Safety instructions
Carefully read the operation and safety instructions before commissioning and connecting the device, ensuring that all
requirements are met.
• Inspect the machine for damage before commissioning. If any damage is found, it shall not be operated.
• Always supervise the machine when it is switched on.
• Please use original SCHEU-DENTAL strips of 114x499mm!
• Keep the device out of reach of children!
• Avoid any contact with liquids in order to protect the device against electric shock.
• Infrared heaters reach high temperatures during operation.
• Do not operate the device close to highly flammable materials.
• Ensure to operate the device only using its handles to avoid the risk of burns.
• The device shall only be transported when it has cooled down.
• Make sure that the heater is not exposed to any load during transport.
• Safe operation of the device can only be ensured using the original SCHEU-DENTAL spare parts.
• Any kind of service operation shall always be performed by service technicians instructed by SCHEU-DENTAL or at the
SCHEU-DENTAL facilities. Any conversion or modification of the device compromises product safety and leads to the
expiration of warranty and guarantee claims.
• Never open the device without authorization. Caution: Risk of injury!
• Never carry out repairs yourself, without consulting a specialist or following the instruction in this manual!
To prevent electrical overloads, overheating, or potential damage to your electrical system, please take the following
precautions:
• Check your electrical capacity: ensure that your electrical circuit can handle the current requirements of this device.
Consult with a qualified electrician if you are unsure.
• Avoid overloading circuits: do not use multiple high-power devices on the same circuit as this device to prevent
electrical tripping or damage to your electrical infrastructure.
• Use the appropriate power source: always connect this device to a compatible power source with the required voltage
and amperage rating.
The installation of power supply for the connection of our equipment shall be carried out in accordance with international
regulations and the regulations derived thereof. Our equipment is built according to VDE (German Association for
Electrical Engineering, Electronics and Information Technology), protection class I and shall be connected to a socket with
protective conductor.
Installation
Ensure to use solely the original power and air connections provided with the delivery. Make also sure that the
compressed air supply is completely free from oil residues and humidity and has a minimum feed pressure of 4.0 bar and
flow rate of 5.0 CFM, 140 l/min . The device operates on 230V, 115V, 100V AC with 50 or 60Hz. The maximum power input is
1450 W. Plug into an outlet of at least 16A without an other appliance connected.
1. Positioning device
Place the device on a flat surface not close to steam jet and sand blasting units or places with high plaster and dust
exposure. Make sure that hot air can exit the device on the back, do not place the device directly against a wall. The foil
tray
1
should rest on the support rails
surface.
2. Mains connection
Connect the BIOSTAR® 4-Aligner device to the power supply by plugging the power cable provided with the machine into
the power socket
on the back of the device. A single fuse is built in the main socket protecting the electrical parts from
4
overvoltage. In order to exchange the fuses, press the small clip underneath the power socket and remove the fuse box
A spare fuse is stored in the fuse box. The fuse T15A (REF 3030.935) is used.
3. Compressed air connection
A 20 bar air hose with filter element
BIOSTAR® 4-Aligner device to the provided (DN 7.2 / 6 mm inner tube diameter) air hose and your compressed air system.
The operating pressure is set at the factory to 4.0 bar/58 psi. This pressure guarantees best thermoforming results and
is being continuously indicated on the display; it shall not be modified. In case a reduction should be required, you can
adjust the pressure using the pressure regulator
pulling and can then be turned (-
2
when not used. Placing the foil tray on top of the device might damage the
5
(DN 7.2 / 6 mm inner tube diameter) is connected to the device. Connect the
6
on the back of the device. The pressure regulator is unlocked by
+). After adjusting, the pressure regulator should be locked again by pressing it in.
ENGLISH
GB
3
.
