FONESTAR FO-454 User Manual

FONESTAR FO-454 User Manual

Wi-fi, dnla and tcp/ip ethernet hdmi adapter
Hide thumbs Also See for FO-454:

Advertisement

Quick Links

Download this manual
FO-454
WI-FI, DNLA AND TCP/IP ETHERNET
HDMI ADAPTER
N User guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the FO-454 and is the answer not in the manual?

Questions and answers

Related Manuals for FONESTAR FO-454

Summary of Contents for FONESTAR FO-454

  • Page 1 FO-454 WI-FI, DNLA AND TCP/IP ETHERNET HDMI ADAPTER N User guide...

  • Page 2: Installation

    - Connect the HDMI output from the FO-454 adapter to your television and switch it on. - Power the FO-454 with the mains adapter supplied and switch it on. - After approximately 30 seconds, information on the FO-454 will appear on your TV screen (SSID, assigned IP and security).
  • Page 3 Press the Apply button and reboot the adapter. Note: take into account that from this moment on the FO-454 adapter creates a new wireless network, with SSID being MirrorOp, and by default does not have activated security. It can be activated in the Network setup, Wireless setup, activating the encryption and the security key.

  • Page 4: Mirrorop Sender

    - Select the Connect option and the next window from the MirrorOp program will be shown: Central Button: to stop or start the connection with the FO-454 and project the images on the TV. App Mode: recommended configuration for high speed connections and low latency: for connecting through ethernet, programs, games, etc.
  • Page 5 Menu: the menu options available are the following: - Search remote box: to configure the installation in order to visualize the content in another FO-454 adapter. It shows the screen where the IP for the new device to be used needs to be inserted. The IP for the last equipment connected will be shown.
  • Page 6 - TV offset compensation: to compensate the cuts due to excess TV scanning. - Auto power management : if you select this option, the power plan will change to High Performance. - Auto Wi-fi Connect: if this option is activated, the program will show the available access points. If it is deactivated, we have to insert the IP manually.
  • Page 7 - Activate on-line: insert the key included with the CD and select Activate now. Note: the fifth field will be filled in automatically, if it happens to be different to the one that appears in your key, ignore it. - Check for updates: to check if there are any software updates available. - About: shows the version of the software installed.

  • Page 8: Web Configuration

    WEB CONFIGURATION Make sure that your computer is connected to the MirrorOp device correctly. Press the Stop button and the following will appear on your screen: Insert the IP address shown on the screen, in the example: 192.168.1.171, in your computer browser to access the web setup.
  • Page 9 Versions: - Firmware version: firmware version of the product software. Network status: - IP address: to show the IP of the FO-454 adapter connected. - Subnet mask: to show the subnet mask. - Default gateway: to show the default gateway.
  • Page 10 - Key: insert your wireless network password. Press the Apply option to save the setup, immediately afterwards the equipment will restart itself. Then connect your computer to your wireless access point and the FO-454 will also automatically connect to it.
  • Page 11 To update your equipment software to the latest version available. Reboot To reboot the system. SHARE FILES USING DLNA The FO-454 adapter allows you to project smartphone multimedia or portable electronic device content using DLNA. The compatible formats are the following: - Video: AVI/ASF/WMV/MKV/MP4/MOV/3GP/TS/RM/FLV/MPG.
  • Page 12 - 12 -...
