CSP033G
Gran Torino
Boost Overdrive
™
The MXR Gran Torino Boost Overdrive amplifies
and enriches the natural sound of your rig with the
warm, organic sound of classic tube amps, from
clean boosting with rich sustain to smooth, mellow
overdrive.
jimdunlop.com/csp033g
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for mxr Gran Torino CSP033G
Summary of Contents for mxr Gran Torino CSP033G
- Page 1 CSP033G Gran Torino Boost Overdrive ™ The MXR Gran Torino Boost Overdrive amplifies and enriches the natural sound of your rig with the warm, organic sound of classic tube amps, from clean boosting with rich sustain to smooth, mellow overdrive.
- Page 2 External Controls 1 VOL knob controls overall effect volume 2 OD switch toggles between Boost (switch OUT, blue LED) and OD (switch IN, red LED) modes 3 HI knob cuts or boosts high frequencies 4 MID knob cuts or boosts midrange frequencies 5 LO knob cuts or boosts low frequencies 6 GAIN knob controls amount of overdrive 7 FOOTSWITCH toggles effect on/bypass (blue LED indicates on)
- Page 3 Gran Torino Boost Overdrive is powered by one ™ ® 9-volt battery (remove bottom plate to install), a 9-volt AC adapter such as the Dunlop ECB003/ECB003EU, or an MXR Brick Series power supply. ™ Directions Run a cable from your guitar to the CSP033G’s INPUT jack and run another cable from the CSP033G’s OUTPUT jack to your amplifier.
- Page 4 Specifications Input Impedance 2.4 MΩ, 1kHz Output Impedance 24 kΩ max Nominal Output Level* -17dBV Tone Controls Bass ±9 dB, 40 Hz ±5.5 dB, 600 Hz Treble ±6.5 dB, 10 kHz Distortion Gain 34 dB to 67 dB, 1 kHz Noise Floor* -100 dBV Gain Range...
