FONESTAR FO-454 Manual

FO-454
EN
WI-FI, DNLA AND TCP/IP ETHERNET HDMI
ADAPTER
DESCRIPTION
- Wi-Fi, DNLA and TCP/IP Ethernet HDMI adapter.
- Plays computer content through Wi-Fi or TCP/IP Ethernet.
- Transmits multimedia content from smartphones or portable
electronic devices with DLNA.
- HDMI output for connecting to screens and projectors.
- For creating a wireless network from a router without Wi-Fi.
- Compatible with Windows and Mac-OS.
CONTROLS AND FUNCTIONS
FRONT PANEL
1.- q: On/off button on the receiver.
CONNECTION
There are four connection options available for sharing multimedia content:
Wi-Fi connection
Connects your computer and the FO-454 adapter to the router without cables.
Ethernet connection
Connects your computer and the FO-454 adapter to the router using the Cat 5e/6 cable.
Mixed connection
Connects your computer to the router using Wi-Fi and the FO-454 adapter to the router using Cat 5e/6 cable.
BACK PANEL
1.- Transmitter/receiver aerials.
2.- 5 V DC: Power supply connection for the 5 V DC adapter included.
3.- Keyboard/USB Mouse: USB connection for connecting a USB
keyboard or mouse and controlling the PC/Mac remotely.
4.- HDMI OUTPUT: digital A/V output, female HDMI connector.
5.- ETHERNET: Port for connecting a router using Cat 5e/6 cable.
