  • Page 1 BigSqueeze Product Manual BigSqueeze Owner’s Manual / 1655.1023...

  • Page 3: Table Of Contents

    Thank you! Congratulations on your purchase of Precautionary Warnings..Page 1 the BigSqueeze , pail, filter and can crusher by Newstripe. With Assembly……………..……… Page 2 proper care and service, your new unit will provide years of trouble Operation…………….………. Page 3-4 free service.

  • Page 4: Precautionary Warnings

    BigSqueeze ALWAYS wear safety goggles or protective eyewear when operating the unit! PRECAUTIONARY WARNINGS! • Please read and understand all operation instructions as detailed in this manual. Failure to follow specified instructions may result in equipment damage or severe injury to personnel.

  • Page 5: Assembly

    ALWAYS wear safety goggles or protective eyewear when operating the unit! • If you have purchased the optional floor stand, assemble the floor stand first, using the instructions provided. Mount the BigSqueeze on the top of the floor stand. • If you are installing the unit on a bench or shelf, make sure the mounting surface can support double the weight of the unit to allow for forces generated during the crushing cycle.

  • Page 6: Operation

    BigSqueeze ALWAYS wear safety goggles or protective eyewear when operating the unit! STANDARD OPERATION NOTE: The unit may begin to automatically operate when the air supply is connected with the door closed. If this happens, it means that the operating cycle button was pushed prior to closing the door. Let the unit complete its cycle (Factory setting for release is 85 psi) and the unit will reset and be ready to begin the next cycle when the operating button is pushed.
  • Page 7 #14 Pedestal Drain Plate 1) Open the door and place the alignment ring in the bottom recess of the BigSqueeze . The alignment ring should fit nicely within the recess. 2) Place the pedestal drain plate in the center of the alignment ring.

  • Page 8: Parts List

    BigSqueeze ALWAYS wear safety goggles or protective eyewear when operating the unit! PARTS LIST Item# Description Part # Item Description Part # Gauge, 0-160 psi 10004965 Return Spring, 2 req. (Not shown) 10001658 Valve, Cycle/Operating 10001659 Door Latch/Handle 10001694 Valve, Safety Relief...

  • Page 9: Maintenance

    BigSqueeze ALWAYS wear safety goggles or protective eyewear when operating the unit! MAINTENANCE ITEM CHECK MAINTENANCE ACTION Tie Rods After every 20 hours of operation Grease with high pressure bearing (4 ram guideposts) or once a week grease. Door Hinges and Monthly Lubricate with light spray oil.

  • Page 10: Warranty

    18 (Eighteen) months from the date of purchase. In no event shall Newstripe, Inc. be liable for incidental or consequential damages and no person had any authority to bind it to any representation or warranty, not be responsible for work done, materials furnished, or repairs made by others without its' specific written authorization.
