- Page 1 SKYLIGHTS Skylux ® electric screen Solar Mounting instructions...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY p. 3 OVERVIEW OF PARTS p. 5 NECESSARY TOOLS p. 5 DIMENSIONS AND CURB p. 6 INTERIOR FINISH p. 6 ORIENTATION p. 6 INSTALLATION OF SOLAR PANEL p. 8 INSTALLATION ON THE INSIDE p. 11 CONTROL p. -
Page 3: Safety
SAFETY Take the necessary and required safety precautions, such as safety nets and lifelines when installing from the outside, safety goggles, gloves, hard hat, etc. Do not step on the glass. Falling from height • When using ladders to go on the roof: - Ladder in good condition? - Set up correctly at an angle of 75°? - Secured below and on top against moving? - Page 4 Sharp objects • Make sure your fingers/hands are not pinched and watch out for cuts while handling skylights or barrel vaults. • Be careful where you put your hands during the installation. • Wearing cut-resistant gloves is mandatory. Ergonomics • Always lift loads correctly: bend your knees, move your feet instead of forcing your spine, lift as close to your body as possible.
-
Page 5: Overview Of Parts
OVERVIEW PARTS Electric screen Solar Possibilities: Sunblind Blackout blind Insect screen 77375 Leaf spring HiLo screw 25 mm PH2 - 5115 for installation in PVC curb 78278 Rivet white 5.6 mm Installation instructions electric 111812 screen Solar 110751 Remote control 112209 Solar panel 112201... -
Page 6: Dimensions And Curb
DIMENSIONS AND CURB In general: The dimensions of the electric screen depend on the daylight size of the curb. The electric screen is to be installed in the daylight size, at the top of the curb. daylight size roof opening Curb requirements: It is important that the curb and its daylight size are perpendicular and have no deformations. - Page 7 long side of screen < 2000 mm 2000 mm < long side of screen > 3000 mm top view top view actuator side actuator side screen screen cable entrance solar panel + keypad cable entrance solar panel + keypad long side of screen < 2000 mm 2000 mm <...
-
Page 8: Installation Of Solar Panel
INSTALLATION OF SOLAR PANEL Remove everything from the packaging. Do not use a utility knife to prevent any damage. Preparation of the solar panel Take the solar panel and place it with the cable side up. Take the brackets and slide them over the edge of the solar panel profile. Make sure the brackets are positioned as shown in the image below (high edge of the brackets towards the cable). - Page 9 Take a cable cover and apply a layer of silicone to the indentations at the back. Place the cable cover with silicone over the hole where the cable comes out. Screw this in place with the Ø 5.3 x 45 mm HiLo screws. Make sure the screws do not turn further. Place the other cable cover at a distance of 328 mm.
- Page 10 Installation of solar panel parallel to the glass -25° to the glas -50° to the glass -75° to the glass hole for bolt Clip the bracket over the protruding pin of the cable cover and secure with the M6 bolt with the split lock washer. Choose the optimal opening so that the solar panel is positioned approximately at an angle of 45°...
-
Page 11: Installation On The Inside
Attach the solar panel connector with the cable coming from the frame. solar panel piggy tail Attach the clicked connectors to the bottom of the solar panel with fasteners. INSTALLATION ON THE INSIDE Orientation of the electric screen Orientation top / bottom: Cover with keypad cover facing always on the bottom. - Page 12 Installation of the mounting clips Position and number of clips: Mounting clips must always be provided on the rail sides of the screen. screen long side (L) ≤ 2000 mm X 12 clips X 12 clips X 12 clips X 12 clips X 12 clips 150 long side (L) >...
- Page 13 Intermediate distance X from between number # clips between between between between between between daylight size start and short of clips per side 6 - end side 400 x 400 400 x 700 400 x 1000 400 x 1300 400 x 1400 400 x 1600 400 x 1900 400 x 2200...
- Page 14 Intermediate distance X from between number # clips between between between between between between daylight size start and short of clips per side 6 - end side 800 x 1800 800 x 2000 800 x 2200 800 x 2300 800 x 2500 800 x 2800 850 x 850 900 x 900...
- Page 15 Screw the mounting clips in the daylight size of the curb by using the supplied fixations; depending on the curb type: PVC curb Polyester (GRP) curb HiLo screw rivet PVC curbs: Screw the mounting clips in the daylight size of the curb, on the screw line (if available), at 10 mm from the top side. Use the HiLo screws 25 mm PH2.
- Page 16 Place the electric screen Take the electric screen and install it correctly as described above. Place and clip the electric screen on the inside of the skylight/window in the mounting clips. Attach correctly (clip): click! 16/20 E_MH_Mounting_instructions_Skylux_Electric_screen_Solar 15/04/2024...
- Page 17 Prevent the electric screen from getting blocked by the mounting clips during opening and closing. Pull the electric screen horizontally in relation to the curb: 10 mm Pull Interior finish Make sure the cover with keypad is always accessible. Please note that the screen must be easy to dismantle in the event of disassembly. This is to provide the best possible after- sales service.
-
Page 18: Control
Once this is attached, insert the connector into the hole at the top of the screen. Test the screen by pushing the “screen” button of the remote control. The installation is finished! CONTROL RF remote control he provided remote control is connected in advance to your Skylux device. Functionalities screen ventilation set-up... - Page 19 I have lost the remote control It is possible to pair a new remote control to your device: 1. Order a new remote control (www.skylux.eu). 2. Push and hold the pairing button on the keypad (P) and release it after hearing 2 beeps At the same time, the green LED on the keypad will also flash twice.
- Page 20 General use The electric screen Solar is suited for normal use in normal climate conditions for flat roof windows and/or skylights. Do not store, place or transport the electric screen in places where extra heat accumulation can occur, nor in places that are extremely humid.
