- Page 1 HOBBYIST Soldering Iron with LEDs User Manual TS1470...
-
Page 2: Table Of Contents
CONTENTS General Information & Safety Instructions ............3 Box Contents ......................... 3 Product Diagram ......................4 Before First Use ......................4 Warnings & Safety Information ................. 5 Features .......................... 5 Operating Instructions ....................6 Cleaning, Care, Storage & Maintenance ..............7 Specifications ........................ -
Page 3: General Information & Safety Instructions
BOX CONTENTS 1x Soldering Iron PRODUCT DIAGRAM Power LED Indicator LED Lights Power Cable Soldering Tip Power Switch... -
Page 4: Before First Use
BEFORE FIRST USE Using a soldering iron for the first time requires careful preparation to ensure safety and effectiveness. Here are the steps to follow before you begin: Preparation Inspect the Soldering Iron: Check for any visible damage to the cord, handle, or tip. -
Page 5: Warnings & Safety Information
WARNINGS & SAFETY INFORMATION When handling electric soldering irons, it is important to adhere to fundamental safety measures at all times: • Verify that the voltage specified on the appliance’s rating plate matches the local electrical network’s voltage before connecting it to the main power supply. •... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS 1. Remove any dirt, rust, 2. Apply rosin-based 3. Allow the solder to or paint from the part solder to the part and cool and harden before you intend to solder. melt it with the soldering handling the soldered Then, heat the part using iron. -
Page 7: Cleaning, Care, Storage & Maintenance
CLEANING, CARE, STORAGE & MAINTENANCE Soldering Tip Care Guidelines • Always ensure that the tips are coated with tin to prolong their service life. • Avoid leaving the iron at high temperatures for an extended duration. • Never clean the tip with abrasive materials. •... -
Page 8: Specifications
SPECIFICATIONS Heating Element Temperature Range 420-450ºC Input Voltage 240VAC @ 50/60Hz Weight 195g Dimensions 215(H) x 35(Dia.)mm Cable Length WORKING TEMPERATURE Soldering at the correct temperature is crucial to ensuring a perfect solder connection. If the temperature is too low, the solder will not flow correctly and may result in cold solder joints. -
Page 10: Warranty Information
WARRANTY INFORMATION Our product is guaranteed to be free from manufacturing defects for a period of 12 Months. If your product becomes defective during this period, Electus Distribution will repair, replace, or refund where a product is faulty; or not fit for intended purpose.
