DURA -METER Quick Start Manual

DURA-METER
Operating Temp
Flow Rate
Meter Accuracy
Backlit LCD Display
Max Pressure
Power Source
Nutating Disc
Wetted Materials
Housing Chamber
Moisture Sealed
Amount Metered
Batch Count
Units Measured
Chemically Resistant
Calibration
Dimensions
Weight
EPA Compliant
™
The meter will turn ON
with any button press or
when uid passes through
the meter. It will turn OFF
when not in use.
Use buttons to navigate the
four main menus; Reset,
Program, Calibration, Info.
The buttons correspond to
the on screen indicators.
4-AAA batteries provide about 70
hours of use with the backlight
turned ON, and about 300 hours
with the backlight OFF.
-10˚F to 130˚F, -23˚C to 54˚C
2 to 22GPM, 7.5 to 83LPM
+/ - .5%
Yes; with back-light timeout
40 PSI
4 "AAA" batteries; strength indicator
Yes
Polypropylene; 304 Stainless Steel;
Ryton; EPDM, Viton or Silicone seals
®
Polypropylene
Yes; with sealed circuitry
Yes
Yes
Gallons, Liters and Ounces
Yes
Quick List or Manual
5-1/4" W x 5-1/4" H x 4-1/4" D
1.5 lbs
Yes
C A L I B R AT I O N
NOTE: Use a primed system. Verify your calibration. Fluid viscosity changes with
temperature.
Q U I C K L I S T
Select a thickness number. For
most agricultural chemicals, 8 is a
good starting point.
Check
Pump 5 Gallons and see
how close you are
Adjust
Each reference number represents
1% change. If the meter reads
high, lower the number. (meter
shows 5.25 gallons, adjust the
number down 5% or 5 numbers.)
Repeat as needed
M E T H O D T R A I T S
Q U I C K L I S T
• Number is the same • Most accurate
across any Dura-Meter, • Usually only takes one
attempt
great for eet use
• Adjustable to compensate
for different measurement
containers; 2.5-7 Gallon
range
M A N UA L
Once the cal jug has 5 gallons
in it, Press "Cont"inue button
Adjust "Up" or Down"
to match the volume in
the Cal Jug
Press save &
VERIFY!
M A N UA L
Arcadia, IN 46030 (317) 984-4003
