- Page 1 Installation instructions and how to use and look after your built-in cooker hoods NEFF...
- Page 2 Fig. 1 Abb. 1 ELECTRO...
-
Page 3: Appliance Description
Filter grille technical measures, such as reciprocal fan switches interlocking, etc. If the air intake is inadequate, there is a risk of poisoning from combustion gases which are drawn back into the room. An air-intake/exhaust-air wall box by itself is no guarantee that the limiting value will not be exceeded. -
Page 4: Before Using For The First Time
Use carefully. They contain important you may find descriptions of individual information concerning your personal features that do not apply to your safety as well as on use and care of the specific appliance. appliance. This extractor hood complies with all Please retain the operating and relevant safety regulations. -
Page 5: Safety Instructions
Carefully clean the extractor hood before switching on for the first time. Overheated fat or oil can easily catch fire. If you are cooking with fat or oil, e.g. chips, Do not place any objects on the etc., never leave the cooker unattended. -
Page 6: Operating Procedure
Intensive setting: The most effective method of removing vapours produced during cooking is to: Maximum power is obtained at the intensive setting. It is only required for short Switch the ventilator ON intervals. as soon as you begin cooking. Keep pressing the + button until a ç... -
Page 7: Filters And Maintenance
Important: By cleaning the metal grease filters at appropriate intervals, the possibility of them catching fire as a result of a build-up of heat such as occurs when deep-fat frying or roasting is taking place, is reduced. Saturation indicator: When the grease filters reach saturation... - Page 8 The activated carbon filter should risk of fire and the function of the extractor be replaced straight away. hood may be impaired. Important: Replacing the activated carbon filter: Change the activated carbon filter promptly...
-
Page 9: Cleaning And Care
Cleaning and care Isolate the extractor hood by pulling out Stainless steel surfaces: the mains plug or switching off the fuse. Use a mild non-abrasive stainless steel cleaner. Do not clean the extractor hood with Clean the surface in the same direction abrasive sponges or with cleaning agents as it has been ground and polished. -
Page 10: Replacing The Light Bulbs
If is not possible to operate the extractor hood: Disconnect the extractor hood from the mains electricity supply by pulling out the plug or switching it off at the main fuse box. Wait for approx. 1 minute and then 3. Replace the halogen light bulb switch it on again. -
Page 11: Installation Instructions
Weight in kg: Exhaust air Recirculating air 29,5 30,2 We reserve the right to construction changes within the context of technical development. - Page 12 flue that is interlocking, etc. currently used for other purposes, nor into a shaft that is used for ventilating rooms in If the air intake is inadequate, there is a which stoves or fireplaces are also located.
- Page 13 Short, smooth air exhaust pipe. Mount the pipe directly onto the air As few bends in the pipe as possible. outlet on the hood. Diameter of pipe to be as large as possible and no tight bends in pipe.
-
Page 14: Electrical Connection
A separator must be installed in the household circuit. A suitable separator is a switch that has a contact gap of more than 3 mm and interrupts all poles. Such devices include circuit breakers and contactors. -
Page 15: Installation
Exhaust air 430 - 710 2. Using the template, mark screw Circulating air positions on the ceiling. 430 - 750 3. Drill 4x 8 mm holes and insert wall plugs flush with the ceiling. min. 550 electric 650 gas... - Page 16 8 screws. Exhaust air 430 – 710 Circulating air 430 – 750 09. Screw the extractor hood to the support frame and screw back the panel. 6. Screw the support frame to the ceiling with 4 screws. 7. Remove the panel.
- Page 17 11. Connect the pipes. screw into position. 12. Connect the power. 13. Carefully remove the protective foil. 14. Place the two sections of the upper flue on the extractor hood and clip together. Protect the extractor hood from damage. 16. Insert the two sections of the lower flue and clip together.
- Page 18 Notes...
- Page 19 Notes...
- Page 20 Notes...
- Page 21 Notes...
- Page 22 Notes...
- Page 23 Z5120X5 351210...
- Page 24 NEFF Grand Union House, Old Wolverton Road, Old Wolverton Milton Keynes, MK12 5PT Tel: 01908 328300 9000 422 758 Fax: 01908 328399 Printed in Germany 0709 Es.
