place float above the float bracket. Align the holes in the float with the top hole in the float bracket. Draw the
rope up through the float. Insert the long eyebolts and washer from inside, through float bracket and float and
secure with washers and locknuts. Fig. 3
4. Secure the red eye-bolts in the red marked holes in the gray tube with washers and locknuts. Fig. 3
5. Take the 2 lengths of rope included with the unit and tie them to the loops in the white rope. Secure rope ends to
docks or pilings and adjust tension to achieve position that works best. If the float has a tendency to rise when
the unit is on, move loops down 3-4 inches.
Figure 1
Float
Bracket
SS Wire Basket
Figure 3
Figure 2
!
Always use a GFCI
Always disconnect the power
when swimmers are present
Float
!
Do NOT use an extension cord
to supply power to the motor
AquaSweep
Float Model
