Summary of Contents for protech HOBBYIST TS1485
- Page 1 HOBBYIST Soldering Iron User Manual TS1485...
-
Page 2: Table Of Contents
CONTENTS General Information & Safety Instructions ..........3 Box Contents ..................... 3 Product Diagram .....................4 Operating Instructions ...................4 Cleaning, Care, Storage & Maintenance ..........6 Working Temperature ..................7 Warranty Information ..................8... -
Page 3: General Information & Safety Instructions
GENERAL INFORMATION & SAFETY INSTRUCTIONS Product introductions, safety warnings, & any other relevant information that doesn’t fit anywhere else in the manual. Any disposal or recycling instructions should be included here. Any major warnings or notes should be clearly addressed at the end of this section in the below method;... -
Page 4: Product Diagram
PRODUCT DIAGRAM Soldering Tip Power Cable OPERATING INSTRUCTIONS 1. Remove any dirt, rust, 2. Apply rosin-based 3. Allow the solder to or paint from the part solder to the part cool and harden you intend to solder. and melt it with the before handling the Then, heat the part soldering iron. - Page 5 Soldering steps to protect the tip from oxidation. 1. Before soldering, clean the tip using a sponge, and then apply solder to the tip. 2. Begin your soldering work. 3. When not in use, please place the soldering iron on the holder. 4.
-
Page 6: Cleaning, Care, Storage & Maintenance
CLEANING, CARE, STORAGE & MAINTENANCE Soldering Tip Care Guidelines • Always ensure that the tips are coated with solder to prolong their service life. • Avoid leaving the iron at high temperatures for an extended duration. • Never clean the tip with abrasive materials. •... -
Page 7: Working Temperature
WORKING TEMPERATURE Soldering at the correct temperature is very important to ensure perfect solder connection. If the temperature is too low the solder will not flow correctly and will cause cold solder joints. If the temperature is too high the flux will be burned and not allow the solder to flow. -
Page 8: Warranty Information
WARRANTY INFORMATION Our product is guaranteed to be free from manufacturing defects for a period of 12 Months. If your product becomes defective during this period, Electus Distribution will repair, replace, or refund where a product is faulty; or not fit for intended purpose. This warranty will not cover modified product;...
